Siemens 6AG4021-0AA12-0BA0 SIMATIC IPC127E Industrial Box PC
Siemens 6AG4021-0AA12-0BA0 SIMATIC IPC127E Industrial Box PC
0.0
Points
Brand:Siemens Item No.:6AG4021-0AA12-0BA0 Product Origin: Germany Product Dimensions:85 × 104 × 41 mm Product Weight:0.72 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction to the SIMATIC IPC127E Extended Platform
The Siemens 6AG4021-0AA12-0BA0 is a compact industrial computer intended for applications that require embedded processing and multiple industrial communication connections. Its Intel Atom E3930 processor, 2 GB DDR4 memory, and 64 GB SSD provide a hardware foundation for lightweight data acquisition, monitoring, and edge gateway tasks.
Compared with the base IPC127E configuration, this extended version provides three Ethernet interfaces and four USB 3.0 ports. These additional connections can simplify integration with multiple network segments, industrial peripherals, and service equipment.
The fanless design and 24 V DC power input support installation in appropriately engineered industrial enclosures. Because the unit is supplied without an operating system or mounting accessories, software compatibility and installation requirements should be established before deployment.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order number
6AG4021-0AA12-0BA0
Product family
SIMATIC IPC127E
Device type
Industrial Box PC
Configuration
Extended version
Installation type
Built-in unit
Processor
Intel Atom E3930
Processor cores / threads
2 cores / 2 threads
Processor frequency
1.3 GHz
Installed memory
2 GB DDR4
Maximum memory
2 GB
Storage
64 GB SSD
Operating system
Not included
Ethernet interfaces
3 × RJ45
Ethernet speed
Up to 1 Gbps
PROFINET interfaces
3
USB interfaces
4 × USB 3.0
Display interface
1 × DisplayPort
Ethernet protocol
TCP/IP
PCI expansion slots
0
Power supply
24 V DC
Power-failure buffering
5 ms
Cooling
Fanless
Monitoring functions
Temperature monitoring and watchdog
Status indicators
1 × power LED, 3 × user LEDs
Protection rating
IP40
Operating temperature
0–55 °C
Dimensions (W × H × D)
85 × 104 × 41 mm
Weight
Approx. 0.72 kg; confirm packaged versus device weight
Mounting accessories
Not included
Recommended Companion Models
Model
Product Name
Typical Application
6AG4021-0AA11-0AA0
SIMATIC IPC127E, Atom E3930, 2 GB RAM, 32 GB SSD, base version
Compact applications requiring fewer interfaces
6AG4021-0AA11-1BA0
SIMATIC IPC127E, Atom E3930, 2 GB RAM, 64 GB SSD, Windows 10 Enterprise LTSB 2016
Applications requiring a preinstalled operating system
6AG4021-0AB11-0BA0
SIMATIC IPC127E, Atom E3940, 4 GB RAM, 64 GB SSD, base version
Applications requiring more processing power and memory
Where It Supports Industrial Automation and Edge Computing
Designed for industrial data collection, machine monitoring, communication gateways, and embedded automation applications.
Integrates an Intel Atom E3930 dual-core processor with 2 GB DDR4 memory for lightweight industrial workloads.
Includes a 64 GB SSD for local application files, configuration data, and industrial software.
Features an extended interface configuration with three Ethernet RJ45 ports and four USB 3.0 ports.
Supports PROFINET communication and TCP/IP networking for integration with compatible automation equipment.
Uses a compact, fanless enclosure suitable for space-constrained control cabinets and machine installations.
Supplied without an operating system, allowing integrators to select and configure compatible software.
Key Benefits for Industrial System Integration
Extended network connectivity: Three Ethernet interfaces support multiple industrial network connections and flexible communication architectures.
Additional USB connectivity: Four USB 3.0 ports accommodate compatible peripherals, service tools, and external devices.
Compact embedded design: The IPC127E platform is designed for installation close to production equipment with minimal space requirements.
Efficient processing: The Intel Atom E3930 processor supports lightweight edge computing, monitoring, and data-forwarding tasks.
Solid-state storage: The 64 GB SSD provides local storage without relying on mechanical hard drives.
Industrial communication: Three PROFINET interfaces support compatible industrial communication configurations.
Reduced maintenance requirements: Fanless cooling eliminates a moving component and supports low-maintenance operation.
Flexible installation: Compatible mounting arrangements include DIN-rail, wall, and portrait mounting, with mounting accessories ordered separately.
Technical FAQs
1. What is the Siemens 6AG4021-0AA12-0BA0?
It is a SIMATIC IPC127E industrial Box PC in the extended hardware configuration, designed for industrial networking, data acquisition, and embedded computing.
2. Which processor does this model use?
It uses an Intel Atom E3930 processor operating at 1.3 GHz with two cores and two threads.
3. How much memory is installed?
The unit includes 2 GB of DDR4 memory, with a maximum supported capacity of 2 GB for this configuration.
4. What storage capacity does it provide?
It includes a 64 GB solid-state drive for local software, configuration files, and application data.
5. Does the device include an operating system?
No. This model is supplied without an operating system, so a compatible operating environment must be installed separately.
6. How many Ethernet interfaces are available?
The extended version provides three RJ45 Ethernet interfaces supporting Gigabit Ethernet and TCP/IP communication.
7. Does the IPC127E support PROFINET?
Yes. The model supports three PROFINET interfaces for compatible industrial network configurations.
8. Which USB and display interfaces are included?
It provides four USB 3.0 ports and one DisplayPort graphics interface for compatible peripherals and displays.
9. What are the power and environmental requirements?
The device operates on 24 V DC, provides approximately 5 ms of power-failure buffering, and has an IP40 enclosure rating. Its specified operating temperature range is 0–55 °C, subject to installation conditions.
10. Are mounting accessories included?
No. Mounting accessories must be ordered separately according to the selected installation method.
