Siemens 6AG4010-6AC30-0XX5 Industrial PC

Where It Excels in Industrial Use

• Centralized industrial computing applications that require HMI, SCADA, visualization, engineering, and production-data functions.

• Control rooms and automation cabinets where a standardized 19-inch rack PC is preferred for organized equipment installation.

• Manufacturing systems that need Ethernet communication with PLCs, automation networks, and plant-level systems.

• Applications requiring both modern USB and display connectivity and serial communication for industrial peripherals.

• Industrial modernization projects where a rack-mounted computer must accommodate existing automation software and legacy equipment.

Key Strengths at a Glance

• Based on the Siemens SIMATIC IPC3000 Smart V3 rack PC platform.

• Uses a 19-inch, 4U chassis suitable for standardized industrial rack installations.

• Equipped with dual Ethernet connectivity for industrial network integration.

• Provides serial, USB, VGA, DisplayPort, PS/2, and audio interfaces for flexible system integration.

• Configured with an Intel Pentium Dual-Core G4400 processor, 8 GB DDR4 memory, and dual 1 TB hard drives.

• Supplied without an operating system, allowing the installation to be matched to the intended industrial application.

Technical FAQs

1. What is the Siemens 6AG4010-6AC30-0XX5 designed for?

The 6AG4010-6AC30-0XX5 is an industrial rack PC designed for HMI, SCADA, visualization, engineering, monitoring, and industrial data-processing applications.

2. What processor is installed in this model?

This configuration uses an Intel Pentium Dual-Core G4400 processor with two cores, two threads, a 3.3 GHz clock frequency, and 3 MB cache.

3. How much memory and storage does the 6AG4010-6AC30-0XX5 provide?

The configuration provides 8 GB of DDR4 SDRAM and two 1 TB hard drives.

4. What network interfaces are available?

The industrial PC provides two Ethernet LAN interfaces for connection to industrial and plant networks.

5. Does the model support serial communication?

Yes, the configuration provides two serial interfaces together with two COM interfaces supporting RS232, RS422, and RS485 communication.

6. What USB and display interfaces are available?

The PC provides four rear USB ports, two front USB ports, one VGA interface, and one DisplayPort interface.

7. Can this model be integrated with Siemens PLC systems?

Yes, it can be integrated with compatible Siemens PLC systems through Ethernet or supported serial communication interfaces and the appropriate industrial software.

8. Is an operating system included with the 6AG4010-6AC30-0XX5?

No, this configuration is supplied without an operating system, so the appropriate supported operating environment must be installed separately.

9. What should be considered when installing the PC in a rack cabinet?

The installation should provide suitable 19-inch mounting, adequate cabinet depth, ventilation, power capacity, cable clearance, and environmental conditions appropriate for industrial PC operation.

10. Is this configuration suitable for replacing an older rack-mounted industrial PC?

It can be considered for replacement applications when the existing software, processor requirements, storage, communication interfaces, rack dimensions, and operating-system requirements have been checked for compatibility.
