Siemens 6AG4021-0AB11-0BA0 SIMATIC IPC127E Industrial Box PC
Siemens 6AG4021-0AB11-0BA0 SIMATIC IPC127E Industrial Box PC
0.0
Points
Brand:Siemens Item No.: 6AG4021-0AB11-0BA0 Product Origin: Germany Product Dimensions:85 × 85 × 41 mm Product Weight:14 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4021-0AB11-0BA0 SIMATIC IPC127E is a compact industrial computer developed for automation, machine-level data processing, and industrial communication tasks. Its Intel Atom E3940 quad-core processor, 4 GB RAM, and 64 GB SSD provide a practical hardware platform for applications that need local processing and network connectivity in a small footprint.
Two independent Ethernet interfaces support industrial network integration, while USB 3.0 and DisplayPort provide connections for peripherals and local visualization. Integrated temperature monitoring and watchdog functions help support system diagnostics.
This base-version configuration is supplied without an operating system or mounting accessories. Before deployment, confirm software compatibility, storage requirements, network configuration, and the mounting hardware needed for the intended installation.
Technical Specifications
Specification
Details
Brand
Siemens
Product Series
SIMATIC IPC127E
Order Number
6AG4021-0AB11-0BA0
Product Type
Industrial Box PC
Version
Base version
Processor
Intel Atom E3940
Processor Frequency
1.6 GHz
Processor Cores / Threads
4 cores / 4 threads
Chipset
System-on-Chip (SoC)
Installed Memory
4 GB DDR4 RAM
Maximum Memory
4 GB
Storage
64 GB SSD
Operating System
Not preinstalled
Ethernet Interfaces
2 × independent RJ45
Ethernet Speed
10/100/1000 Mbps
PROFINET
Supported via standard Ethernet interfaces
USB Interfaces
2 × USB 3.0
Graphics Interface
1 × DisplayPort
Supply Voltage
24 V DC
Permitted Supply Range
19.2–28 V DC
Power-Failure Buffering
5 ms
Cooling
Fanless
Diagnostics
Temperature monitoring, watchdog, status LEDs
PCI Expansion Slots
0
Dimensions (W × H × D)
Approximately 85 × 85 × 41 mm
Mounting Accessories
Not included
Typical Applications
Industrial automation, machine control, data acquisition, industrial networking
More Ethernet and USB ports with increased storage
6AG4021-0AA11-0AA0
SIMATIC IPC127E, Atom E3930, 2 GB RAM, 32 GB SSD
Lower-specification base configuration
6AG4021-0AA20-0AA1
SIMATIC IPC127E DIN Rail Mounting Kit
Mounting accessory rather than a complete industrial PC
Industrial Computing for Automation and Control Applications
Designed for industrial automation, machine control, and compact computing applications.
Powered by an Intel Atom E3940 quad-core processor operating at 1.6 GHz.
Equipped with 4 GB DDR4 RAM and a 64 GB solid-state drive for industrial data processing and local storage.
Provides two independent Gigabit Ethernet RJ45 interfaces for industrial network communication.
Supports PROFINET communication through standard Ethernet interfaces.
Includes two USB 3.0 ports for connecting compatible peripherals and external devices.
Features a DisplayPort output for connecting a compatible monitor.
Operates from a 24 V DC power supply for integration into industrial control systems.
Key Benefits and Performance Features
Quad-core processing: The Intel Atom E3940 processor supports industrial control, data acquisition, and edge computing workloads.
Compact industrial design: The SIMATIC IPC127E box PC format helps conserve space in machinery and control cabinets.
Reliable solid-state storage: The 64 GB SSD provides local storage without relying on a mechanical hard drive.
Industrial network connectivity: Two independent Ethernet interfaces support communication with automation equipment and industrial networks.
PROFINET support: Facilitates integration into compatible Siemens automation architectures.
Integrated graphics output: DisplayPort enables local visualization, monitoring, and maintenance interfaces.
Fanless construction: The system uses a fanless design, reducing moving parts and maintenance requirements.
Integrated diagnostics: Temperature monitoring and watchdog functions support system supervision.
Flexible installation: Compatible mounting approaches for the IPC127E family include DIN rail, wall, and portrait mounting, with mounting accessories selected separately.
Operating system flexibility: This configuration is supplied without a preinstalled operating system, allowing the user to plan software deployment according to project requirements.
Technical FAQs
1. What is Siemens 6AG4021-0AB11-0BA0?
It is a Siemens SIMATIC IPC127E industrial box PC featuring an Intel Atom E3940 processor, 4 GB RAM, a 64 GB SSD, and no preinstalled operating system.
2. Which processor does this industrial PC use?
The device uses an Intel Atom E3940 processor running at 1.6 GHz with four cores and four threads.
3. How much memory and storage are included?
This configuration includes 4 GB of onboard DDR4 RAM and a 64 GB solid-state drive.
4. Which Ethernet interfaces are available?
The base version provides two independent RJ45 Ethernet interfaces supporting 10/100/1000 Mbps communication.
5. Does the IPC127E support PROFINET?
Yes. PROFINET real-time communication is supported through standard Ethernet interfaces, subject to the selected software and automation configuration.
6. Which USB and display connections are provided?
The device includes two USB 3.0 ports and one DisplayPort graphics interface.
7. What power supply does the unit require?
The IPC127E operates on 24 V DC. The specified supply range for the product family is 19.2–28 V DC.
8. Does this model include a Windows operating system?
No. The 6AG4021-0AB11-0BA0 configuration is supplied without a preinstalled operating system. The required operating system and software must be selected separately.
9. Is the IPC127E suitable for continuous industrial operation?
It is designed for industrial applications and includes monitoring functions such as temperature supervision and a watchdog. Suitability for a specific duty cycle depends on environmental conditions, application requirements, and the applicable installation guidelines.
10. Are mounting accessories included with this model?
No. This configuration is specified without mounting accessories. Select compatible mounting hardware separately according to the required installation method.
