Siemens 6AG2136-6BA00-1CA0 SIPLUS ET 200SP F-DI Safety Digital Input Module
Siemens 6AG2136-6BA00-1CA0 SIPLUS ET 200SP F-DI Safety Digital Input Module
0.0
Points
Brand:Siemens Item No.: 6AG2136-6BA00-1CA0 Product Origin: Germany Product Dimensions:7.30 × 1.50 × 5.80 cm Product Weight:0.049 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2136-6BA00-1CA0 is a SIPLUS ET 200SP F-DI 4/8x24 V DC fail-safe digital input module based on the 6ES7136-6BA00-0CA0 design. It provides eight fail-safe 24 V DC digital inputs for safety-related automation applications.
The module supports safety functions up to PL e according to ISO 13849-1 and SIL 3 according to IEC 61508. Its SIPLUS RAIL configuration includes conformal coating and an operating temperature range of -30 to +60 °C, with +70 °C permitted for 10 minutes under specified extended-temperature conditions. Siemens identifies 6AG2136-6BA01-2CA0 as the successor product.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG2136-6BA00-1CA0
Product Type
SIPLUS ET 200SP F-DI 4/8x24 V DC RAIL
Base Design
6ES7136-6BA00-0CA0
Product Family
SIPLUS ET 200SP fail-safe digital input modules
Number of Digital Inputs
8
Input Type
Fail-safe digital input
Rated Input Voltage
24 V DC
Permissible Supply Voltage
20.4–28.8 V DC
Safety Performance Level
Up to PL e
Safety Integrity Level
Up to SIL 3
Suitable BaseUnit
Type A0
Conformal Coating
Yes
Protection Rating
IP20
Horizontal Operating Temperature
-30 to +60 °C
Extended Temperature
+70 °C for 10 minutes under specified conditions
Maximum Installation Altitude
2000 m
Mounting
ET 200SP rail system
Dimensions (L × W × H)
7.30 × 1.50 × 5.80 cm
Net Weight
Approx. 0.049 kg
Application
Fail-safe 24 V DC digital signal acquisition
Recommended Companion Models
Model
Product Name
6AG2193-6BP00-4DA0
Siemens SIPLUS ET 200SP BU15-P16+A0+2D BaseUnit
6AG2136-6AA00-1CA1
Siemens SIPLUS ET 200SP F-AI 4xI 2/4-wire HF Analog Input Module
6AG2136-6DB00-1CA0
Siemens SIPLUS ET 200SP F-DQ 4x24VDC/2A PM Safety Output Module
6AG2136-6DC00-1CA0
Siemens SIPLUS ET 200SP F-DQ 8x24VDC/0.5A Safety Output Module
Frequently Selected Alternatives
Model
Product Name
6ES7136-6BA00-0CA0
Siemens SIMATIC ET 200SP F-DI 8x24 V DC HF Digital Input Module
6AG2136-6BA01-2CA0
Siemens SIPLUS ET 200SP F-DI 4/8x24 V DC RAIL Successor Module
6AG2136-6DB00-1CA0
Siemens SIPLUS ET 200SP F-DQ 4x24VDC/2A PM Safety Output Module
6AG2136-6DC00-1CA0
Siemens SIPLUS ET 200SP F-DQ 8x24VDC/0.5A Safety Output Module
Where It Fits in Industrial Applications
• Designed for fail-safe digital signal acquisition in Siemens SIMATIC ET 200SP distributed I/O systems.
• Provides eight fail-safe digital inputs for 24 V DC signals and safety-related field devices.
• Suitable for safety functions requiring Performance Level e according to ISO 13849-1 and SIL 3 according to IEC 61508.
• Designed for demanding industrial and railway applications with SIPLUS conformal coating and extended environmental protection.
Key Strengths at a Glance
• SIPLUS ET 200SP F-DI 4/8x24 V DC RAIL module based on the Siemens 6ES7136-6BA00-0CA0 design.
• Provides eight fail-safe 24 V DC digital inputs with configurable channel evaluation.
• Supports safety applications up to PL e and SIL 3.
• Conformal coating and extended temperature capability support harsh industrial operating conditions.
Technical FAQs
1. What is Siemens 6AG2136-6BA00-1CA0?
6AG2136-6BA00-1CA0 is a SIPLUS ET 200SP F-DI 4/8x24 V DC fail-safe digital input module based on the 6ES7136-6BA00-0CA0 design.
2. How many digital inputs does the module provide?
The module provides eight fail-safe digital inputs for 24 V DC signals.
3. What is the rated supply voltage?
The module operates from a rated 24 V DC supply, with a permissible voltage range of 20.4 to 28.8 V DC.
4. What safety levels can the module support?
The module is designed for safety applications up to Performance Level e according to ISO 13849-1 and SIL 3 according to IEC 61508.
5. Is the module suitable for railway applications?
Yes. The SIPLUS RAIL version is designed with environmental characteristics supporting railway applications, subject to the applicable installation and system requirements.
6. What environmental temperature range is specified?
The module is specified for -30 to +60 °C in horizontal installation. An extended temperature of +70 °C is permitted for 10 minutes under the specified OT1/ST1/ST2 conditions.
7. Does the module have conformal coating?
Yes. The module has conformal coating for enhanced protection against demanding environmental conditions.
8. What type of BaseUnit is required?
The module is designed for use with ET 200SP BaseUnits of type A0.
9. Is 6AG2136-6BA00-1CA0 still the current SIPLUS version?
The 6AG2136-6BA00-1CA0 is identified as a spare-part/cancelled SIPLUS version, and Siemens lists 6AG2136-6BA01-2CA0 as its successor.
10. What should be verified before ordering this module?
The ET 200SP station configuration, required BaseUnit, safety requirements, firmware compatibility, environmental conditions, and whether the original module or its Siemens successor is required should be verified before installation.
