Siemens 6AG1972-0BB70-7XA0 SIPLUS DP PROFIBUS FastConnect PG Bus Connector
Siemens 6AG1972-0BB70-7XA0 SIPLUS DP PROFIBUS FastConnect PG Bus Connector
0.0
Points
Brand:Siemens Item No.: 6AG1972-0BB70-7XA0 Product Origin: Germany Product Dimensions:6.70 × 7.90 × 3.00 cm Product Weight:0.053 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1972-0BB70-7XA0 is a SIPLUS DP PROFIBUS connector designed for PROFIBUS DP network connections in industrial automation systems. It is based on the 6ES7972-0BB70-0XA0 design and features a PG socket, 90° cable outlet, and Siemens FastConnect insulation displacement technology.
The connector supports PROFIBUS DP transmission rates from 9.6 kbit/s to 12 Mbit/s. Its screwed mechanical connection, conformal coating, and -40 to +70 °C operating range make it suitable for demanding industrial communication installations.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG1972-0BB70-7XA0
Product Type
SIPLUS DP PROFIBUS connector
Base Design
6ES7972-0BB70-0XA0
Network Type
PROFIBUS DP
Transmission Rate
9.6 kbit/s to 12 Mbit/s
PG Socket
Yes
Cable Outlet
90°
Cable Connection Technology
FastConnect insulation displacement
Locking Mechanism
Screwed joint
Conformal Coating
Yes
Operating Temperature
-40 to +70 °C
Maximum Installation Altitude
5000 m
Relative Humidity
Up to 100% RH including condensation and frost
Dimensions (L × W × H)
6.70 × 7.90 × 3.00 cm*
Net Weight
0.053 kg
Product Family
SIPLUS DP PROFIBUS
Application
PROFIBUS industrial network connection
* The published Siemens dimensional data is provided as packaging dimensions rather than a fixed product-body dimension.
Recommended Companion Models
Model
Product Name
6AG1972-0BB12-2XA0
Siemens SIPLUS DP PROFIBUS 90° PG Bus Connector
6AG1972-0BB42-7XA0
Siemens SIPLUS DP PROFIBUS 35° PG Bus Connector
6AG1972-0BA42-7XA0
Siemens SIPLUS DP PROFIBUS 35° Bus Connector without PG
6AG1972-0AA02-7XA0
Siemens SIPLUS DP RS-485 Repeater
Frequently Selected Alternatives
Model
Product Name
6ES7972-0BB70-0XA0
Siemens SIMATIC DP PROFIBUS FastConnect Connector with PG Socket
6AG1972-0BB12-2XA0
Siemens SIPLUS DP PROFIBUS 90° PG Bus Connector
6AG1972-0BB42-7XA0
Siemens SIPLUS DP PROFIBUS 35° PG Bus Connector
6AG1972-0DA00-2AA0
Siemens SIPLUS DP RS-485 Terminator
Where It Fits in Industrial Applications
• Designed for PROFIBUS DP network connections in Siemens industrial automation and SIMATIC systems.
• Provides a 90° cable outlet for organized PROFIBUS cable routing in control cabinets and automation panels.
• Includes a PG socket for convenient connection of programming devices or compatible service equipment.
• Supports PROFIBUS DP communication rates from 9.6 kbit/s up to 12 Mbit/s.
Key Strengths at a Glance
• SIPLUS DP PROFIBUS connector based on the Siemens 6ES7972-0BB70-0XA0 design.
• Conformal coating and an operating temperature range of -40 to +70 °C support demanding environmental conditions.
Technical FAQs
1. What is Siemens 6AG1972-0BB70-7XA0?
6AG1972-0BB70-7XA0 is a SIPLUS DP PROFIBUS connector with a PG socket, 90° cable outlet, and FastConnect insulation displacement connection technology.
2. What standard Siemens connector is this product based on?
The SIPLUS version is based on the Siemens 6ES7972-0BB70-0XA0 PROFIBUS connector design.
3. What PROFIBUS transmission rates are supported?
The connector supports PROFIBUS DP transmission rates from 9.6 kbit/s up to 12 Mbit/s.
4. Does the connector include a PG socket?
Yes. The 6AG1972-0BB70-7XA0 includes a PG socket for connecting a programming device or compatible service equipment.
5. What type of cable connection does this connector use?
It uses Siemens FastConnect insulation displacement technology for connecting the PROFIBUS cable.
6. What is the cable outlet angle?
The connector has a 90° cable outlet, allowing the connected PROFIBUS cable to be routed perpendicular to the device connection.
7. What is the purpose of the SIPLUS conformal coating?
The conformal coating provides additional protection for the electronic and connection assembly against demanding environmental conditions and contamination.
8. What operating temperature range is specified?
The connector is specified for operation from -40 to +70 °C.
9. How is the connector mechanically secured?
The connector uses a screwed joint for mechanical fastening to the connected device.
10. What should be checked before ordering this PROFIBUS connector?
The required PROFIBUS connector design, PG socket requirement, 90° cable outlet, FastConnect cable technology, transmission rate, and compatibility with the applicable Siemens equipment should be verified before installation.
