Brand:Siemens Item No.:6AG1964-2AA04-7AB0 Product Origin: Germany Product Dimensions:13.0 × 2.6 × 5.4 cm Product Weight:0.065 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1964-2AA04-7AB0 is a SIPLUS S7-400 IF964-DP interface module based on the standard 6ES7964-2AA04-0AB0. It is designed to provide an additional PROFIBUS DP interface for compatible S7-400 CPU configurations and distributed I/O networks.
The module uses an electrically isolated RS-485 interface with a 9-pin Sub-D connection and supports PROFIBUS DP transmission rates up to 12 Mbit/s. It supports DP master operation as the default configuration as well as DP slave functionality, with services including PG/OP communication, equidistance, SYNC/FREEZE, and direct data exchange. The SIPLUS version incorporates conformal coating and an extended operating temperature range of approximately -25 °C to +70 °C.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG1964-2AA04-7AB0
Product Type
SIPLUS S7-400 IF964-DP Interface Module
Base Standard Part Number
6ES7964-2AA04-0AB0
Application
SIMATIC S7-400
Communication Interface
PROFIBUS DP
Physical Interface
Electrically isolated RS-485
Connector
9-pin Sub-D socket
DP Master
Yes, default setting
DP Slave
Yes
Transmission Rate
9.6 kbit/s to 12 Mbit/s
Maximum DP Slaves
125, depending on CPU
Maximum Cable Length
1,200 m; approx. 100 m at 12 Mbit/s
User Data per DP Slave
Up to 244 bytes input / 244 bytes output
Services
PG/OP, equidistance, SYNC/FREEZE, direct data exchange
Maximum Current Consumption
150 mA from CPU
Typical Power Loss
Approx. 1 W
Environmental Design
Conformal coating
Operating Temperature
Approx. -25 °C to +70 °C
Dimensions (L × W × H)
13.0 × 2.6 × 5.4 cm
Net Weight
Approx. 0.065 kg
Recommended Companion Models
Model
Product Name
6AG1416-3XS07-4AB0
Siemens SIPLUS S7-400 CPU 416-3
6AG1416-3ES07-4AB0
Siemens SIPLUS S7-400 CPU 416-3 PN/DP
6AG1417-4XT07-4AB0
Siemens SIPLUS S7-400 CPU 417-4
6AG1972-0AA02-7XA0
Siemens SIPLUS DP RS-485 Repeater
Frequently Selected Alternatives
Model
Product Name
6ES7964-2AA04-0AB0
Siemens SIMATIC S7-400 IF964-DP Interface Module
6AG1960-1AA06-7XA0
Siemens SIPLUS S7-400H Near Synchronization Module
6AG1972-0AA02-7XA0
Siemens SIPLUS DP RS-485 Repeater
6AG1972-0BA12-2XA0
Siemens SIPLUS PROFIBUS DP Bus Connector
Where It Fits in Industrial Applications
• Designed as a SIPLUS S7-400 IF964-DP interface module for connecting distributed I/O systems over PROFIBUS DP.
• Provides an electrically isolated RS-485 PROFIBUS DP interface through a 9-pin Sub-D connection.
• Supports PROFIBUS DP master operation as the default configuration and can also operate as a DP slave.
• Intended for compatible SIPLUS S7-400 CPU configurations requiring an additional PROFIBUS DP interface.
Key Strengths at a Glance
• Supports PROFIBUS DP communication at transmission rates up to 12 Mbit/s.
• Provides electrically isolated RS-485 communication for improved industrial network integration.
• Supports up to 125 DP slaves, depending on the installed S7-400 CPU.
• Supports PG/OP communication, equidistance, SYNC/FREEZE, and direct slave-to-slave data exchange.
• Features conformal coating and an extended operating temperature range of approximately -25 °C to +70 °C.
Technical FAQs
1. What is Siemens 6AG1964-2AA04-7AB0?
6AG1964-2AA04-7AB0 is a SIPLUS S7-400 IF964-DP interface module based on the Siemens 6ES7964-2AA04-0AB0.
2. What is the main function of the IF964-DP module?
The module adds a PROFIBUS DP interface to compatible S7-400 CPU configurations for communication with distributed I/O and other PROFIBUS DP devices.
3. What communication interface does the module use?
It uses an electrically isolated RS-485 physical interface connected through a 9-pin Sub-D socket.
4. What is the maximum PROFIBUS DP transmission rate?
The maximum PROFIBUS DP transmission rate is 12 Mbit/s.
5. How many PROFIBUS DP devices can be connected?
Up to 125 DP slaves can be supported, depending on the specific S7-400 CPU used.
6. What is the maximum PROFIBUS DP cable length?
The maximum cable length is approximately 1,200 m at lower transmission rates such as 9.6 kbit/s; at 12 Mbit/s, the specified maximum is approximately 100 m.
7. Can the module operate as a DP slave?
Yes. DP slave functionality is supported in addition to DP master operation.
8. What communication services are supported?
Supported services include PG/OP communication, equidistance mode, SYNC/FREEZE, and direct data exchange between PROFIBUS DP slaves.
9. What is the operating temperature range?
The SIPLUS version is specified for an operating temperature range of approximately -25 °C to +70 °C, with additional altitude-dependent temperature limitations at higher installation elevations.
10. What should be verified before ordering this interface module?
The S7-400 CPU type, required PROFIBUS DP function, available module position, transmission rate, network topology, and applicable Siemens compatibility documentation should be verified before ordering.
