The Siemens SIMATIC IPC547G Industrial Rack PC is a ruggedized computing platform developed for industrial automation, process monitoring, and equipment integration. Its rack-based design combines conventional PC processing with a broad selection of expansion and communication interfaces, making it suitable for applications that require specialized hardware alongside industrial software.

A key characteristic of the IPC547G platform is its balance between standard computing components and industrial integration features. The availability of PCI Express and PCI expansion slots allows engineers to retain compatible interface cards and established application hardware rather than redesigning an entire system around a smaller computer.

The product family includes configurations with different processors, memory capacities, storage options, and operating systems. Because the suffix of the order number determines the supplied configuration, the specifications of one IPC547G variant should not automatically be applied to another.

For procurement, maintenance, or replacement projects involving 6AG4104-4CA10-0JX3, confirm the original equipment label and configuration record before ordering compatible components or planning a system migration.

5. Technical Specifications

The following table combines documented IPC547G family characteristics with a clear distinction between confirmed family-level information and unverified details for the exact order number.

Parameter	Specification
Manufacturer	Siemens
Product family	SIMATIC IPC547G
Order number	6AG4104-4CA10-0JX3
Product type	Industrial Rack PC
Rack format	19-inch, 4U
Processor	Exact processor for this order number not independently verified
Supported family processors	Intel Pentium G4400, Core i5-6500, Core i7-6700, Xeon E3-1275 v5, depending on configuration
Motherboard chipset	Intel H110 or Intel C236, depending on configuration
Memory technology	DDR4 SDRAM
Installed memory	To be verified for this exact order number
Storage	Configuration-dependent; HDD, SSD, and selected RAID arrangements were available in the family
Ethernet	2 × Intel Gigabit Ethernet on documented family configurations
Front USB	2 × USB 3.0 on documented family configurations
Rear USB	Depends on motherboard configuration
Display interfaces	Configuration-dependent; documented family options include DVI-D and DisplayPort
PS/2 interfaces	2 on documented family configurations
Audio	Rear audio interfaces on documented family configurations
Expansion slots	5 × PCI Express and 2 × PCI
Graphics	Integrated graphics or optional dedicated graphics, depending on configuration
Power input	100–240 V AC on documented family configurations
Redundant power supply	Available on selected configurations; unverified for this exact order number
System monitoring	Temperature and fan monitoring
Watchdog	Supported by the IPC547G family
Standard enclosure dimensions (W × H × D)	481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)	481.4 × 176.6 × 356.6 mm
Weight	Approximately 15–23 kg across family configurations; exact weight depends on installed equipment
Operating system	Depends on the supplied configuration
Mounting	Rack installation; additional accessories may be required for alternative mounting arrangements

Configuration caution: The dimensions and weight above describe the IPC547G family. The exact enclosure variant and shipping weight of 6AG4104-4CA10-0JX3 should be verified before installation, transport, or cabinet-layout planning.

6. Recommended Related Models

The following SIMATIC IPC547G variants are documented configurations that may be useful when comparing hardware, sourcing replacements, or evaluating a system upgrade. They are not asserted to be direct drop-in replacements for 6AG4104-4CA10-0JX3.

Model	Configuration highlights	Potential relevance
6AG4104-4CA01-0XX1	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, onboard graphics, no operating system	Reference configuration for a conventional IPC547G system
6AG4104-4CA12-1DX1	Core i5-6500, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 10 Enterprise 2016 LTSB	Useful for comparing memory and operating-system configurations
6AG4104-4DA12-3BX2	Core i7-6700, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 7 Ultimate	Higher-tier processor configuration within the family
6AG4104-4GA12-2DX1	Core i5-6500, C236 chipset, 8 GB DDR4, 1 TB HDD, dual-head graphics card, Windows 10 Enterprise 2016 LTSB	Relevant where a C236 platform and additional display capability are needed
6AG4104-4GK13-1BX2	Core i5-6500, C236 chipset, 8 GB DDR4, front-access 480 GB SSD, redundant AC power supplies	Useful for comparing front-access storage and power redundancy

The IPC547G generation includes legacy configurations, and some part numbers have been discontinued. Before selecting an alternative, verify the required interfaces, storage arrangement, software compatibility, and power-supply design.

7. Popular Related Models

These additional IPC547G variants cover different storage, memory, and power arrangements and may be relevant to maintenance or procurement comparisons.

Model	Configuration highlights	Typical reason to compare
6AG4104-4CA04-0BX0	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, DVD±RW, redundant AC power supplies, Windows 7 Ultimate	Comparison for systems requiring redundant power
6AG4104-4EN16-3XX0	Pentium G4400, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, COM2 and LPT, no operating system	Comparison for legacy peripherals and mirrored storage
6AG4104-4GN16-4BX0	Core i5-6500, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, Windows 7 Ultimate	Comparison for a mirrored-storage configuration
6AG4104-4CC20-0XX1	Core i5-6500, H110 chipset, 16 GB DDR4, 240 GB SSD, short enclosure, no operating system	Comparison for a short-depth chassis and SSD storage
6AG4104-4CA00-0BX2	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, short enclosure, Windows 7 Ultimate	Reference for a short-enclosure configuration

1. Applications

The SIMATIC IPC547G platform is suitable for industrial applications that need a rack-mounted computer with flexible I/O and expansion capability.

Factory automation: Hosts supervisory applications, production monitoring, and machine-control software.
SCADA and HMI systems: Supports visualization, operator interfaces, and process data management.
Industrial data acquisition: Collects and processes information from controllers, sensors, and connected equipment.
Machine vision and inspection: Can accommodate compatible expansion cards and graphics hardware, depending on the installed configuration.
Test and measurement systems: Provides a rack-based computing platform for automated testing and data analysis.
Industrial networking: Supports Ethernet-based communication between applications, controllers, and plant systems.
Legacy system maintenance: Can serve as a replacement platform where existing software and hardware depend on the IPC547G generation.

Advantages

Flexible Expansion for Industrial Systems

The IPC547G provides seven expansion slots, including five PCI Express slots and two PCI slots. This layout allows compatible interface cards, fieldbus adapters, data-acquisition hardware, and other peripherals to be integrated into a single rack-mounted system.

Multiple Connectivity Options

The platform includes two Gigabit Ethernet interfaces, front-access USB 3.0 ports, PS/2 connections, and rear audio interfaces. Additional display and USB connections depend on the installed motherboard configuration.

Designed for Industrial Operation

Temperature and fan monitoring help operators identify thermal or cooling issues. The integrated watchdog function can support application recovery strategies when appropriately configured in the system software.

Rack Installation Versatility

The 19-inch, 4U enclosure is designed for equipment racks and can support horizontal or vertical installation under the specified mounting conditions. Optional mounting accessories may be required for particular installation arrangements.

Configuration Choices

The IPC547G family was offered with different processors, memory capacities, storage arrangements, graphics options, and power-supply configurations. This flexibility makes it useful for maintaining established industrial applications, although compatibility must be checked before replacing an existing unit.

Practical for Legacy-System Support

For plants running validated software or relying on older PCI-based hardware, retaining a compatible IPC547G configuration can reduce the engineering effort associated with a complete platform migration.

Technical FAQs

Q1. What type of computer is the Siemens 6AG4104-4CA10-0JX3?
It is identified as an order number in the SIMATIC IPC547G industrial rack PC series. The exact configuration associated with this complete part number has not been independently confirmed.

Q2. How many expansion slots does the IPC547G provide?
The IPC547G family provides seven expansion slots: five PCI Express and two PCI. The compatibility of a particular card depends on the slot type, dimensions, power requirements, and system configuration.

Q3. Does this computer support Gigabit Ethernet?
The IPC547G family includes two Intel Gigabit Ethernet interfaces. Verify the specific unit’s configuration and interface condition before commissioning.

Q4. What processors are available across the IPC547G family?
Documented family configurations include Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processors. These are family-level options, not a confirmed specification for the exact order number in this article.

Q5. Which memory technology does the IPC547G use?
Documented IPC547G configurations use DDR4 SDRAM. Installed capacity and memory arrangement vary by order number, so the actual unit should be checked before planning an upgrade.

Q6. Does the IPC547G support RAID?
Selected configurations provide onboard RAID functionality and may be supplied with RAID 1 or RAID 5 storage arrangements. RAID support and the installed drive layout must be confirmed for the specific unit.

Q7. Can an additional graphics card be installed?
The family supports compatible PCI Express graphics options in certain configurations. Available slots, card dimensions, power requirements, and display outputs should be checked before installation.

Q8. Does the IPC547G have a watchdog function?
Yes. The family includes a watchdog function that can support system supervision. Its practical behavior depends on the application, operating system, driver support, and watchdog configuration.

Q9. What power supply does the IPC547G use?
The family supports 100–240 V AC input. Certain configurations have redundant power supplies, but redundancy should not be assumed for the 6AG4104-4CA10-0JX3 without verifying its installed hardware.

Q10. What should be checked before replacing an existing IPC547G?
Compare the processor, motherboard chipset, memory, storage layout, operating system, expansion cards, display interfaces, network connections, power supply, and mounting arrangement. Matching the full order number is preferable to comparing the product family name alone.
