Siemens 6AG4012-2CC20-0XX0 SIMATIC IPC347G Industrial Rack PC

Where It Supports Industrial Computing Applications

• Designed for industrial workstations, SCADA visualization, production monitoring, and equipment management.

• Combines an Intel Core i7-6700 processor with 8 GB DDR4 memory for everyday industrial computing and control applications.

• Features a 512 GB SSD for operating-system installation, industrial software, and local data storage.

• Uses a 19-inch, 4U rack-mount chassis suited to industrial cabinets and centralized control-room installations.

• Provides Ethernet, serial, USB, and display interfaces for integration with compatible industrial equipment and peripherals.

Key Benefits for Industrial System Integration

• Industrial processing platform: The Intel Core i7-6700 supports multitasking, visualization, and production-support workloads.

• Solid-state storage: The 512 GB SSD provides responsive access to applications and local data.

• Configurable software environment: Supplied without an operating system, this model allows system integrators to select a compatible software platform.

• Extensive connectivity: Dual Gigabit Ethernet, DisplayPort, VGA, USB, serial, PS/2, and audio interfaces support diverse integration requirements.

• Expansion flexibility: PCI and PCI Express slots accommodate compatible communication cards and additional hardware.

• Rack-mount construction: The 4U enclosure supports organized installation in industrial racks and equipment cabinets.

Technical FAQs

1. What is the Siemens 6AG4012-2CC20-0XX0?

It is a Siemens SIMATIC IPC347G industrial rack PC designed for industrial computing, visualization, monitoring, and automation-related applications.

2. Which processor does this model use?

It uses an Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, up to 4.0 GHz turbo frequency, and 8 MB cache.

3. How much memory is installed?

This configuration includes 8 GB of DDR4 memory for industrial software, visualization, and general multitasking workloads.

4. What storage capacity does it provide?

The system includes a 512 GB solid-state drive for operating-system installation, application files, and local data.

5. Does this model include a preinstalled operating system?

No. The 0XX0 suffix identifies a configuration supplied without an operating system, which must be installed separately.

6. Which network interfaces are available?

The IPC347G provides two Gigabit Ethernet interfaces for network communication and connection to compatible industrial equipment.

7. Which display interfaces does it support?

It includes one DisplayPort and one VGA interface for connecting compatible displays.

8. What USB and serial interfaces are included?

The platform provides two front USB ports, four rear USB ports, two internal USB connections, two serial interfaces, two PS/2 interfaces, and audio connections.

9. What are the power and environmental specifications?

The system uses a 350 W power supply with a 100–240 V AC input range. Its specified operating temperature is 5–40 °C, with IP20 protection at the front and rear.

10. What should be checked before installation?

Verify rack clearance, ventilation, power compatibility, operating-system support, peripheral requirements, and expansion-card compatibility before deploying the system.
