Siemens 6AG4021-0AA11-1BA0 SIMATIC IPC127E Industrial Box PC
Siemens 6AG4021-0AA11-1BA0 SIMATIC IPC127E Industrial Box PC
0.0
Points
Brand:Siemens Item No.:6AG4021-0AA11-1BA0 Product Origin: Germany Product Dimensions:85 × 85 × 41 mm Product Weight:0.444 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4021-0AA11-1BA0 is an embedded industrial computer designed for compact automation systems, machine-level monitoring, and industrial communication. Its Intel Atom E3930 processor, 2 GB DDR4 memory, and 64 GB SSD provide a practical hardware foundation for applications with modest computing requirements.
The preinstalled Windows 10 Enterprise LTSB 2016 operating system helps simplify initial software deployment. Two independent Gigabit Ethernet interfaces, PROFINET support, USB 3.0 ports, and DisplayPort connectivity enable integration with compatible peripherals and industrial networks.
With fanless cooling and a 24 V DC power input, this IPC127E configuration is suitable for appropriately designed industrial installations. Confirm software compatibility, mounting requirements, and lifecycle support before deploying it in a new system.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order number
6AG4021-0AA11-1BA0
Product family
SIMATIC IPC127E
Device type
Industrial Box PC
Chassis design
Base version, built-in unit
Processor
Intel Atom E3930
Processor cores / threads
2 cores / 2 threads
Processor frequency
1.3 GHz
Installed memory
2 GB DDR4
Maximum memory
2 GB
Storage
64 GB SSD
Operating system
Windows 10 Enterprise LTSB 2016, 64-bit
Supported UI languages
English, German, French, Italian, Spanish
Ethernet interfaces
2 × independent RJ45
Ethernet speed
10/100/1000 Mbps
PROFINET
2 interfaces supported
USB interfaces
2 × USB 3.0
Display interface
1 × DisplayPort
Expansion slots
0 × PCI
Power supply
24 V DC
Power-failure buffering
5 ms
Cooling
Fanless
Diagnostics
Temperature monitoring and watchdog
Status indicators
1 × power LED, 3 × user LEDs
Protection rating
IP40
Operating temperature
0–55 °C, depending on mounting conditions
Dimensions (W × H × D)
85 × 85 × 41 mm
Weight
Approximately 0.444 kg
Mounting accessories
Not included
Recommended Companion Models
Model
Product Name
Typical Application
6AG4021-0AA11-0AA0
SIMATIC IPC127E, Atom E3930, 2 GB RAM, 32 GB SSD, without OS
Base configuration for customized software installation
SIMATIC IPC127E, Atom E3940, 4 GB RAM, 64 GB SSD, Windows 10 Enterprise LTSB 2016
Quad-core processor and increased memory
6AG4021-0AB12-1CA0
SIMATIC IPC127E Extended, Atom E3940, 4 GB RAM, 128 GB SSD, Windows 10 Enterprise LTSB 2016
Higher processing capacity and expanded connectivity
Where It Supports Industrial Automation
Designed for compact industrial computing, machine monitoring, data acquisition, and industrial communication applications.
Integrates an Intel Atom E3930 dual-core processor with 2 GB DDR4 memory for lightweight embedded workloads.
Includes a 64 GB SSD and Windows 10 Enterprise LTSB 2016, 64-bit, for a ready-to-configure industrial software environment.
Provides two independent Gigabit Ethernet interfaces and two PROFINET interfaces for compatible industrial network integration.
Uses a compact, fanless Box PC design for installation in appropriately designed control cabinets and machinery.
Supports local monitoring and diagnostics through integrated temperature monitoring, watchdog functions, and status LEDs.
Key Benefits for Industrial Deployment
Preinstalled operating system: Windows 10 Enterprise LTSB 2016, 64-bit, includes multilingual support for English, German, French, Italian, and Spanish.
Compact industrial computing: The small enclosure is suitable for applications where cabinet space is limited.
Efficient embedded processing: The Intel Atom E3930 is suited to lightweight monitoring and industrial communication tasks.
Solid-state storage: The 64 GB SSD provides local storage for the operating system and compatible applications.
Industrial networking: Two independent RJ45 Ethernet interfaces support 10/100/1000 Mbps connections.
PROFINET communication: Supports integration with compatible industrial automation networks.
Fanless construction: Eliminates a cooling fan and reduces the number of moving parts.
Integrated diagnostics: Watchdog and temperature-monitoring functions assist with system supervision.
Flexible mounting: Supports suitable DIN-rail, wall, or portrait mounting arrangements with compatible accessories.
Technical FAQs
1. What is the Siemens 6AG4021-0AA11-1BA0?
It is a Siemens SIMATIC IPC127E industrial Box PC equipped with an Intel Atom E3930 processor, 2 GB RAM, a 64 GB SSD, and Windows 10 Enterprise LTSB 2016.
2. Which processor does this model use?
It uses an Intel Atom E3930 processor operating at 1.3 GHz with two cores and two threads.
3. How much memory is installed?
The system includes 2 GB of onboard DDR4 memory, with a maximum supported capacity of 2 GB for this configuration.
4. What storage capacity is provided?
The device includes a 64 GB solid-state drive for the operating system, industrial software, and local files.
5. Which operating system is preinstalled?
It includes Windows 10 Enterprise LTSB 2016, 64-bit, with multilingual user-interface support for English, German, French, Italian, and Spanish.
6. How many Ethernet interfaces are available?
The base version provides two independent RJ45 Ethernet interfaces supporting 10/100/1000 Mbps communication.
7. Does the IPC127E support PROFINET?
Yes. It supports PROFINET Real-Time communication through compatible Ethernet interfaces and software configurations.
8. Which USB and display interfaces are included?
The base version provides two USB 3.0 ports and one DisplayPort graphics interface.
9. What are the power and protection requirements?
The unit operates on 24 V DC, has approximately 5 ms of power-failure buffering, and provides IP40 enclosure protection.
10. Are mounting accessories included?
No. Mounting accessories are not included and should be selected according to the intended installation method.
