Siemens 6AG2155-5AA01-4AB0 PROFINET Interface Module

Where It Excels in Industrial Use

• Railway automation systems: Provides a robust PROFINET interface for ET 200MP distributed I/O stations used in railway control and monitoring equipment.
• Harsh industrial installations: The conformal-coated SIPLUS construction is suited to environments exposed to temperature variation, condensation, chemically active substances, salt mist, and other demanding conditions.
• Distributed machine control: Connects ET 200MP electronic modules to a higher-level PROFINET IO controller while maintaining a compact and modular station architecture.
• Large distributed I/O stations: Supports up to 12 I/O modules without an additional power supply and up to 30 I/O modules when additional power supplies are installed.
• Redundant network architectures: MRP, Shared Device, and related PROFINET functions make the module suitable for network designs requiring improved availability and flexible controller connectivity.
• Time-critical automation: IRT and isochronous operation provide deterministic communication capabilities for applications requiring tightly synchronized process data exchange.

Key Strengths at a Glance

• Railway-oriented SIPLUS design: Developed from the SIMATIC ET 200MP IM 155-5 PN ST platform with conformal coating and an extended environmental operating range.
• Extended temperature capability: Supports operation from -40 to +70 °C, with short-duration operation up to +85 °C for 10 minutes under the specified ST1/ST2 conditions.
• Integrated two-port switch: Two RJ45 ports simplify PROFINET network connections and allow practical network integration without a separate external switch for basic line configurations.
• Flexible PROFINET communication: Supports PROFINET IO, MRP, Shared Device, IRT, and isochronous operation for demanding distributed automation systems.
• Scalable station architecture: Supports up to 30 ET 200MP I/O modules when additional system power supplies are used.
• Advanced diagnostics: RUN, ERROR, MAINT, and port link/activity indicators provide convenient local status information for commissioning and troubleshooting.
• Engineering flexibility: Supports I&M0 to I&M3 identification and maintenance data, helping simplify device identification and service management.

Technical FAQs

What is the function of the Siemens 6AG2155-5AA01-4AB0?

The 6AG2155-5AA01-4AB0 is a SIPLUS ET 200MP IM 155-5 PN ST TX RAIL PROFINET IO interface module. It connects ET 200MP electronic modules to a higher-level PROFINET IO controller and manages communication with the distributed I/O station.

Which base module is the 6AG2155-5AA01-4AB0 derived from?

The module is based on the SIMATIC ET 200MP IM 155-5 PN ST with article number 6ES7155-5AA01-0AB0 and adds the SIPLUS RAIL design characteristics required for demanding environmental applications.

How many PROFINET ports does the module provide?

The module provides one PROFINET interface with two RJ45 ports through an integrated two-port Ethernet switch.

Does the module support PROFINET IRT?

Yes. The interface supports PROFINET IRT with a minimum communication cycle of 250 μs, making it suitable for applications that require predictable and synchronized data exchange.

Can the interface module operate in an isochronous system?

Yes. Isochronous operation is supported, allowing suitable ET 200MP configurations to synchronize process data acquisition and output with the automation system cycle.

Does the module support PROFINET Media Redundancy Protocol?

Yes. The module supports MRP, allowing it to participate in suitable PROFINET ring topologies designed for media redundancy.

Can multiple IO controllers access the same ET 200MP station?

Yes. Shared Device functionality allows compatible configurations to make selected I/O data available to multiple IO controllers, with support for up to four IO controllers.

How many I/O modules can be connected to the station?

The station can accommodate up to 12 I/O modules without an additional power supply and up to 30 I/O modules when additional system power supplies are installed.

Which engineering environment is used to configure the interface module?

The module is configured within the Siemens STEP 7 engineering environment in TIA Portal, using the appropriate hardware configuration and device description for the ET 200MP station.

What diagnostic information can be obtained from the module?

The interface provides local LED indications for RUN, ERROR, MAINT, and PROFINET port link/activity status, while the PROFINET system can provide additional diagnostic and maintenance information.
