Siemens 6AG1992-1AM00-7AA0 SIPLUS NET SCALANCE X SFP992-1LD Optical Transceiver
Siemens 6AG1992-1AM00-7AA0 SIPLUS NET SCALANCE X SFP992-1LD Optical Transceiver
0.0
Points
Brand:Siemens Item No.:6AG1992-1AM00-7AA0 Product Origin: Germany Product Dimensions:5.70 × 1.40 × 0.90 cm Product Weight:0.010 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1992-1AM00-7AA0 is a SIPLUS NET SCALANCE X SFP992-1LD plug-in optical transceiver designed for compatible SCALANCE X industrial Ethernet switches. It is based on the 6GK5992-1AM00-8AA0 design and provides one 1000 Mbps LC optical port for single-mode fiber communication.
The transceiver operates at a 1310 nm wavelength and supports an optical transmission range of up to 10 km. Its SIPLUS configuration includes conformal coating and an extended operating temperature range of -40 to +85 °C, making it suitable for industrial Ethernet applications requiring long-distance optical connectivity.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG1992-1AM00-7AA0
Product Type
SIPLUS NET SCALANCE X SFP992-1LD
Base Design
6GK5992-1AM00-8AA0
Product Form
SFP plug-in transceiver
Application
SCALANCE X accessory
Optical Port
1 × LC
Data Rate
1000 Mbps
Optical Wavelength
1310 nm
Fiber Type
Single-mode
Optical Transmission Range
0 to 10 km
Transmitter Output
-9.5 to -3 dBm
Maximum Receiver Input
-3 dBm
Receiver Sensitivity
-19 dBm
Protection Rating
IP20
Conformal Coating
Yes
Operating Temperature
-40 to +85 °C
Storage Temperature
-40 to +85 °C
Transport Temperature
-40 to +85 °C
Fastening Method
Latched
Dimensions (L × W × H)
5.70 × 1.40 × 0.90 cm
Net Weight
0.010 kg
Product Family
SIPLUS NET SCALANCE X SFP
Application Interface
Industrial Ethernet optical communication
Recommended Companion Models
Model
Product Name
6AG1992-1AL00-7AA0
Siemens SIPLUS NET SCALANCE X SFP992-1 Multimode Optical Transceiver
6AG1991-1AF00-7AA0
Siemens SIPLUS NET SCALANCE X SFP991-1LD Optical Transceiver
6AG1901-1BB20-7AA0
Siemens SIPLUS NET RJ45 Plug 90° Connector
6AG1901-1BB10-7AA0
Siemens SIPLUS NET RJ45 Plug 180° Connector
Frequently Selected Alternatives
Model
Product Name
6GK5992-1AM00-8AA0
Siemens SCALANCE X SFP992-1LD 1000 Mbps Single-Mode SFP
6AG1992-1AL00-7AA0
Siemens SIPLUS NET SCALANCE X SFP992-1 Multimode Optical Transceiver
6AG1991-1AF00-7AA0
Siemens SIPLUS NET SCALANCE X SFP991-1LD 100 Mbps Optical Transceiver
6AG1800-4BA00-7AA0
Siemens SIPLUS SINAUT ST7 TIM 4R-IE Communication Module
Where It Fits in Industrial Applications
• Designed as an SFP accessory for compatible Siemens SCALANCE X industrial Ethernet switches.
• Provides one 1000 Mbps optical LC interface for high-speed industrial Ethernet communication.
• Uses single-mode optical fiber for transmission distances of up to 10 km.
• Suitable for industrial networking applications requiring long-distance optical communication in demanding environmental conditions.
Key Strengths at a Glance
• SIPLUS NET SCALANCE X SFP992-1LD plug-in transceiver based on the Siemens 6GK5992-1AM00-8AA0 design.
• Provides one 1000 Mbps LC optical port for single-mode fiber communication.
• Uses a 1310 nm optical wavelength with a specified transmission range of 0 to 10 km.
• Conformal coating and -40 to +85 °C operating capability support demanding industrial networking environments.
Technical FAQs
1. What is Siemens 6AG1992-1AM00-7AA0?
6AG1992-1AM00-7AA0 is a SIPLUS NET SCALANCE X SFP992-1LD plug-in transceiver for compatible SCALANCE X industrial Ethernet switches.
2. What standard Siemens product is this SFP module based on?
The SIPLUS version is based on the Siemens 6GK5992-1AM00-8AA0 SFP992-1LD design.
3. What data rate does the SFP992-1LD support?
The transceiver provides one optical LC port supporting a data rate of 1000 Mbps.
4. What type of fiber does the SFP992-1LD use?
The module is designed for single-mode optical fiber.
5. What is the maximum specified transmission range?
The specified optical transmission range is up to 10 km, depending on the optical fiber and network conditions.
6. What optical wavelength does the module use?
The optical interface operates at 1310 nm for single-mode transmission.
7. What type of optical connector is provided?
The module uses an LC optical interface.
8. What operating temperature range is supported?
The module is specified for operation from -40 to +85 °C. A maximum operating temperature of +85 °C is permitted for a duration of up to 16 hours.
9. How is the SFP module installed?
The SFP module uses a latched fastening method for installation in a compatible SCALANCE X interface.
10. What should be verified before ordering this SFP module?
The compatible SCALANCE X switch, required 1000 Mbps optical interface, single-mode fiber type, LC connector, transmission distance, and environmental requirements should be verified before installation.
