Brand:Siemens Item No.:6AG2193-6AF00-4AA0 Product Origin: Germany Product Dimensions:65 × 77 × 23 mm Product Weight:53 g Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2193-6AF00-4AA0 is a SIPLUS ET 200SP BA 2xFC TX RAIL BusAdapter developed for reliable PROFINET connectivity in demanding industrial and railway applications. Based on the standard 6ES7193-6AF00-0AA0 BA 2xFC architecture, it combines Siemens FastConnect copper connectivity with the environmental protection characteristics of the SIPLUS RAIL platform.
Its two FastConnect connections provide a practical solution for PROFINET network integration where field-terminated copper cabling is preferred. The adapter supports up to 100 m of copper cable and provides a two-port switched connection, making it well suited to distributed ET 200SP architectures.
The TX RAIL design adds conformal coating and an extended temperature capability, supporting operation from -40 to +70 °C with short-duration operation up to +85 °C for 10 minutes under the specified conditions. This combination makes the adapter particularly attractive for railway vehicles, transportation infrastructure, and industrial systems exposed to challenging environmental conditions.
For maintenance teams and system integrators, the modular BusAdapter approach is another practical advantage. The communication interface can be selected according to the required connection technology, allowing compatible ET 200SP equipment to be adapted to different network installation requirements without changing the complete interface module.
Technical Specifications
Specification
Details
Product Family
SIPLUS ET 200SP RAIL
Product Type
BA 2xFC TX RAIL
Module Type
PROFINET BusAdapter Module
Article Number
6AG2193-6AF00-4AA0
Base Model
6ES7193-6AF00-0AA0
PROFINET Interfaces
1
Port Configuration
2-port switch
Connection Technology
FastConnect
FastConnect Connections
2
Cable Type
Copper Industrial Ethernet / PROFINET
Maximum Copper Cable Length
100 m
Transmission Rate
100 Mbit/s full duplex
Conformal Coating
Yes
Railway Application
Yes
Operating Temperature
-40 to +70 °C
Short-Duration Temperature
Up to +85 °C for 10 minutes
Environmental Classification
OT4 / ST1 / ST2
Railway Standards
EN 50121-3-2, EN 50121-4, EN 50124-1, EN 50125-1, EN 50125-2, EN 50125-3, EN 50155, EN 61373, EN 45545-2
Mounting Concept
Plug-in BusAdapter for compatible ET 200SP devices
Dimensions
Approx. 65 × 77 × 23 mm
Weight
Approx. 53 g
The published technical data identifies the underlying BA 2xFC as a two-port FastConnect PROFINET BusAdapter with 100 m maximum copper cable length, while the SIPLUS TX RAIL version is specified with conformal coating and the -40 to +70 °C operating range. Siemens documentation lists the base BA 2xFC at approximately 53 g and dimensions of 20 × 69.5 × 59 mm; external product listings may express the overall BusAdapter envelope differently depending on measurement convention.
Recommended Companion Models
Model
Product Name
6AG2155-6AU01-4CN0
SIPLUS ET 200SP IM155-6PN HF TX RAIL PROFINET Interface Module
6AG2155-6AA01-4BN0
SIPLUS ET 200SP IM155-6PN ST BA TX RAIL PROFINET Interface Module
6AG2155-6AU01-4BN0
SIPLUS ET 200SP IM155-6PN ST TX RAIL PROFINET Interface Module
6AG2155-6AU01-1CN0
SIPLUS ET 200SP IM155-6PN HF T1 RAIL PROFINET Interface Module
These SIPLUS ET 200SP interface modules are documented as RAIL variants designed for compatible BusAdapter-based configurations.
Frequently Selected Alternatives
Model
Product Name
6AG2193-6AR00-4AA0
SIPLUS ET 200SP BA 2xRJ45 TX RAIL BusAdapter
6AG2193-6AM00-4AA0
SIPLUS ET 200SP BA 2xM12 RAIL BusAdapter
6AG1193-6AF00-7AA0
SIPLUS ET 200SP BA 2xFC PN BusAdapter
6AG1193-6AG00-2AA0
SIPLUS ET 200SP BA 2xLC BusAdapter
The listed alternatives represent different ET 200SP connection technologies, including RJ45, M12, FastConnect, and LC optical interfaces.
Where It Excels in Industrial Use
Railway PROFINET installations: Designed for SIPLUS ET 200SP RAIL systems where reliable Ethernet connectivity is required under demanding railway operating conditions.
High-vibration automation equipment: The FastConnect interface provides a robust copper connection approach for machines and installations subject to increased mechanical and EMC loads.
Industrial Ethernet field connections: Provides two FastConnect connections for PROFINET, making it practical for line and network-segment installations where direct field cable termination is preferred.
Harsh environmental applications: The conformal-coated design is intended for environments with increased exposure to environmental substances and supports an operating range of -40 to +70 °C.
Compact distributed I/O systems: Its BusAdapter design integrates directly with compatible SIPLUS ET 200SP interface modules, helping maintain a compact and modular network architecture.
Key Strengths at a Glance
Dual FastConnect ports: Provides two FastConnect connections for PROFINET cabling and supports a practical two-port switched network connection.
Railway-ready construction: Developed as a SIPLUS ET 200SP RAIL BusAdapter with conformal coating for demanding environmental conditions.
Extended temperature capability: Supports operation from -40 to +70 °C, with short-duration operation up to +85 °C for 10 minutes under the specified railway conditions.
100 m copper cable reach: Supports copper PROFINET cable lengths of up to 100 m, providing useful flexibility for distributed network layouts.
Tool-assisted FastConnect termination: The FastConnect design supports efficient field assembly of compatible Industrial Ethernet cables and can simplify installation work.
Replaceable connection technology: The BusAdapter concept allows the connection interface to be changed independently of the compatible ET 200SP device, which can simplify maintenance and network adaptation.
Strong railway application profile: The product documentation identifies railway-related requirements including EN 50121-3-2, EN 50121-4, EN 50124-1, EN 50125-1, EN 50125-2, EN 50125-3, EN 50155, EN 61373, and EN 45545-2.
Technical FAQs
What is the primary function of the Siemens 6AG2193-6AF00-4AA0?
The 6AG2193-6AF00-4AA0 is a SIPLUS ET 200SP BA 2xFC TX RAIL BusAdapter that provides a FastConnect-based PROFINET connection for compatible ET 200SP RAIL devices.
How many PROFINET connections are available on the BusAdapter?
The BusAdapter provides two FastConnect connections associated with one PROFINET interface and an integrated two-port switch.
What type of cable connection does the BA 2xFC use?
The BA 2xFC uses Siemens FastConnect technology for copper Industrial Ethernet cabling, allowing compatible PROFINET cables to be terminated directly at the adapter.
What is the maximum supported copper cable length?
The specified maximum copper conductor length is 100 m for the PROFINET connection.
Can the BusAdapter be used with standard ET 200SP interface modules?
The underlying BA 2xFC design is based on the SIMATIC ET 200SP 6ES7193-6AF00-0AA0 BusAdapter and is intended for compatible devices equipped with the corresponding BusAdapter interface.
Why is FastConnect useful in industrial Ethernet installations?
FastConnect allows compatible Industrial Ethernet cables to be prepared and terminated efficiently, which can reduce installation effort and provide a consistent connection method for distributed PROFINET systems.
Does the module support PROFINET IO?
Yes. The BA 2xFC provides the physical PROFINET connection required by compatible ET 200SP interface devices and uses two switched FastConnect ports for network connectivity.
What environmental protection distinguishes the TX RAIL version?
The SIPLUS TX RAIL version uses conformal coating and is designed for increased exposure to environmental substances, with a specified operating range of -40 to +70 °C and short-duration operation up to +85 °C for 10 minutes.
Is the BusAdapter suitable for applications with increased mechanical or EMC loads?
Yes. The SIPLUS RAIL documentation specifically identifies the BA 2xFC as a suitable connection option for applications with increased mechanical and EMC loading.
Can the BusAdapter be replaced without replacing the complete compatible ET 200SP device?
The modular BusAdapter concept allows the connection technology to be changed or replaced independently on compatible ET 200SP devices, which can simplify service work and future network adaptations.
