Siemens 6AG4010-6AD30-0FX5 SIMATIC IPC3000 SMART V3 Industrial PC
Siemens 6AG4010-6AD30-0FX5 SIMATIC IPC3000 SMART V3 Industrial PC
0.0
Points
Brand:Siemens Item No.:6AG4010-6AD30-0FX5 Product Origin: Germany Product Dimensions:481 × 176 × 509 mm Product Weight:14 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4010-6AD30-0FX5 belongs to the SIMATIC IPC3000 SMART V3 family, a 19-inch rack-mounted industrial PC platform developed for professional automation and industrial computing applications. Its 4U architecture provides a substantial hardware platform for applications where centralized computing, communication, visualization, and expansion capabilities are required.
The IPC3000 SMART V3 combines an Intel-based computing architecture with a broad selection of industrial interfaces. Dual Gigabit Ethernet, serial communication, USB, VGA, DisplayPort, and expansion interfaces give system integrators considerable flexibility when designing industrial control and monitoring systems.
This type of industrial PC is well suited to production environments where the computer needs to work alongside PLCs, HMIs, drives, remote I/O, industrial networks, and supervisory software. The rack-mounted design also makes it convenient for larger automation cabinets where several computing and communication components need to be installed in an organized configuration.
For machine builders, automation engineers, and maintenance teams, the 6AG4010-6AD30-0FX5 offers a practical Siemens industrial computing solution for established automation architectures, system upgrades, and demanding production applications.
Technical Specifications
Specification
Details
Manufacturer
Siemens
Model
6AG4010-6AD30-0FX5
Product Family
SIMATIC IPC3000 SMART V3
Product Type
Industrial PC
Form Factor
19-inch Rack PC
Rack Height
4U
Processor Platform
Intel processor platform
Memory Technology
DDR4-SDRAM
Memory Slots
2 × DDR4-SDRAM
Ethernet
2 × RJ45, 10/100/1000 Mbps
Serial Communication
RS232 / RS422 / RS485
USB
Front and rear USB interfaces
Display Interfaces
VGA / DisplayPort
Expansion
PCI / PCI Express
Power Input
100–240 VAC
Power Frequency
50–60 Hz
Power Supply
Configuration-dependent
Width
481 mm with handles / 430 mm without handles
Height
176 mm
Depth
509 mm with handles / 466 mm without handles
Dimensions
481 × 176 × 509 mm (W × H × D), with handles
Weight
10.8–14 kg, depending on configuration
The Siemens operating instructions for the SIMATIC IPC3000 SMART family specify 481 × 176 × 509 mm (W × H × D) for the applicable rack configuration and state a configuration-dependent weight range of 10.8 to 14 kg.
Because the exact 6AG4010-6AD30-0FX5 order number was not returned as an individually indexed Siemens product record in the available search results, the processor, storage, memory, and exact net weight should not be presented as model-specific values unless confirmed against the complete Siemens order documentation.
• Industrial Automation Control — The SIMATIC IPC3000 SMART V3 platform is designed for automation environments that require industrial computing for control, monitoring, visualization, and production management.
• Machine and Equipment Integration — Its 19-inch rack architecture makes it a practical computing platform for machine builders and system integrators working with centralized industrial control cabinets.
• Production Monitoring — The industrial PC can support visualization, equipment-status monitoring, production-data processing, and communication with connected automation devices.
• Industrial Networking — Dual Gigabit Ethernet interfaces and serial communication resources provide practical connectivity for PLCs, HMIs, industrial networks, and peripheral equipment.
• Centralized Automation Computing — The 4U rack format is particularly suitable for installations where computing, communication, and expansion hardware need to be organized within a standard industrial rack.
Key Strengths at a Glance
• 19-inch 4U Rack Design — Provides a professional industrial computing platform that integrates naturally into standardized control cabinets and equipment racks.
• Industrial Connectivity — The IPC3000 SMART V3 platform combines Gigabit Ethernet, serial communication, USB, VGA, and DisplayPort interfaces for flexible system integration.
• Expandable Hardware Architecture — PCI and PCI Express expansion capabilities allow additional industrial communication and application-specific hardware to be incorporated when required.
• Flexible Computing Platform — The IPC3000 SMART V3 family is based on Intel processor technology and supports configurations intended for different levels of industrial computing demand.
• Wide-Range AC Input — The platform supports a 100–240 VAC input range, helping simplify deployment across different industrial power environments.
• Service-Oriented Industrial Construction — The rack-mounted architecture provides an organized solution for professional automation installations where accessibility and system maintainability are important.
Technical FAQs
1. What is the Siemens 6AG4010-6AD30-0FX5?
The 6AG4010-6AD30-0FX5 is a Siemens SIMATIC IPC3000 SMART V3 industrial PC configuration intended for industrial automation, machine systems, visualization, data processing, and supervisory applications.
2. What type of installation is the IPC3000 SMART V3 designed for?
The platform uses a 19-inch 4U rack-mounted form factor and is intended for integration into industrial cabinets, equipment racks, and centralized automation computing installations.
3. What Ethernet communication capability does the IPC3000 SMART V3 provide?
The platform provides two RJ45 Ethernet interfaces supporting 10/100/1000 Mbps communication, making it suitable for connecting the industrial PC to automation networks and higher-level production systems.
4. Which serial communication standards are supported?
The IPC3000 SMART V3 platform provides serial communication resources supporting RS232, RS422, and RS485, allowing connection to compatible industrial equipment and legacy serial devices.
5. Does the IPC3000 SMART V3 support additional expansion cards?
Yes. The platform provides PCI and PCI Express expansion resources, enabling additional communication, acquisition, interface, and application-specific cards to be installed according to the system configuration.
6. What display interfaces are available?
The platform provides VGA and DisplayPort interfaces for connecting industrial monitors and other compatible display equipment.
7. What USB interfaces are available on the system?
The documented IPC3000 SMART V3 platform provides USB interfaces on both the front and rear panels, allowing convenient access for service equipment and permanent peripheral connections.
8. What type of storage configuration can be used with the IPC3000 SMART V3?
The platform supports industrial storage configurations using its available drive bays, allowing the system to be configured for applications requiring operating-system storage, application data, or additional local storage capacity.
9. What power supply architecture does the IPC3000 SMART V3 use?
The platform supports a wide 100–240 VAC input range and is available with industrial power-supply configurations including 350 W, 500 W, and 850 W options depending on the specific product configuration.
10. What should be checked before replacing another IPC3000 SMART V3 model with the 6AG4010-6AD30-0FX5?
The complete order number should be checked against the existing system configuration, including processor, memory, storage, operating system, power supply, expansion requirements, interfaces, and software compatibility before replacement.
