Siemens 6AG2510-1DJ01-4AB0 SIPLUS ET 200SP CPU 1510SP-1 PN RAIL Central Processing Unit
Siemens 6AG2510-1DJ01-4AB0 SIPLUS ET 200SP CPU 1510SP-1 PN RAIL Central Processing Unit
0.0
Points
Brand:Siemens Item No.: 6AG2510-1DJ01-4AB0 Product Origin: Germany Product Dimensions:100 × 117 × 75 mm Product Weight:470 g Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2510-1DJ01-4AB0 SIPLUS ET 200SP CPU 1510SP-1 PN RAIL is a compact central processing unit for distributed ET 200SP automation systems. Based on the CPU 1510SP-1 PN platform, it combines PLC control, integrated PROFINET communication, and ruggedized SIPLUS environmental protection in a space-efficient design.
With 100 KB of work memory for the program and 750 KB for data, the CPU provides a practical processing platform for distributed machine and infrastructure automation. Its integrated PROFINET interface includes a 3-port switch and supports PROFINET IRT, enabling deterministic communication and synchronized operation for applications where timing consistency is important.
The CPU is powered from a 24 V DC supply and supports a wide permissible voltage range of 19.2 to 28.8 V DC. Configuration and programming are performed through STEP 7 in TIA Portal, while the required SIMATIC Memory Card provides the load-memory medium for the controller.
The SIPLUS RAIL construction is intended for demanding railway and industrial environments. Conformal coating and the extended temperature specification help the electronics withstand conditions beyond those normally associated with standard indoor automation installations. Multi-hot-swapping support also simplifies maintenance of compatible ET 200SP configurations.
The 6AG2510-1DJ01-4AB0 is a spare-part version of the CPU 1510SP-1 PN RAIL and has been superseded by the 6AG2510-1DK03-4AB0, which provides a newer CPU generation with increased memory and processing performance.
Technical Specifications
Specification
Details
Product Type
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
Article Number
6AG2510-1DJ01-4AB0
Base Product
6ES7510-1DJ01-0AB0
CPU Type
CPU 1510SP-1 PN
System
SIMATIC ET 200SP
Module Type
Central Processing Unit
Program Work Memory
100 KB
Data Work Memory
750 KB
Load Memory
SIMATIC Memory Card, up to 32 GB
PROFINET Interface
1 × PROFINET with 3-port switch
PROFINET Function
PROFINET IRT
Isochronous Mode
Supported
Typical Bit Performance
72 ns
Supply Voltage
24 V DC
Permissible Supply Range
19.2 ... 28.8 V DC
Rated Current Consumption
0.6 A
Maximum Current Consumption
0.9 A
Inrush Current
Max. 4.7 A
Power Loss
Approx. 5.6 W
Backplane Bus Power
Approx. 8.75 W
Voltage-Failure Buffering
Approx. 5 ms
Engineering Software
STEP 7 / TIA Portal
Configuration Control
Supported via data record
Hot Swapping
Multi-hot swapping supported
Conformal Coating
Yes
Operating Temperature
-40 ... +70 °C
Short-Duration Temperature
+85 °C for 10 minutes
Maximum Installation Altitude
5,000 m with applicable restrictions
Protection Rating
IP20
Mounting
ET 200SP station mounting
Dimensions
100 × 117 × 75 mm
Weight
Approx. 470 g
Product Status
Spare part / discontinued article
Successor
6AG2510-1DK03-4AB0
Recommended Companion Models
Model
Product Name
6AG2510-1DK03-4AB0
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
6AG2512-1DK01-4AB0
SIPLUS ET 200SP CPU 1512SP-1 PN RAIL
6AG2511-1AK02-4AB0
SIPLUS S7-1500 CPU 1511-1 PN TX RAIL
6AG2521-1BH00-4AB0
SIPLUS S7-1500 DI 16x24VDC HF TX RAIL
Frequently Selected Alternatives
Model
Product Name
6AG2510-1DJ01-1AB0
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL
6AG2511-1AL03-4AB0
SIPLUS S7-1500 CPU 1511-1 PN RAIL
6AG2512-1DM03-4AB0
SIPLUS ET 200SP CPU 1512SP-1 PN RAIL
6AG2510-1SJ01-1AB0
SIPLUS ET 200SP CPU 1510 F-1 PN RAIL
Where It Excels in Industrial Use
Distributed railway automation systems built around the SIMATIC ET 200SP platform.
Decentralized control cabinets where compact PLC architecture and PROFINET communication are required.
Railway vehicles and infrastructure exposed to extended temperature ranges and demanding environmental conditions.
Machine and plant automation requiring deterministic PROFINET IRT communication.
Synchronized automation applications using isochronous PROFINET operation.
Industrial control systems that benefit from modular ET 200SP I/O expansion.
Existing installations requiring a rugged SIPLUS RAIL CPU as a replacement or spare part.
Key Strengths at a Glance
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL design with conformal coating.
100 KB integrated work memory for the user program and 750 KB for data.
Integrated PROFINET interface with a 3-port switch.
Supports PROFINET IRT and isochronous operation.
Typical bit processing performance of 72 ns.
24 V DC supply with an allowable range of 19.2 to 28.8 V DC.
Multi-hot-swapping capability for supported ET 200SP configurations.
SIMATIC Memory Card required for program and load-memory functions.
No pluggable BusAdapter is included with this article number.
Designed for railway applications with operation from -40 to +70 °C and short-duration exposure up to +85 °C.
Technical FAQs
1. What is the Siemens 6AG2510-1DJ01-4AB0 used for?
The 6AG2510-1DJ01-4AB0 is a SIPLUS ET 200SP CPU 1510SP-1 PN RAIL central processing unit used to control ET 200SP automation stations and exchange data with distributed devices through PROFINET.
2. What PROFINET capabilities are integrated into this CPU?
The CPU provides a PROFINET interface with a 3-port switch and supports PROFINET IRT. This allows deterministic communication and synchronized operation for automation applications with demanding timing requirements.
3. How much memory does the CPU provide?
The CPU has 100 KB of integrated work memory for the program and 750 KB of integrated work memory for data. A SIMATIC Memory Card is required for load memory and operation.
4. Does the CPU support isochronous operation?
Yes. Isochronous operation is supported over PROFINET. For the specified configuration, synchronized operation can be used with a minimum OB 6x cycle of 625 µs.
5. What is the typical bit processing performance of the CPU?
The CPU has a typical bit processing time of approximately 72 ns, making it suitable for fast sequence control and general PLC applications within its performance class.
6. What programming environment is used with the 6AG2510-1DJ01-4AB0?
The CPU is configured and programmed using STEP 7 in the TIA Portal engineering environment. The supported TIA Portal version depends on the corresponding hardware and firmware configuration.
7. What supply voltage is required by the CPU?
The CPU uses a nominal 24 V DC supply. The permissible supply range is 19.2 to 28.8 V DC, and reverse-polarity protection is provided.
8. Can ET 200SP modules be replaced while the station is operating?
Yes. The CPU supports multi-hot-swapping functionality for compatible ET 200SP configurations, allowing supported modules to be replaced during operation without necessarily shutting down the complete station.
9. Is a BusAdapter supplied with the 6AG2510-1DJ01-4AB0?
No. This particular article number is specified without a pluggable BusAdapter. The CPU itself provides the integrated PROFINET interface and 3-port switch architecture.
10. What environmental conditions are supported by the SIPLUS RAIL CPU?
The CPU uses conformal coating and is designed for railway applications. Its specified operating temperature is -40 to +70 °C, with short-duration operation up to +85 °C for 10 minutes under the applicable environmental conditions.
