Siemens 6AG2136-6RA00-1BF0 SIPLUS ET 200SP F-RQ Safety Relay Output Module
Siemens 6AG2136-6RA00-1BF0 SIPLUS ET 200SP F-RQ Safety Relay Output Module
0.0
Points
Brand:Siemens Item No.: 6AG2136-6RA00-1BF0 Product Origin: Germany Product Dimensions:5.80 × 2.00 × 7.30 cm Product Weight:0.056 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2136-6RA00-1BF0 is a SIPLUS ET 200SP F-RQ fail-safe relay output module designed for safety-related switching applications. It provides one relay output with two normally open contacts and supports 24 V DC as well as 24–230 V AC load voltages, with a specified total output current of 5 A.
Based on the 6ES7136-6RA00-0BF0 design, the SIPLUS version adds conformal coating and an extended environmental range for demanding industrial and railway applications. When correctly integrated with an appropriate fail-safe F-DQ module, it can support safety applications up to PL e / SIL 3.
Technical Specifications
Parameter
Specification
Brand
Siemens
Article Number
6AG2136-6RA00-1BF0
Product Family
SIPLUS extreme RAIL digital F-output module relay
Product Type
F-RQ 1×24 V DC / 24–230 V AC / 5 A
Based On
6ES7136-6RA00-0BF0
Overall Width
20 mm
Relay Outputs
1
Relay Contacts
2 normally open contacts
Rated Relay Coil Voltage
24 V DC
Load Voltage
24 V DC and 24–230 V AC
Maximum Summation Output Current
5 A
Safety Capability
Up to PL e / SIL 3 when correctly controlled by F-DQ
Suitable BaseUnit
BU type F0
Conformal Coating
Yes
Operating Temperature
-30 to +60 °C
Short-Duration Temperature
+70 °C for 10 minutes under OT1 conditions
Dimensions (L × W × H)
5.80 × 2.00 × 7.30 cm
Weight
Approx. 0.056 kg
Recommended Companion Models
Model
Product Name
6AG2136-6DB00-1CA0
SIPLUS ET 200SP F-DQ 4×24 V DC / 2 A Safety Digital Output Module
6AG2136-6PA00-1BC0
SIPLUS ET 200SP F-PM-E 24 V DC / 8 A Fail-Safe Power Module
6AG2193-6BP20-4BF0
SIPLUS ET 200SP BU20-P8+A4+0B TX RAIL BaseUnit
6AG2136-6BA00-1CA0
SIPLUS ET 200SP F-DI 8×24 V DC Safety Digital Input Module
Frequently Selected Alternatives
Model
Product Name
6ES7136-6RA00-0BF0
SIMATIC ET 200SP F-RQ 1×24 V DC / 24–230 V AC / 5 A Relay Output Module
6AG2136-6DB00-1CA0
SIPLUS ET 200SP F-DQ 4×24 V DC / 2 A Safety Digital Output Module
6AG2136-6DC00-1CA0
SIPLUS ET 200SP F-DQ 8×24 V DC / 0.5 A Safety Digital Output Module
6AG2136-6PA00-1BC0
SIPLUS ET 200SP F-PM-E 24 V DC / 8 A Fail-Safe Power Module
Where It Fits in Industrial Applications
• Designed for fail-safe relay output switching in Siemens SIPLUS ET 200SP automation and safety systems.
• Provides one relay output with two normally open contacts for switching 24 V DC or 24–230 V AC loads.
• Suitable for safety applications where the relay output is controlled by an appropriate fail-safe digital output module.
• Designed for demanding railway and industrial environments with conformal coating and an extended operating temperature range.
Key Strengths at a Glance
• Based on the SIMATIC ET 200SP F-RQ 1×24 V DC / 24–230 V AC / 5 A relay output module.
• Supports a maximum summed output current of 5 A for the relay output.
• Provides two normally open relay contacts for flexible safety-related load switching.
• Supports applications up to PL e / SIL 3 when correctly controlled through an appropriate F-DQ module.
6AG2136-6RA00-1BF0 is a SIPLUS ET 200SP F-RQ fail-safe relay output module based on the standard 6ES7136-6RA00-0BF0 module.
2. How many relay outputs does the module provide?
The module provides one relay output with two normally open contacts.
3. What load voltage does 6AG2136-6RA00-1BF0 support?
The relay output supports load voltages of 24 V DC and 24–230 V AC.
4. What is the maximum output current?
The specified summation output current is 5 A, with the switching capacity dependent on the applicable load conditions.
5. Can this module be used in safety applications?
Yes. The module is designed as a fail-safe relay output module and can be used up to PL e / SIL 3 when controlled through an appropriate fail-safe digital output.
6. What type of BaseUnit is required?
The module uses a compatible ET 200SP BaseUnit of type F0. Siemens identifies 6AG2193-6BP20-4BF0 as a suitable SIPLUS RAIL BaseUnit for this configuration.
7. What is the operating temperature range?
The specified operating range is -30 to +60 °C, with OT1 allowing operation at +70 °C for 10 minutes under the applicable conditions.
8. Does the module have conformal coating?
Yes. The SIPLUS version includes conformal coating intended to improve protection in demanding environmental conditions.
9. Is 6AG2136-6RA00-1BF0 suitable for railway applications?
Yes. The SIPLUS extreme RAIL version is designed for railway applications and is associated with relevant railway standards and approvals.
10. What should be verified before installation?
The ET 200SP configuration, compatible F0 BaseUnit, fail-safe controller or F-DQ module, load voltage, load current, and applicable safety requirements should be verified before installation.
