Siemens 6AG2136-6DB00-1CA0 SIPLUS ET 200SP F-DQ Safety Digital Output Module
Siemens 6AG2136-6DB00-1CA0 SIPLUS ET 200SP F-DQ Safety Digital Output Module
0.0
Points
Brand:Siemens Item No.: 6AG2136-6DB00-1CA0 Product Origin: Germany Product Dimensions:7.30 × 1.50 × 5.80 cm Product Weight:0.057 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2136-6DB00-1CA0 is a SIPLUS ET 200SP F-DQ 4x24VDC/2A PM fail-safe digital output module based on the 6ES7136-6DB00-0CA0 design. It provides four transistor outputs for switching 24 V DC loads in safety-related automation applications.
The outputs are configurable and include short-circuit, overload, and open-circuit monitoring. The module supports fail-safe applications up to PL e according to ISO 13849 and SIL 3 according to IEC 61508. Its SIPLUS configuration features conformal coating and an operating temperature range of -30 to +60 °C, with +70 °C permitted for 10 minutes under specified conditions.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG2136-6DB00-1CA0
Product Type
SIPLUS ET 200SP F-DQ 4x24VDC/2A PM
Base Design
6ES7136-6DB00-0CA0
Product Family
SIPLUS extreme RAIL digital F-output modules
Number of Digital Outputs
4
Output Type
Fail-safe transistor
Rated Output Voltage
24 V DC
Permissible Supply Voltage
20.4–28.8 V DC
Rated Output Current
2 A per output
Short-Circuit Protection
Yes
Overload Protection
Yes
Open-Circuit Detection
Yes
Open-Circuit Response Threshold
Approx. 8 mA
Fail-Safe Performance Level
Up to PL e
Safety Integrity Level
Up to SIL 3
Suitable BaseUnit
Type A0
Conformal Coating
Yes
Protection Rating
IP20
Operating Temperature
-30 to +60 °C
Extended Temperature
+70 °C for 10 minutes under specified conditions
Mounting
ET 200SP rail system
Dimensions (L × W × H)
7.30 × 1.50 × 5.80 cm
Net Weight
Approx. 0.057 kg
Application
Fail-safe 24 V DC digital output switching
Recommended Companion Models
Model
Product Name
6AG2193-6BP00-4DA0
Siemens SIPLUS ET 200SP BU15-P16+A0+2D BaseUnit
6AG2136-6BA00-1CA0
Siemens SIPLUS ET 200SP F-DI 4/8x24VDC Safety Digital Input Module
6AG2136-6DC00-1CA0
Siemens SIPLUS ET 200SP F-DQ 8x24VDC/0.5A Safety Digital Output Module
6AG2136-6RA00-1BF0
Siemens SIPLUS ET 200SP F-RQ 24VDC/230VAC/5A Safety Relay Output Module
Frequently Selected Alternatives
Model
Product Name
6ES7136-6DB00-0CA0
Siemens SIMATIC ET 200SP F-DQ 4x24VDC/2A PM Digital Output Module
6AG2136-6DC00-1CA0
Siemens SIPLUS ET 200SP F-DQ 8x24VDC/0.5A Safety Digital Output Module
6AG2136-6BA00-1CA0
Siemens SIPLUS ET 200SP F-DI 4/8x24VDC Safety Digital Input Module
6AG2136-6RA00-1BF0
Siemens SIPLUS ET 200SP F-RQ 24VDC/230VAC/5A Safety Relay Output Module
Where It Fits in Industrial Applications
• Designed for fail-safe digital output switching in Siemens SIMATIC ET 200SP distributed I/O systems.
• Provides four 24 V DC transistor outputs for controlling safety-related actuators and loads.
• Supports output currents up to 2 A per channel for suitable resistive loads.
• Suitable for safety applications up to PL e according to ISO 13849 and SIL 3 according to IEC 61508.
Key Strengths at a Glance
• SIPLUS ET 200SP F-DQ 4x24VDC/2A PM module based on the Siemens 6ES7136-6DB00-0CA0 design.
• Four fail-safe transistor outputs provide configurable 24 V DC switching for industrial loads.
• Conformal coating and extended temperature capability support demanding industrial and railway environments.
Technical FAQs
1. What is Siemens 6AG2136-6DB00-1CA0?
6AG2136-6DB00-1CA0 is a SIPLUS ET 200SP F-DQ 4x24VDC/2A PM fail-safe digital output module based on the 6ES7136-6DB00-0CA0 design.
2. How many digital outputs does the module provide?
The module provides four fail-safe digital transistor outputs.
3. What output voltage does the module use?
The rated output voltage is 24 V DC, with the module operating from a permissible supply range of 20.4 to 28.8 V DC.
4. What is the rated output current?
Each output supports up to 2 A with a suitable resistive load.
5. Does the module provide short-circuit protection?
Yes. The digital outputs include short-circuit protection as well as overload protection.
6. Does the module provide open-circuit detection?
Yes. Open-circuit detection is provided, with the specified response threshold of approximately 8 mA.
7. What safety performance can the module support?
The module is designed for fail-safe digital output applications up to Performance Level e according to ISO 13849 and SIL 3 according to IEC 61508.
8. What BaseUnit is required for the module?
The module is designed for use with ET 200SP BaseUnits of type A0.
9. What environmental conditions are supported?
The SIPLUS version has conformal coating and is specified for -30 to +60 °C operation, with +70 °C permitted for 10 minutes under the specified extended-temperature conditions.
10. What should be verified before ordering this output module?
The ET 200SP station configuration, required A0 BaseUnit, output load requirements, safety architecture, firmware compatibility, and applicable Siemens documentation should be verified before installation.
