Siemens 6AG2510-1DJ01-1AB0 SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
Siemens 6AG2510-1DJ01-1AB0 SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
0.0
Points
Brand:Siemens Item No.:6AG2510-1DJ01-1AB0 Product Origin: Germany Product Dimensions:100 × 117 × 75 mm Product Weight:310 g Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2510-1DJ01-1AB0 SIPLUS ET 200SP CPU 1510SP-1 PN RAIL is a compact central processing unit for ET 200SP automation systems. It combines the distributed architecture of the ET 200SP platform with PROFINET IRT communication and enhanced environmental characteristics for railway and other demanding industrial installations.
The CPU provides 100 KB of work memory for the user program and 750 KB for data, giving it a practical memory configuration for a wide range of distributed automation tasks. Its integrated PROFINET interface incorporates a 3-port switch and supports IRT communication, making the controller suitable for systems where deterministic network behavior and synchronized operation are required.
Programming and configuration are carried out in the TIA Portal environment using STEP 7. The CPU supports established PLC programming languages including LAD, FBD, STL, SCL, and GRAPH, allowing it to fit naturally into Siemens-based automation projects.
As a SIPLUS RAIL product, this CPU is built for more demanding environmental conditions than standard automation hardware. Conformal coating and an extended temperature capability help protect the electronics in installations where moisture, corrosive substances, temperature variation, vibration, or other environmental stresses may be present.
The compact ET 200SP design also makes the CPU well suited to decentralized control cabinets. A SIMATIC Memory Card is required, while BusAdapters provide the physical interface for the PROFINET ports, allowing the CPU to be integrated into a modular ET 200SP station.
Technical Specifications
Specification
Details
Product Type
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
Article Number
6AG2510-1DJ01-1AB0
Base Product
6ES7510-1DJ01-0AB0
CPU Type
CPU 1510SP-1 PN
System
SIMATIC ET 200SP
Controller Type
Central Processing Unit
Program Work Memory
100 KB
Data Work Memory
750 KB
PROFINET Interface
1 interface with 3-port switch
PROFINET Function
PROFINET IRT
Isochronous Mode
Supported
Typical Bit Performance
72 ns
Supply Voltage
24 V DC
Permissible Supply Range
19.2 ... 28.8 V DC
Current Consumption
Approx. 0.6 A
Engineering Software
STEP 7 / TIA Portal
Programming Languages
LAD, FBD, STL, SCL, GRAPH
SIMATIC Memory Card
Required
BusAdapter
Required for PROFINET ports
Hot Swapping
Supported
Conformal Coating
Yes
Operating Temperature
-40 ... +60 °C
Short-Duration Temperature
+70 °C for 10 minutes
Installation Altitude
Up to 5,000 m with applicable restrictions above 2,000 m
Protection Rating
IP20
Dimensions
100 × 117 × 75 mm
Weight
Approx. 310 g
Recommended Companion Models
Model
Product Name
6AG2512-1DK01-1AB0
SIPLUS ET 200SP CPU 1512SP-1 PN RAIL
6AG2510-1DJ01-4AB0
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
6AG2511-1AK02-1AB0
SIPLUS S7-1500 CPU 1511-1 PN T1 RAIL
6AG2521-1BH00-4AB0
SIPLUS S7-1500 DI 16x24VDC HF TX RAIL
Frequently Selected Alternatives
Model
Product Name
6AG2510-1DK03-1AB0
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
6AG2512-1DK01-4AB0
SIPLUS ET 200SP CPU 1512SP-1 PN RAIL
6AG2511-1AL03-1AB0
SIPLUS S7-1500 CPU 1511-1 PN RAIL
6AG2510-1SJ01-1AB0
SIPLUS ET 200SP CPU 1510SP F-1 PN RAIL
Where It Excels in Industrial Use
Distributed automation systems requiring a compact ET 200SP central processing unit.
Railway and transportation control applications exposed to demanding environmental conditions.
Machine and plant automation where PROFINET IRT communication is required.
Decentralized control cabinets with limited installation space.
Production systems using ET 200SP distributed I/O and modular signal processing.
Motion and synchronized automation applications that benefit from deterministic PROFINET communication.
Industrial installations where conformal-coated electronics and an extended temperature range are important.
Key Strengths at a Glance
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL central processing unit.
Based on the SIMATIC ET 200SP CPU 1510SP-1 PN platform.
100 KB work memory for program data and 750 KB for data.
Integrated PROFINET interface with a 3-port switch.
Supports PROFINET IRT and isochronous operation.
Typical bit performance of 72 ns for Boolean operations.
STEP 7 programming through the TIA Portal engineering environment.
SIMATIC Memory Card required for operation.
BusAdapters are required for the PROFINET ports.
Conformal coating and railway-oriented environmental qualification support demanding installations.
Technical FAQs
1. What is the main function of the Siemens 6AG2510-1DJ01-1AB0?
The 6AG2510-1DJ01-1AB0 is a SIPLUS ET 200SP CPU 1510SP-1 PN RAIL central processing unit designed to control ET 200SP automation stations and communicate with distributed devices through PROFINET.
2. What type of PROFINET communication does the CPU support?
The CPU provides PROFINET IRT communication through its integrated interface and supports deterministic, synchronized communication for applications where precise timing between automation devices is important.
3. How much work memory is available in the CPU?
The CPU provides 100 KB of integrated work memory for the user program and 750 KB of integrated work memory for data.
4. Does the CPU support isochronous operation?
Yes. The CPU supports isochronous operation over PROFINET. This can be used for applications requiring synchronized acquisition and processing of distributed signals and deterministic cyclic communication.
5. Which engineering software is used to program the CPU?
The CPU is engineered and programmed with STEP 7 in the TIA Portal environment. The exact supported TIA Portal version depends on the configured hardware and firmware combination.
6. Is a memory card required for the 6AG2510-1DJ01-1AB0?
Yes. A SIMATIC Memory Card is required for operation. The card is used for storing the user program and associated CPU data required by the controller.
7. How are the PROFINET ports connected to the CPU?
The CPU provides a PROFINET interface with a 3-port switch. BusAdapters are required for the PROFINET ports, allowing the physical connection arrangement to be adapted to the selected ET 200SP installation.
8. What supply voltage does the CPU require?
The CPU operates from a nominal 24 V DC supply. The specified permissible supply range is 19.2 to 28.8 V DC.
9. Can the CPU support hot swapping in an ET 200SP station?
Yes. The CPU supports module replacement functions within the ET 200SP architecture, including multi-hot-swapping capabilities where the configured station and supported modules permit this operating mode.
10. What makes the SIPLUS RAIL version suitable for demanding environments?
The 6AG2510-1DJ01-1AB0 uses conformal coating and is designed for railway-oriented environmental requirements. Its specified operating range is -40 to +60 °C, with short-duration operation up to +70 °C for 10 minutes under the applicable temperature conditions.
