Siemens 6AG4012-2CA40-0BX0 SIMATIC IPC347G Industrial Rack PC

Where It Supports Industrial Computing

• Designed for industrial workstation, machine visualization, and plant-floor computing applications.

• Powered by an Intel Core i7-6700 processor for demanding multitasking and industrial software workloads.

• Equipped with 32 GB DDR4 memory to support memory-intensive applications and concurrent processes.

• Includes a 1 TB internal hard disk for application files, operational records, and local data storage.

• Uses a 19-inch, 4U rack-mount chassis suited to industrial cabinets and control-room equipment racks.

• Ships with Windows 10 IoT Enterprise for i7, providing a preinstalled operating system environment for compatible industrial applications.

Key Benefits for Industrial Integration

• High-capacity memory: 32 GB RAM supports applications that require substantial working memory.

• Multicore processing: The Intel Core i7-6700 features four cores and eight threads for parallel workloads.

• Industrial network connectivity: Dual Gigabit Ethernet interfaces support communication with compatible automation and enterprise networks.

• Broad peripheral support: USB, serial, PS/2, and audio interfaces accommodate a range of industrial and legacy devices.

• Flexible display connection: DisplayPort and VGA support compatible monitors and visualization setups.

• Rack-based installation: The 4U enclosure is designed for integration into standard 19-inch rack environments.

• Preinstalled operating system: Windows 10 IoT Enterprise for i7 reduces the need for a separate initial OS installation, subject to application compatibility and licensing requirements.

Technical FAQs

Q1: What is the Siemens 6AG4012-2CA40-0BX0?

It is a SIMATIC IPC347G industrial rack PC designed for industrial computing, visualization, and system integration applications.

Q2: Which processor does this model use?

It uses an Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, a maximum turbo frequency of 4.0 GHz, and 8 MB cache.

Q3: How much RAM is installed?

This configuration includes 32 GB of DDR4 memory, providing substantial capacity for multitasking and memory-intensive industrial applications.

Q4: What storage does the system provide?

It is configured with a 1 TB internal hard disk drive for software, local records, and operational data.

Q5: Which operating system is included?

This model includes Windows 10 IoT Enterprise for i7. Compatibility with the intended software and peripherals should be checked before deployment.

Q6: What Ethernet interfaces are available?

The IPC347G provides two Gigabit Ethernet interfaces for network communication and connection to compatible industrial systems.

Q7: Which display connections are supported?

The system provides one DisplayPort and one VGA interface for compatible displays.

Q8: Can it connect to legacy industrial equipment?

Yes. Its interface set includes serial COM ports supporting RS-232, RS-422, and RS-485, along with PS/2 and USB connections.

Q9: What power input does the computer require?

It uses a 350 W power supply designed for 100–240 V AC input. The power supply cable is not included.

Q10: What are the chassis dimensions and installation format?

The computer uses a 19-inch, 4U rack format and measures approximately 430 × 176 × 465.8 mm (W × H × D). Allow additional clearance for cabling, ventilation, and servicing.
