Siemens 6AG2137-6AA00-1BA0 SIPLUS ET 200SP CM PTP Serial Communication Module
Siemens 6AG2137-6AA00-1BA0 SIPLUS ET 200SP CM PTP Serial Communication Module
0.0
Points
Brand:Siemens Item No.: 6AG2137-6AA00-1BA0 Product Origin: Germany Product Dimensions:7.80 × 2.30 × 6.40 cm Product Weight:0.042 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2137-6AA00-1BA0 is a SIPLUS ET 200SP CM PTP T1 RAIL serial communication module designed for industrial serial data exchange. Based on the 6ES7137-6AA00-0BA0 platform, it supports RS-232, RS-422, and RS-485 interfaces together with Freeport, 3964(R), USS, and MODBUS RTU master/slave communication.
The module operates from a 24 V DC supply and supports communication speeds up to 115.2 kbit/s. Its conformal-coated SIPLUS construction is intended for demanding industrial environments. Siemens lists 6AG2137-6AA01-4BA0 as the successor to this discontinued product.
Technical Specifications
Parameter
Specification
Brand
Siemens
Article Number
6AG2137-6AA00-1BA0
Product Family
SIPLUS ET 200SP
Product Type
CM PTP T1 RAIL Serial Communication Module
Based On
6ES7137-6AA00-0BA0
Communication Interfaces
RS-232 / RS-422 / RS-485
Communication Functions
Freeport, 3964(R), USS, MODBUS RTU
MODBUS RTU Operation
Master / Slave
Maximum Communication Speed
115.2 kbit/s
Rated Supply Voltage
24 V DC
Permissible Supply Range
19.2–28.8 V DC
Reverse Polarity Protection
Yes
Rated Current Consumption
Approx. 29 mA
Firmware Update
Supported
I&M Data
I&M0 to I&M3
Compatible BaseUnit
BU type A0
Conformal Coating
Yes
Operating Temperature
-40 to +60 °C
Short-Duration Temperature
+70 °C for 10 minutes under OT2 conditions
Dimensions (L × W × H)
7.80 × 2.30 × 6.40 cm*
Weight
Approx. 0.042 kg
*The published 7.80 × 2.30 × 6.40 cm values are Siemens-listed packaging dimensions rather than a confirmed product-body measurement.
Recommended Companion Models
Model
Product Name
6AG2137-6AA01-4BA0
SIPLUS ET 200SP CM PTP Serial Communication Module, Successor
6AG2137-6BD00-1BA0
SIPLUS ET 200SP CM 4×IO-Link ST T1 RAIL Communication Module
6AG2138-6AA00-1BA0
SIPLUS ET 200SP TM COUNT 1×24 V T1 RAIL Technology Module
6AG2155-6AU00-1CN0
SIPLUS ET 200SP IM 155-6 PN HF T1 RAIL Interface Module
Frequently Selected Alternatives
Model
Product Name
6ES7137-6AA00-0BA0
SIMATIC ET 200SP CM PtP Serial Communication Module
6AG2137-6AA01-4BA0
SIPLUS ET 200SP CM PTP Serial Communication Module, Successor
6AG2137-6BD00-1BA0
SIPLUS ET 200SP CM 4×IO-Link ST T1 RAIL Communication Module
6AG1800-3BA00-7AA0
SIPLUS SINAUT ST7 TIM 3V-IE Communication Module
Where It Fits in Industrial Applications
• Designed for serial communication within Siemens SIPLUS ET 200SP distributed I/O systems.
• Supports RS-232, RS-422, and RS-485 serial interfaces for connecting industrial devices.
• Suitable for Freeport, 3964(R), USS, and MODBUS RTU communication applications.
• Supports MODBUS RTU master and slave operation for integration with compatible field devices and controllers.
Key Strengths at a Glance
• Based on the SIMATIC ET 200SP CM PtP 6ES7137-6AA00-0BA0 communication module.
• Provides flexible serial communication through RS-232, RS-422, and RS-485 interfaces.
• Supports communication speeds up to 115.2 kbit/s.
• Includes conformal coating for enhanced environmental protection in demanding industrial installations.
• Designed for ET 200SP applications requiring compact rail-mounted serial communication.
Technical FAQs
1. What is Siemens 6AG2137-6AA00-1BA0?
6AG2137-6AA00-1BA0 is a SIPLUS ET 200SP CM PTP T1 RAIL serial communication module based on the standard 6ES7137-6AA00-0BA0.
2. Which serial interfaces are supported?
The module supports RS-232, RS-422, and RS-485 serial communication.
3. Which communication protocols are supported?
Supported functions include Freeport, 3964(R), USS, and MODBUS RTU master and slave communication.
4. What is the maximum communication speed?
The module supports communication speeds up to 115.2 kbit/s.
5. What supply voltage does the module require?
The rated supply voltage is 24 V DC, with an allowable range of 19.2 to 28.8 V DC.
6. Which BaseUnit is compatible with this module?
The module is designed for use with an ET 200SP BaseUnit of type A0.
7. Does the module support firmware updates?
Yes. The product documentation identifies firmware update capability for the communication module.
8. What environmental protection does the SIPLUS version provide?
The module has conformal coating and is designed for an extended environmental operating range compared with standard ET 200SP modules.
9. Is 6AG2137-6AA00-1BA0 still a current Siemens product?
No. Siemens identifies this article as a discontinued spare part and lists 6AG2137-6AA01-4BA0 as its successor.
10. What should be checked before replacing this module?
The ET 200SP station configuration, BaseUnit type, serial interface requirements, communication protocol, firmware requirements, and successor-product compatibility should be verified before replacement.
