Siemens 6AG4012-2BB20-0XX0 SIMATIC IPC347G Industrial Rack PC

Where It Fits in Industrial Computing Systems

• Designed for industrial applications that require a rack-mounted computer for equipment supervision, production monitoring, and data processing.

• Combines an Intel Core i5-6500 processor with 8 GB of DDR4 memory for compatible industrial software and operational workloads.

• Uses a 19-inch, 4U chassis for installation in compatible industrial racks and control-room enclosures.

• Includes two Gigabit Ethernet ports for connecting to industrial networks and other Ethernet-enabled equipment.

• Offers DisplayPort, VGA, USB, serial, PS/2, and audio connections for a variety of displays and peripherals.

• Provides a 1 TB internal hard disk drive for operating-system installation, applications, and locally stored data.

• Ships without an operating system, allowing system integrators to select and install compatible software.

Notable Advantages for Automation Integration

• Quad-core Intel processing: The Core i5-6500 operates at 3.2 GHz, with turbo frequencies up to 3.6 GHz and 6 MB cache.

• 8 GB DDR4 memory: The specified configuration uses one 8 GB memory module, with platform support for memory expansion up to 32 GB.

• High-capacity local storage: The included 1 TB HDD accommodates application files, configuration backups, and operational records.

• Flexible software deployment: The 0XX0 suffix identifies a configuration supplied without an operating system.

• Multiple communication options: Two Gigabit Ethernet ports and two serial interfaces support integration with compatible networked and legacy equipment.

• Rack-ready design: The 4U form factor suits installations designed for 19-inch rack equipment.

• Industrial AC power: A 350 W power supply supports 100–240 V AC input; the power cable is supplied separately.

Technical FAQs

1. What is the Siemens 6AG4012-2BB20-0XX0 used for?

It is a SIMATIC IPC347G industrial rack PC intended for compatible industrial computing, production monitoring, equipment supervision, and automation support.

2. Which processor does this model use?

It features an Intel Core i5-6500 processor with four cores, four threads, a 3.2 GHz base frequency, turbo speeds up to 3.6 GHz, and 6 MB cache.

3. How much memory is installed?

The specified configuration includes 8 GB of DDR4 memory in one 8 GB module. The IPC347G platform supports memory expansion up to 32 GB, subject to module compatibility.

4. What storage is included?

This model includes one internal 1 TB hard disk drive (HDD) for applications, configuration files, and locally retained data.

5. Does the computer come with an operating system?

No. The 0XX0 variant is supplied without an operating system, so the integrator can install a compatible platform and application software.

6. Which network connections are available?

It provides two Gigabit Ethernet interfaces for connecting to compatible industrial networks, local systems, and other Ethernet-enabled devices.

7. What display interfaces does it have?

The system includes one DisplayPort and one VGA interface for compatible monitors and display equipment.

8. Which USB and serial interfaces are provided?

It includes two front USB ports, four rear USB ports, two internal USB connections, two serial COM ports, two COM pin headers, two PS/2 connections, and audio interfaces.

9. What are the power requirements?

The computer uses a 350 W industrial power supply with a 100–240 V AC input range. The power supply cable is not included.

10. What should be considered before installation?

Ensure the rack provides adequate ventilation, suitable power, and access for servicing. The unit has IP20 protection at the rear; it should be installed in a suitable controlled environment rather than exposed to water or excessive dust.
