Siemens 6AG2137-6BD00-1BA0 SIPLUS ET 200SP CM 4xIO-Link ST Communication Module
Siemens 6AG2137-6BD00-1BA0 SIPLUS ET 200SP CM 4xIO-Link ST Communication Module
0.0
Points
Brand:Siemens Item No.:6AG2137-6BD00-1BA0 Product Origin: Germany Product Dimensions:5.80 × 1.50 × 7.30 cm Product Weight:0.030 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2137-6BD00-1BA0 is a SIPLUS ET 200SP CM 4xIO-Link ST T1 RAIL communication module that functions as an IO-Link master for connecting up to four compatible IO-Link devices. It supports IO-Link protocol versions 1.0 and 1.1 and provides COM1, COM2, and COM3 communication rates up to 230.4 kbaud.
Based on the 6ES7137-6BD00-0BA0 platform, the module operates from a 24 V DC supply and provides four simultaneously controllable IO-Link ports. Its conformal-coated SIPLUS construction and extended environmental specifications make it suitable for demanding industrial and railway installations.
+70 °C for 10 minutes under OT2/ST1/ST2 conditions
Dimensions (L × W × H)
5.80 × 1.50 × 7.30 cm
Weight
Approx. 0.030 kg
Recommended Companion Models
Model
Product Name
6AG2137-6AA01-4BA0
SIPLUS ET 200SP CM PTP RAIL Serial Communication Module
6AG2137-6EA00-2BA0
SIPLUS ET 200SP CM CAN RAIL Communication Module
6AG2138-6AA01-1BA0
SIPLUS ET 200SP TM COUNT 1×24 V T1 RAIL Technology Module
6AG2155-6AU01-1CN0
SIPLUS ET 200SP IM 155-6 PN HF RAIL Interface Module
Frequently Selected Alternatives
Model
Product Name
6ES7137-6BD00-0BA0
SIMATIC ET 200SP CM 4xIO-Link ST Communication Module
6AG2137-6AA01-4BA0
SIPLUS ET 200SP CM PTP RAIL Serial Communication Module
6AG2137-6EA00-2BA0
SIPLUS ET 200SP CM CAN RAIL Communication Module
6AG2138-6BA01-2BA0
SIPLUS ET 200SP TM POSINPUT 1 RAIL Technology Module
Where It Fits in Industrial Applications
• Designed as an IO-Link master communication module for Siemens SIPLUS ET 200SP distributed I/O systems.
• Provides four IO-Link ports for connecting compatible IO-Link sensors, actuators, and field devices.
• Supports IO-Link protocol versions 1.0 and 1.1 for flexible device integration.
• Suitable for demanding industrial and railway environments requiring conformal-coated ET 200SP components.
Key Strengths at a Glance
• Based on the SIMATIC ET 200SP CM 4xIO-Link ST module, article 6ES7137-6BD00-0BA0.
• Provides four independently usable IO-Link master ports, with all four ports simultaneously controllable.
• Supports COM1, COM2, and COM3 transmission rates up to 230.4 kbaud.
• Provides 24 V DC supply with a permissible range of 19.2–28.8 V DC, or at least 20.5 V when IO-Link devices are supplied through the master.
• Includes short-circuit protection for the 24 V encoder supply and diagnostic monitoring functions.
Technical FAQs
1. What is Siemens 6AG2137-6BD00-1BA0?
6AG2137-6BD00-1BA0 is a SIPLUS ET 200SP CM 4xIO-Link ST T1 RAIL communication module based on the standard 6ES7137-6BD00-0BA0.
2. How many IO-Link ports does the module provide?
The module provides four IO-Link ports, and all four ports can be operated simultaneously.
3. Which IO-Link protocol versions are supported?
The module supports both IO-Link protocol version 1.0 and version 1.1.
4. What communication speeds are supported?
The IO-Link interface supports COM1 at 4.8 kbaud, COM2 at 38.4 kbaud, and COM3 at 230.4 kbaud.
5. What supply voltage does the module require?
The rated supply voltage is 24 V DC, with a permissible range of 19.2–28.8 V DC. When IO-Link devices are supplied through the master, the supply voltage must be at least 20.5 V.
6. What output current is available for each IO-Link channel?
Each channel provides a rated output current of 700 mA for the associated 24 V device supply.
7. Is the 24 V device supply protected against short circuits?
Yes. The 24 V device supply includes short-circuit protection, with a maximum total output current of 2.1 A.
8. Which BaseUnit is compatible with this module?
The module is designed for use with an ET 200SP BaseUnit of type A0.
9. Is 6AG2137-6BD00-1BA0 suitable for railway applications?
Yes. The SIPLUS extreme RAIL version is designed for demanding railway environments and is associated with railway standards including EN 50155, EN 15121, EN 50124, EN 50125, and EN 45545.
10. What should be verified before installation?
The ET 200SP station configuration, compatible A0 BaseUnit, IO-Link device requirements, supply voltage, port configuration, and applicable environmental conditions should be verified before installation.
