Introduction to the SIMATIC IPC347G Platform

The Siemens SIMATIC IPC347G is a rack-mounted industrial computer designed for applications requiring PC-based processing, broad peripheral connectivity, and compatibility with industrial software. The 6AG4012-2CA30-0BX0 configuration combines an Intel Core i7-6700 processor, 16 GB of DDR4 memory, a 1 TB HDD, and Windows 10 IoT Enterprise.

Its dual Gigabit Ethernet ports, display outputs, serial communication interfaces, and expansion options make it suitable for compatible industrial visualization, equipment monitoring, and data-processing applications. The 19-inch, 4U enclosure supports integration into equipment racks and control-room environments.

Technical Specifications

Specification	Details
Manufacturer	Siemens
Product family	SIMATIC IPC347G
Order number	6AG4012-2CA30-0BX0
Product type	Industrial rack PC
Chassis format	19-inch, 4U
Processor	Intel Core i7-6700
Processor cores / threads	4 cores / 8 threads
Base / turbo frequency	3.4 GHz / up to 4.0 GHz
Cache	8 MB
Chipset	Intel H110
Installed memory	16 GB DDR4
Maximum memory	Up to 32 GB
Storage	1 TB internal HDD
Operating system	Windows 10 IoT Enterprise for Core i7
Ethernet	2 × Gigabit Ethernet
Display interfaces	1 × DisplayPort, 1 × VGA
USB interfaces	2 × front USB 2.0, 4 × rear USB 3.0, 2 × internal USB 2.0
Serial interfaces	2 × COM ports supporting RS-232, RS-422, and RS-485
Additional interfaces	2 × PS/2, audio
Optical drive	No DVD ±RW
Expansion slots	7 expansion slots across PCI and PCI Express configurations
Power supply	350 W
Input voltage	100–240 V AC
Operating temperature	Up to 40 °C for full processor performance, subject to installation conditions
Protection rating	IP20 on the rear
Dimensions (W × H × D)	481 × 176 × 509 mm
Weight	Approximately 17 kg, depending on configuration
Mounting	Horizontal or vertical
Power cable	Not included

Recommended Companion Models

Model	Product name
6AG4012-2CA20-0BX0	Siemens SIMATIC IPC347G Core i7 Rack PC, 8 GB DDR4, 1 TB HDD, Windows 10 IoT Enterprise
6AG4012-2CB30-0BX0	Siemens SIMATIC IPC347G Core i7 Rack PC, 16 GB DDR4, 256 GB SSD, Windows 10 IoT Enterprise
6AG4012-2CB20-0BX0	Siemens SIMATIC IPC347G Core i7 Rack PC, 8 GB DDR4, SSD storage, Windows 10 IoT Enterprise
6AG4012-2BB30-0XX0	Siemens SIMATIC IPC347G Core i5 Rack PC, 16 GB DDR4, 1 TB HDD, without operating system

Frequently Selected Alternatives

Model	Product name
6AG4012-2CA30-0XX0	Siemens SIMATIC IPC347G Core i7 Rack PC, 16 GB DDR4, 1 TB HDD, without operating system
6AG4012-2BA20-0AX0	Siemens SIMATIC IPC347G Core i5 Rack PC, 8 GB DDR4, 1 TB HDD, Windows 10 IoT Enterprise
6AG4012-2CB30-0BX0	Siemens SIMATIC IPC347G Core i7 Rack PC, 16 GB DDR4, 256 GB SSD, Windows 10 IoT Enterprise
6AG4012-2AA10-0XX0	Siemens SIMATIC IPC347G Pentium G4400 Rack PC, 4 GB DDR4, 1 TB HDD, without operating system

Where It Excels in Industrial Computing Environments

Designed for 19-inch rack installations with a 4U chassis, supporting industrial computing, visualization, and SCADA applications.
Powered by an Intel Core i7-6700 processor with four cores and eight threads for multitasking and demanding compatible workloads.
Combines 16 GB of DDR4 memory with a 1 TB hard disk drive for application files, system data, and operational records.
Includes Windows 10 IoT Enterprise for Intel Core i7 configurations, supporting compatible Windows-based industrial software.
Provides dual Gigabit Ethernet, DisplayPort, VGA, serial, USB, PS/2, and audio interfaces for integration with industrial equipment.

Key Benefits for Industrial Integration

Multicore performance: The Intel Core i7-6700 supports industrial visualization, monitoring, and data-processing workloads.
Expanded memory capacity: 16 GB of DDR4 memory provides additional headroom for concurrent applications.
High-capacity storage: The 1 TB HDD accommodates software, system files, logs, and operational data.
Industrial connectivity: Multiple network, display, serial, and USB interfaces support integration with compatible peripherals.
Ready-to-deploy software configuration: Windows 10 IoT Enterprise provides a familiar environment for compatible industrial applications.

Technical FAQs

1. What is the Siemens 6AG4012-2CA30-0BX0?

It is a SIMATIC IPC347G industrial rack PC configured with an Intel Core i7-6700 processor, 16 GB of DDR4 memory, a 1 TB HDD, and Windows 10 IoT Enterprise.

2. Which processor does this model use?

It uses an Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, up to 4.0 GHz turbo frequency, and 8 MB of cache.

3. How much memory is installed?

The system includes 16 GB of DDR4 memory and supports expansion up to 32 GB.

4. What storage capacity does it provide?

It includes a 1 TB internal hard disk drive for applications, system files, and operational data.

5. Which operating system is included?

This configuration includes Windows 10 IoT Enterprise for Intel Core i7 systems.

6. Which display interfaces are available?

The PC provides one DisplayPort and one VGA interface for connecting compatible displays.

7. How many Ethernet ports does it have?

It includes two Gigabit Ethernet interfaces for network communication and integration with compatible industrial systems.

8. Can it connect to legacy industrial devices?

Yes, it includes two serial COM ports, two PS/2 interfaces, and multiple USB ports for compatible industrial peripherals.

9. What power supply does it use?

The system uses a 350 W industrial power supply with a 100–240 V AC input range. The power supply cable is not included.

10. Can the memory be upgraded?

Yes, the IPC347G platform supports up to 32 GB of DDR4 memory, allowing additional capacity for compatible applications.
