Siemens 6AG4010-6AD41-0XX5 SIMATIC IPC3000 SMART V3 Industrial PC
Siemens 6AG4010-6AD41-0XX5 SIMATIC IPC3000 SMART V3 Industrial PC
0.0
Points
Brand:Siemens Item No.:6AG4010-6AD41-0XX5 Product Origin: Germany Product Dimensions:481 × 176 × 509 mm Product Weight:17 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4010-6AD41-0XX5 belongs to the SIMATIC IPC3000 SMART V3 family, a 19-inch rack-mounted industrial PC platform developed for industrial automation and information-processing applications.
The platform combines a conventional 4U rack design with dual Gigabit Ethernet, USB connectivity, serial communication, VGA and DisplayPort outputs, and extensive expansion capability. This combination gives system integrators considerable freedom when building HMI, SCADA, machine visualization, data acquisition, and supervisory computing systems.
The IPC3000 SMART V3 is particularly attractive for applications where a compact embedded computer may not offer enough expansion capacity. PCI and PCI Express support allow additional industrial hardware to be integrated directly into the system, while the broad range of standard interfaces helps simplify connections to existing plant equipment.
Because the exact hardware configuration represented by 6AG4010-6AD41-0XX5 is not reliably documented in the public sources located, processor, RAM, storage, operating system, and other configuration-dependent items should be confirmed from the original Siemens order record before purchase.
Technical Specifications
Specification
Details
Product family
SIMATIC IPC3000 SMART V3
Order number
6AG4010-6AD41-0XX5
Form factor
19-inch rack PC, 4U
Ethernet
2 × RJ45, 10/100/1000 Mbps
Front USB
2 × USB 2.0
Rear USB
4 × USB 3.0
Display interfaces
VGA and DisplayPort
Serial connectivity
Serial/COM interfaces; RS232/422/485 support on applicable configuration
Expansion
PCI and PCI Express
Audio
HD audio, Realtek ALC887, 5.1-channel support
Power input
100–240 VAC, 50–60 Hz
Power supply
Configuration-dependent; 350 W and 500 W family variants are documented
Dimensions (W × H × D)
481 × 176 × 509 mm with handles; 430 × 176 × 466 mm without handles
Weight
13.3–17 kg, depending on configuration
Processor
Configuration-dependent; confirm exact order record
Memory
Configuration-dependent; confirm exact order record
Storage
Configuration-dependent; confirm exact order record
Operating system
Configuration-dependent; confirm exact order record
The dimensions above correspond to the documented 6AG4010-6 IPC3000 SMART V3 family, with 481 × 176 × 509 mm for the version with handles and 430 × 176 × 466 mm without handles. Siemens documentation gives a configuration-dependent weight range of 13.3–17 kg.
Recommended Companion Models
Model
Product Name
6AG4010-6AD40-0DX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-6BC30-0XX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-6BC40-0XX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-6BD31-0XX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
The BC30 and BC40 variants are documented as IPC3000 SMART V3 4U rack PCs using Intel Core i5-6500 processors, with different memory and storage configurations. The BD31 variant is likewise documented as a Core i5-6500 configuration with 256 GB SSD, 8 GB DDR4, and a 500 W power supply.
Frequently Selected Alternatives
Model
Product Name
6AG4010-6AB20-0XX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-6AB30-0XX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-6BB20-0XX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-6BB30-0XX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
Where It Excels in Industrial Use
• Industrial automation and machine control: The Siemens 6AG4010-6AD41-0XX5 provides a rack-mounted industrial computing platform for HMI, SCADA, machine visualization, supervisory control, and plant-level data processing.
• Centralized industrial computing: Its 19-inch 4U rack architecture makes it well suited to control cabinets, centralized automation stations, and industrial equipment rooms where expansion capability is important.
• Industrial networking: Dual RJ45 Gigabit Ethernet interfaces support communication between the IPC, automation controllers, engineering stations, production equipment, and plant networks.
• Industrial visualization: VGA and DisplayPort connectivity provides practical options for connecting operator panels, engineering monitors, and industrial displays.
• System integration: PCI and PCI Express expansion capability, combined with USB and serial interfaces, allows the IPC to accommodate additional communication, acquisition, and specialized industrial hardware.
Key Strengths at a Glance
• 19-inch 4U rack-mount format provides a familiar installation solution for industrial control cabinets and centralized automation systems.
• Dual 10/100/1000 Mbps Ethernet ports support fast industrial network communication and LAN Wake functionality.
• Flexible PCI and PCI Express expansion gives integrators room for additional communication, I/O, acquisition, motion, or interface cards.
• Comprehensive USB connectivity includes two front USB 2.0 ports and four rear USB 3.0 ports on the documented V3 platform.
• VGA and DisplayPort interfaces support modern and established industrial display applications.
• Serial and COM connectivity helps bridge the gap between the IPC and existing industrial equipment using RS232, RS422, or RS485 communication.
• Wide-range AC power input supports 100–240 VAC, 50–60 Hz operation, making the platform practical for a broad range of industrial installations.
Technical FAQs
1. What type of industrial computer is the Siemens 6AG4010-6AD41-0XX5?
The 6AG4010-6AD41-0XX5 is part of the SIMATIC IPC3000 SMART V3 family of 19-inch rack-mounted industrial PCs, designed for industrial automation, visualization, communication, and data-processing applications.
2. Does the 6AG4010-6AD41-0XX5 support Gigabit Ethernet?
Yes. The IPC3000 SMART V3 platform provides two RJ45 Ethernet interfaces supporting 10/100/1000 Mbps communication.
3. What expansion options are available on the IPC3000 SMART V3?
The platform provides PCI and PCI Express expansion capability, allowing additional industrial communication, acquisition, control, and interface cards to be installed.
4. How many USB ports does the IPC3000 SMART V3 provide?
The documented V3 platform provides two USB 2.0 ports on the front and four USB 3.0 ports on the rear, with additional USB connectivity available at the motherboard level.
5. Which display interfaces are available?
The IPC3000 SMART V3 platform supports VGA and DisplayPort connectivity, providing flexibility for industrial monitors and conventional displays.
6. Does the IPC3000 SMART V3 support RS232, RS422, and RS485 communication?
Yes. Applicable configurations provide serial/COM interfaces supporting RS232, RS422, and RS485 communication, making the platform suitable for both modern and legacy industrial devices.
7. What type of power supply does the IPC3000 SMART V3 use?
The platform supports 100–240 VAC at 50–60 Hz. Siemens documentation for the 6AG4010-6 family identifies different power-supply configurations, including 350 W and 500 W variants.
8. Can the IPC3000 SMART V3 be expanded with industrial interface cards?
Yes. The PCI and PCI Express expansion architecture is designed to support additional communication, acquisition, control, and other specialized interface cards.
9. Is the CPU configuration of 6AG4010-6AD41-0XX5 fixed?
The 0XX5 suffix represents a configuration-dependent order number, and a reliable public source confirming one specific CPU, memory, or storage combination for this exact order number was not located. Those components should therefore be verified against the original Siemens order documentation.
10. Is the 6AG4010-6AD41-0XX5 suitable for existing automation systems?
Yes. Its combination of Ethernet, serial communication, USB, display interfaces, and PCI/PCIe expansion makes the IPC3000 SMART V3 platform well suited to upgrading or maintaining established industrial automation and control systems.
