Name: Siemens 6AG4012-2CB40-0XX0 SIMATIC IPC347G Industrial Rack PC
Brand: Siemens
SKU: 22541
Availability: InStock
Rating: 5.0 (1 reviews)

Overview of the SIMATIC IPC347G Industrial Platform

The Siemens 6AG4012-2CB40-0XX0 combines Intel Core i7 processing, 32 GB DDR4 memory, and 256 GB SSD storage in a 19-inch, 4U industrial computer. It is suited to industrial visualization, SCADA applications, production monitoring, data acquisition, and other computing tasks that benefit from substantial memory capacity and solid-state storage.

Its selection of network, display, serial, and peripheral interfaces helps simplify integration into existing installations. Because this version is supplied without an operating system, users can plan the software environment around their application requirements, subject to hardware and software compatibility.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Order number	6AG4012-2CB40-0XX0
Product family	SIMATIC IPC347G
Device type	Industrial rack PC
Form factor	19-inch, 4U
Processor	Intel Core i7-6700
CPU cores / threads	4 cores / 8 threads
Base frequency	3.4 GHz
Maximum turbo frequency	Up to 4.0 GHz
CPU cache	8 MB
Installed memory	32 GB DDR4
Memory configuration	2 × 16 GB
Storage	256 GB SSD
Operating system	Not included
Ethernet	2 × Gigabit Ethernet
Display interfaces	1 × DisplayPort, 1 × VGA
USB interfaces	2 × front, 4 × rear, 2 × internal
Serial interfaces	2 × serial ports
Keyboard / mouse interfaces	2 × PS/2
Audio	Audio input/output and microphone input
Expansion slots	PCI and PCI Express
Power supply	350 W
Input voltage	100–240 V AC
Power cable	Not included
Front / rear protection	IP20 / IP20
Operating temperature	5–40 °C
Dimensions (W × H × D)	430 × 176 × 465.8 mm
Weight	Approx. 17 kg
Optical drive	No DVD ±RW drive

Recommended Companion Models

Model	Product Name	Typical Application
6AG4012-2CB30-0XX0	SIMATIC IPC347G, Core i7, 16 GB RAM, 256 GB SSD, without OS	Similar SSD configuration with lower memory
6AG4012-2CB20-0XX0	SIMATIC IPC347G, Core i7, 8 GB RAM, 256 GB SSD, without OS	Standard industrial computing and visualization
6AG4012-2CA40-0XX0	SIMATIC IPC347G, Core i7, 32 GB RAM, 1 TB HDD, without OS	Larger-capacity mechanical storage
6AG4012-2BA20-0XX0	SIMATIC IPC347G, Core i5, 8 GB RAM, 1 TB HDD, without OS	Alternative processing and storage configuration

Frequently Selected Alternatives

Model	Product Name	Key Difference
6AG4012-2CB40-0BX0	SIMATIC IPC347G, Core i7, 32 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise	Same principal hardware with a preinstalled operating system
6AG4012-2CA30-0XX0	SIMATIC IPC347G, Core i7, 16 GB RAM, 1 TB HDD, without OS	HDD storage and reduced memory
6AG4012-2CB30-0XX0	SIMATIC IPC347G, Core i7, 16 GB RAM, 256 GB SSD, without OS	Same SSD capacity with less RAM
6AG4012-2CB20-0XX0	SIMATIC IPC347G, Core i7, 8 GB RAM, 256 GB SSD, without OS	Lower-memory option for less demanding workloads

Where It Supports Industrial Computing Operations

Designed for industrial automation support, SCADA workstations, machine monitoring, and production data processing.
Integrates an Intel Core i7-6700 processor with 32 GB DDR4 memory for multitasking and demanding industrial applications.
Features a 256 GB solid-state drive for responsive application loading and system access.
Uses a 19-inch, 4U rack-mount enclosure suited to industrial cabinets, control rooms, and centralized computing installations.
Supports integration with Ethernet networks, serial devices, display equipment, and established industrial peripherals.

Key Advantages for Industrial Integration

Powerful processing: The four-core, eight-thread Intel Core i7-6700 handles multiple concurrent computing tasks.
Expanded memory: 32 GB DDR4 supports memory-intensive applications and complex visualization workloads.
SSD-based storage: The 256 GB SSD offers fast data access and application startup.
Versatile connectivity: Dual Gigabit Ethernet, DisplayPort, VGA, USB, serial, PS/2, and audio interfaces support varied system configurations.
Expansion options: PCI and PCI Express slots accommodate compatible interface and add-on cards.
Operating-system flexibility: Supplied without an operating system, allowing system integrators to plan a compatible software installation.
Industrial rack format: The metal chassis and ventilation design support installation in appropriately managed industrial environments.

Technical FAQs

1. What is the Siemens 6AG4012-2CB40-0XX0?

It is a Siemens SIMATIC IPC347G industrial rack PC intended for industrial computing, visualization, monitoring, and automation-related applications.

2. Which processor is installed?

The system uses an Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, up to 4.0 GHz turbo frequency, and 8 MB cache.

3. How much RAM does this configuration include?

It includes 32 GB of DDR4 memory, configured as two 16 GB modules.

4. What storage capacity is provided?

The system is equipped with a 256 GB solid-state drive for the operating system, applications, and local data.

5. Does this model come with an operating system?

No. The 0XX0 configuration is supplied without an operating system, so a compatible operating system must be installed separately.

6. Which Ethernet connections are available?

It provides two Gigabit Ethernet interfaces for network communication and connections to compatible industrial devices.

7. What display interfaces does the IPC347G support?

The system includes one DisplayPort and one VGA interface for connecting compatible displays.

8. Which peripheral interfaces are included?

The configuration includes front and rear USB ports, internal USB connections, two serial interfaces, two PS/2 interfaces, and audio connections.

9. What are the power requirements?

The industrial power supply is rated at 350 W and accepts 100–240 V AC. A power supply cable is not included.

10. What installation conditions should be checked?

Verify the rack dimensions, ventilation clearance, ambient temperature, electrical supply, interface requirements, expansion-card compatibility, and operating-system support before installation.
