Siemens 6AG2136-6PA00-1BC0 SIPLUS ET 200SP F-PM-E Fail-Safe Power Module
Siemens 6AG2136-6PA00-1BC0 SIPLUS ET 200SP F-PM-E Fail-Safe Power Module
0.0
Points
Brand:Siemens Item No.:6AG2136-6PA00-1BC0 Product Origin: Germany Product Dimensions:8.90 × 6.60 × 3.80 cm Product Weight:0.084 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2136-6PA00-1BC0 is a SIPLUS ET 200SP F-PM-E 24 V DC/8 A PPM fail-safe power module based on the 6ES7136-6PA00-0BC0 design. It is used for safety-related 24 V DC shutdown of DQ and F-DQ output modules within an ET 200SP potential group.
The module provides two fail-safe digital inputs and one fail-safe PPM digital output, together with diagnostic functions and PROFIsafe communication. It supports safety applications up to PL D/SIL 2 or PL e/SIL 3, depending on the implemented safety function. The SIPLUS configuration includes conformal coating and an operating range of -30 to +60 °C, with +70 °C permitted for 10 minutes under specified conditions.
Technical Specifications
Parameter
Specification
Brand
Siemens
Part Number
6AG2136-6PA00-1BC0
Product Type
SIPLUS ET 200SP F-PM-E 24 V DC/8 A PPM
Base Design
6ES7136-6PA00-0BC0
Product Family
SIPLUS extreme RAIL fail-safe special modules
Rated Supply Voltage
24 V DC
Permissible Supply Voltage
20.4–28.8 V DC
Number of Fail-Safe Digital Inputs
2
Number of Fail-Safe Digital Outputs
1
Output Switching
PPM
Rated Output Current
8 A
Typical Power Loss
Approx. 5 W
Safety Performance
Up to PL e
Safety Integrity Level
Up to SIL 3
PROFIsafe
Yes
Diagnostic Function
Yes
Suitable BaseUnit
Type C0
Conformal Coating
Yes
Protection Rating
IP20
Operating Temperature
-30 to +60 °C
Extended Temperature
+70 °C for 10 minutes under specified conditions
Dimensions (L × W × H)
8.90 × 6.60 × 3.80 cm*
Net Weight
0.084 kg
Application
Fail-safe ET 200SP power switching
* The published 8.90 × 6.60 × 3.80 cm dimensions correspond to the Siemens-listed packaging dimensions.
Recommended Companion Models
Model
Product Name
6AG2136-6DB00-1CA0
Siemens SIPLUS ET 200SP F-DQ 4x24VDC/2A PM Safety Digital Output Module
6AG2136-6DC00-1CA0
Siemens SIPLUS ET 200SP F-DQ 8x24VDC/0.5A Safety Digital Output Module
6AG2136-6BA00-1CA0
Siemens SIPLUS ET 200SP F-DI 4/8x24VDC Safety Digital Input Module
6AG2193-6BP00-4DA0
Siemens SIPLUS ET 200SP BU15-P16+A0+2D BaseUnit
Frequently Selected Alternatives
Model
Product Name
6ES7136-6PA00-0BC0
Siemens SIMATIC ET 200SP F-PM-E 24VDC/8A PPM Fail-Safe Power Module
6AG2136-6DB00-1CA0
Siemens SIPLUS ET 200SP F-DQ 4x24VDC/2A PM Safety Digital Output Module
6AG2136-6DC00-1CA0
Siemens SIPLUS ET 200SP F-DQ 8x24VDC/0.5A Safety Digital Output Module
6AG2136-6RA00-1BF0
Siemens SIPLUS ET 200SP F-RQ 24VDC/230VAC/5A Safety Relay Output Module
Where It Fits in Industrial Applications
• Designed for fail-safe power management in Siemens SIMATIC ET 200SP distributed I/O systems.
• Provides safety-related 24 V DC shutdown of DQ and F-DQ output modules within the associated potential group.
• Integrates two fail-safe digital inputs and one fail-safe PPM digital output for safety-related control functions.
• Suitable for PROFIsafe-based safety applications requiring up to PL e/SIL 3, depending on the implemented safety architecture.
Key Strengths at a Glance
• SIPLUS ET 200SP F-PM-E 24 V DC/8 A PPM module based on the Siemens 6ES7136-6PA00-0BC0 design.
• Provides fail-safe switching of 24 V DC power to connected DQ and F-DQ modules.
• Supports up to 8 A output current with PPM switching and integrated diagnostic functions.
• Conformal coating and -30 to +60 °C operating capability, with specified +70 °C short-duration operation, support demanding industrial and railway environments.
Technical FAQs
1. What is Siemens 6AG2136-6PA00-1BC0?
6AG2136-6PA00-1BC0 is a SIPLUS ET 200SP F-PM-E 24 V DC/8 A PPM fail-safe power module based on the 6ES7136-6PA00-0BC0 design.
2. What is the main function of the F-PM-E module?
The module provides fail-safe 24 V DC power switching for DQ and F-DQ output modules within its potential group.
3. What supply voltage does the module use?
The module has a rated supply voltage of 24 V DC and supports a permissible range of 20.4 to 28.8 V DC.
4. What output current can the module handle?
The PPM output supports up to 8 A, with the applicable derating requirements depending on operating conditions.
5. How many fail-safe digital inputs are provided?
The module provides two fail-safe digital inputs for safety-related signal processing.
6. Does the module provide a fail-safe digital output?
Yes. It provides one fail-safe PPM digital output for safety-related switching.
7. What safety levels can the module support?
The module supports safety applications up to PL D/SIL 2 or PL e/SIL 3, depending on the configured safety function and overall system architecture.
8. Which BaseUnit is required for this module?
The module is designed for use with an ET 200SP BaseUnit of type C0.
9. What environmental conditions are supported?
The SIPLUS version features conformal coating and is specified for -30 to +60 °C operation, with +70 °C permitted for 10 minutes under the specified OT1/ST1/ST2 conditions.
10. What should be verified before ordering this power module?
The ET 200SP station configuration, required C0 BaseUnit, 24 V DC supply, output-current requirements, PROFIsafe configuration, safety level, and applicable Siemens documentation should be verified before installation.
