Siemens 6AG4010-6AD50-0XX5 SIMATIC IPC3000 SMART V3 Rack-Mount Computing System
Siemens 6AG4010-6AD50-0XX5 SIMATIC IPC3000 SMART V3 Rack-Mount Computing System
0.0
Points
Brand:Siemens Item No.:6AG4010-6AD50-0XX5 Product Origin: Germany Product Dimensions:481 × 176 × 509 mm Product Weight:17 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4010-6AD50-0XX5 is a SIMATIC IPC3000 SMART V3 rack-mounted computing system designed for industrial automation, visualization, communication, and data-processing applications. Its 19-inch, 4U mechanical format provides a familiar installation approach for control cabinets and centralized industrial equipment racks.
This particular configuration combines an Intel Pentium Dual Core G4400 processor, 32 GB DDR4 SDRAM, and a 256 GB SSD. The system is also equipped with dual Ethernet, serial communication, multiple USB interfaces, VGA, DisplayPort, PS/2, and audio connectivity, giving it the flexibility needed for a broad range of automation installations.
The 6AG4010-6AD50-0XX5 is therefore a sensible choice when an application calls for a rack-mounted industrial computer with a balanced hardware configuration and extensive connection options rather than a highly specialized computing platform.
Technical Specifications
Specification
Details
Product family
SIMATIC IPC3000 SMART V3
Order number
6AG4010-6AD50-0XX5
Product type
Rack-mounted industrial computer
Rack format
19-inch, 4U
Processor
Intel Pentium Dual Core G4400
CPU
2 cores / 2 threads, 3.3 GHz, 3 MB cache
Installed memory
2 × 16 GB DDR4 SDRAM, 32 GB total
Storage
256 GB SSD
Ethernet
2 × Ethernet LAN
Serial interfaces
2 × serial
COM interfaces
2 × COM, RS232/RS422/RS485
USB
2 × front USB; 4 × rear USB
Display interfaces
1 × VGA; 1 × DisplayPort
Keyboard / mouse
2 × PS/2
Audio
Integrated audio
Optical drive
No DVD drive
Power supply
350 W
Operating system
Without operating system
Market release
China market
Dimensions (W × H × D)
481 × 176 × 509 mm with handles; 430 × 176 × 466 mm without handles
Weight
13.3–17 kg, depending on configuration
The processor, memory, storage, interface arrangement, DVD status, operating-system status, and 350 W supply correspond to the published 6AG4010-6AD50-0XX5 configuration. Siemens documentation for the 6AG4010-6....-.... range specifies dimensions of 481 × 176 × 509 mm and a configuration-dependent weight of 13.3–17 kg.
Recommended Companion Models
Model
Product Name
6AG4010-6AD40-0DX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-6AD50-0FX5
Siemens SIMATIC IPC3000 SMART V3 Automation Computing System
• Centralized automation computing: This SIMATIC IPC3000 SMART V3 configuration provides a practical computing base for supervisory control, industrial software, production monitoring, and machine-level data processing.
• Operator visualization: VGA and DisplayPort outputs make the system suitable for connecting industrial monitors used for HMI visualization, diagnostics, process supervision, and control-room applications.
• Industrial network communication: Two Ethernet interfaces and multiple serial communication options allow the IPC to connect with controllers, automation networks, peripheral devices, and legacy equipment.
• Rack-based control installations: The 19-inch, 4U enclosure fits naturally into standardized industrial racks and larger control cabinets, helping keep computing equipment organized and accessible.
• Production data handling: With 32 GB of DDR4 memory and a 256 GB SSD, the documented configuration provides a solid foundation for industrial applications that require responsive local data processing.
Key Strengths at a Glance
• Balanced processing configuration: The Intel Pentium Dual Core G4400 provides a straightforward two-core platform for industrial software, monitoring, and supervisory workloads.
• Generous installed memory: Two 16 GB DDR4 modules provide 32 GB of system memory, giving the IPC useful headroom for multitasking industrial applications.
• Solid-state storage: A 256 GB SSD provides fast local storage for the system environment, application software, and operational data.
• Broad interface selection: Two Ethernet ports, serial interfaces, front and rear USB, VGA, DisplayPort, PS/2, and audio connections simplify integration with a wide range of industrial equipment.
• Practical rack architecture: The 4U chassis combines a conventional 19-inch rack footprint with the connectivity expected from an industrial automation computer.
Technical FAQs
1. What processor is used in the Siemens 6AG4010-6AD50-0XX5?
The documented configuration uses an Intel Pentium Dual Core G4400 with 2 cores, 2 threads, a 3.3 GHz clock speed, and 3 MB cache.
2. How much RAM is installed in this IPC3000 SMART V3 configuration?
The system is documented with 2 × 16 GB DDR4 SDRAM, providing 32 GB of installed memory.
3. What storage device is included?
The specified configuration includes a 256 GB SSD for local system and application storage.
4. What Ethernet capability does the IPC provide?
The system has two Ethernet LAN interfaces for connecting the industrial PC to automation networks and other Ethernet-based equipment.
5. Which serial communication functions are available?
The configuration provides two serial interfaces and two COM interfaces supporting RS232, RS422, and RS485 communication functions.
6. How is USB connectivity arranged on the IPC?
There are two USB ports on the front and four USB ports on the rear, providing convenient access for both service and permanently connected peripherals.
7. Which video outputs can be used for industrial displays?
The IPC provides VGA and DisplayPort outputs, allowing connection to compatible industrial monitors and visualization equipment.
8. Does this configuration include a DVD drive?
No. The documented configuration is specified as an IPC3000 standard version without a DVD drive.
9. What type of power supply is specified for the 6AG4010-6AD50-0XX5?
The documented configuration uses a 350 W power supply. Siemens documentation for the 6AG4010-6 family specifies 100–240 VAC input for the 350 W supply variant.
10. Can this IPC be integrated into a standard 19-inch rack?
Yes. The IPC3000 SMART V3 is designed as a 19-inch, 4U rack PC, making it suitable for standardized industrial rack and control-cabinet installations.
