Siemens 6AG2510-1SJ01-1AB0 SIPLUS ET 200SP CPU 1510 F-1 PN RAIL Fail-Safe CPU
Siemens 6AG2510-1SJ01-1AB0 SIPLUS ET 200SP CPU 1510 F-1 PN RAIL Fail-Safe CPU
0.0
Points
Brand:Siemens Item No.:6AG2510-1SJ01-1AB0 Product Origin: Germany Product Dimensions:100 × 117 × 75 mm Product Weight:310 g Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG2510-1SJ01-1AB0 SIPLUS ET 200SP CPU 1510 F-1 PN RAIL is a fail-safe central processing unit for ET 200SP automation systems. It combines standard PLC control with integrated safety processing, allowing a single compact controller to handle conventional automation functions and safety-related tasks.
The CPU provides 150 KB of work memory for the program and 750 KB for data. Its integrated PROFINET IO IRT interface includes a three-port switch and supports deterministic communication, isochronous operation, and distributed automation architectures. Up to 64 PROFINET IO devices can be connected under the applicable configuration limits.
Safety communication is handled through PROFIsafe, with support for versions V2.4 and V2.6. This allows compatible fail-safe I/O devices to exchange safety-related information with the CPU while using the existing PROFINET network infrastructure. The controller can achieve safety performance up to SIL 3 and PL e when applied within an appropriately designed and validated safety system.
Beyond PLC and safety control, the CPU supports motion-control functions, including speed-controlled and positioning axes, external encoders, and synchronized axis applications. It can also operate as a PROFINET I-Device, making it suitable for distributed intelligence architectures in which local processing is performed close to the machine or process.
The SIPLUS RAIL design adds conformal coating and railway-specific environmental capabilities. Qualification for demanding rail applications, together with resistance to condensation and challenging environmental influences, makes the CPU suitable for transportation systems and other installations where standard automation hardware may require additional environmental protection.
Technical Specifications
Specification
Details
Product Type
SIPLUS ET 200SP CPU 1510 F-1 PN RAIL
Article Number
6AG2510-1SJ01-1AB0
Base Product
6ES7510-1SJ01-0AB0
CPU Type
CPU 1510SP F-1 PN
Module Type
Fail-Safe Central Processing Unit
System
SIMATIC ET 200SP
Work Memory for Program
150 KB
Work Memory for Data
750 KB
Load Memory
SIMATIC Memory Card, max. 32 GB
PROFINET Interface
1 × PROFINET IO IRT with 3-port switch
PROFINET Ports
1 integrated RJ45 port + 2 via BusAdapter
PROFINET IO Controller
Yes
Maximum PROFINET IO Devices
64
IRT Devices
Up to 64
PROFINET I-Device
Supported
Shared I-Device
Supported for up to 4 controllers
Isochronous Mode
Supported
PROFIsafe
V2.4 / V2.6
Fail-Safe Performance
Up to SIL 3 / PL e, depending on system configuration
Railway Safety Classification
SIL 2 according to EN 50126 / EN 50128 / EN 50129
Typical Bit Operation Time
72 ns
Typical Word Operation Time
86 ns
Supply Voltage
24 V DC
Permissible Supply Range
19.2 ... 28.8 V DC
Rated Current Consumption
0.6 A
Maximum Inrush Current
4.7 A
Power Loss
Approx. 5.6 W
Backplane Bus Power
Approx. 8.75 W
Voltage-Failure Buffering
Approx. 5 ms
Engineering Software
STEP 7 / TIA Portal
Safety Engineering
STEP 7 Safety Advanced
SIMATIC Memory Card
Required
BusAdapter
Required for PROFINET ports 1 and 2
Maximum ET 200SP Modules
64
Maximum ET 200AL Modules
16
Conformal Coating
Yes
Horizontal Operating Temperature
-25 ... +60 °C
Short-Duration Temperature
+70 °C for 10 minutes
Vertical Operating Temperature
-25 ... +50 °C
Maximum Installation Altitude
2,000 m
Protection Rating
IP20
Dimensions
100 × 117 × 75 mm
Weight
Approx. 310 g
Recommended Companion Models
Model
Product Name
6AG2512-1SK01-1AB0
SIPLUS ET 200SP CPU 1512 F-1 PN RAIL Fail-Safe CPU
6AG2510-1DJ01-1AB0
SIPLUS ET 200SP CPU 1510SP-1 PN RAIL CPU
6AG2512-1DK01-1AB0
SIPLUS ET 200SP CPU 1512SP-1 PN RAIL CPU
6AG2136-6BA00-1CA0
SIPLUS ET 200SP F-DI 8x24VDC HF Fail-Safe Digital Input Module
Frequently Selected Alternatives
Model
Product Name
6AG1510-1SJ01-2AB0
SIPLUS ET 200SP CPU 1510SP F-1 PN Fail-Safe CPU
6AG2512-1SK01-4AB0
SIPLUS ET 200SP CPU 1512 F-1 PN RAIL Fail-Safe CPU
6AG2510-1SK03-1AB0
SIPLUS ET 200SP CPU 1510 F-1 PN RAIL Fail-Safe CPU
6AG2515-2FM02-4AB0
SIPLUS S7-1500 CPU 1515F-2 PN RAIL Fail-Safe CPU
Where It Excels in Industrial Use
Railway automation systems requiring both standard PLC control and fail-safe processing.
ET 200SP-based control stations for transportation and rail infrastructure.
Machine and process applications where PROFIsafe communication is required for safety functions.
Distributed control architectures using PROFINET IO and PROFINET IRT.
Applications requiring synchronized acquisition, processing, and output of safety-related signals.
Compact control cabinets where standard and safety automation need to share the same CPU platform.
Industrial environments exposed to condensation, vibration, temperature variation, and other demanding conditions.
Key Strengths at a Glance
SIPLUS ET 200SP CPU 1510 F-1 PN RAIL for combined standard and fail-safe automation.
150 KB work memory for the program and 750 KB for data.
Integrated PROFINET IO IRT interface with a 3-port switch.
Supports PROFIsafe V2.4 and V2.6 for safety-related communication.
Supports PROFINET IO controller operation for up to 64 IO devices.
Supports PROFINET I-Device and shared I-Device functionality.
Provides integrated motion-control functions for speed-controlled and positioning axes.
Fail-safe performance up to SIL 3 and PL e, subject to the complete safety system configuration.
Conformal-coated RAIL construction with railway-oriented environmental and safety qualification.
Technical FAQs
1. What is the main function of the Siemens 6AG2510-1SJ01-1AB0?
The 6AG2510-1SJ01-1AB0 is a SIPLUS ET 200SP CPU 1510 F-1 PN RAIL fail-safe central processing unit designed to execute both standard PLC programs and safety-related programs within an ET 200SP automation station.
2. Which safety communication protocol does the CPU support?
The CPU supports PROFIsafe V2.4 and V2.6. PROFIsafe allows safety-related process data to be exchanged between the fail-safe CPU and compatible safety I/O devices over the PROFINET communication infrastructure.
3. What safety performance can the CPU provide?
The CPU can be used in safety applications up to SIL 3 according to IEC 61508 and Performance Level e according to ISO 13849-1. For railway applications, the relevant safety classification is SIL 2 according to EN 50126, EN 50128, and EN 50129, depending on the complete system architecture and application assessment.
4. How much work memory is available?
The CPU provides 150 KB of integrated work memory for the user program and 750 KB of work memory for data. A SIMATIC Memory Card is required as load memory.
5. What PROFINET functions are available?
The CPU integrates a PROFINET IO IRT interface with a 3-port switch. It can operate as a PROFINET IO controller, PROFINET I-Device, or shared I-Device and supports isochronous operation for synchronized applications.
6. How many PROFINET IO devices can the CPU control?
The CPU can control up to 64 PROFINET IO devices, including up to 64 devices using IRT communication under the specified configuration limits.
7. Is PROFIBUS DP available directly on the CPU?
The CPU does not provide a native PROFIBUS connector. PROFIBUS DP functionality can be added through a compatible communication module, allowing the CPU to operate as a DP master or DP device depending on the selected module and configuration.
8. Which engineering software is used to configure the fail-safe CPU?
The standard PLC functions are configured with STEP 7 in TIA Portal, while the safety-related program requires the STEP 7 Safety Advanced option package. Hardware configuration, PROFINET settings, diagnostics, and safety communication parameters are managed within the TIA Portal environment.
9. Does the CPU support isochronous operation?
Yes. Isochronous operation is supported over PROFINET. The CPU can synchronize signal acquisition, communication, and program execution with the PROFINET cycle for applications requiring deterministic timing.
10. What environmental conditions are supported by the SIPLUS RAIL version?
The CPU uses conformal coating and is designed for railway applications. In horizontal installation, the specified operating temperature is -25 to +60 °C, with short-duration operation up to +70 °C for 10 minutes. Vertical installation has a maximum operating temperature of +50 °C under the specified conditions.
