Name: Siemens 6AG4104-4CA10-0XX1 – SIMATIC IPC547G Industrial Rack PC
Brand: Siemens
SKU: 22893
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Siemens SIMATIC IPC547G is an industrial rack computer intended for automation and industrial computing tasks that benefit from a conventional PC architecture and extensive expansion capability. Its 19-inch, 4U design makes it suitable for integration into control cabinets, equipment racks, and centralized industrial computing installations.

Unlike compact embedded computers with limited expansion options, the IPC547G accommodates both PCI Express and legacy PCI hardware. This is particularly useful in applications that depend on established interface cards, specialized acquisition devices, or existing industrial software.

The platform was supplied in multiple configurations, ranging from basic systems with integrated graphics and hard-disk storage to more specialized versions with different processors, additional memory, RAID storage, dedicated graphics, or redundant power supplies.

For the requested 6AG4104-4CA10-0XX1, the exact configuration remains unverified. The closely matching 6AG4104-4CA01-0XX1 is documented as an Intel Core i5-6500 system with 4 GB DDR4 memory, a 1 TB HDD, onboard graphics, and no operating system. These specifications should not be automatically transferred to the requested number without checking the original product label.

5. Technical Specifications

The table below distinguishes the documented details of the closely matching Siemens model from general IPC547G family characteristics.

Parameter	Specification
Manufacturer	Siemens
Product family	SIMATIC IPC547G
Requested order number	6AG4104-4CA10-0XX1
Exact order-number verification	Not independently confirmed
Closely matching documented model	6AG4104-4CA01-0XX1
Product type	Industrial Rack PC
Rack format	19-inch, 4U
Processor of documented matching model	Intel Core i5-6500
Processor cores / threads	4 / 4
Processor frequency	3.2 GHz base, up to 3.6 GHz
Processor cache	6 MB
Motherboard chipset of matching model	Intel H110
Installed memory of matching model	4 GB DDR4 SDRAM, single channel
Storage of matching model	1 × 1 TB internal HDD
Graphics of matching model	Integrated graphics
Display interfaces of matching model	1 × DVI-D, 1 × DisplayPort 1.2
Front USB	2 × USB 3.0
Rear USB of documented H110 configuration	2 × USB 3.0, 4 × USB 2.0
Ethernet	2 × Intel Gigabit Ethernet
Other interfaces	2 × PS/2; rear audio interfaces
Expansion slots	5 × PCI Express, 2 × PCI
Monitoring features	Temperature and fan monitoring
Watchdog	Supported
Power input	100–240 V AC
Redundant power supply	Available on selected family configurations; not confirmed for the requested model
Standard enclosure dimensions (W × H × D)	481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)	481.4 × 176.6 × 356.6 mm
Family weight range	Approximately 15–23 kg, depending on configuration
Operating system of matching model	None supplied
Exact weight and enclosure of requested model	Not independently verified

Note: Dimensions and weight are documented for the IPC547G family. The actual enclosure type and installed hardware should be confirmed before rack planning or shipment arrangements.

6. Recommended Related Models

The following documented IPC547G configurations are useful comparison points when evaluating replacements, storage options, or changes in computing requirements.

Model	Configuration highlights	Recommended use
6AG4104-4CA01-0XX1	Core i5-6500, H110, 4 GB DDR4, 1 TB HDD, onboard graphics, no operating system	Closest documented comparison to the requested model
6AG4104-4CA12-1DX1	Core i5-6500, H110, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 10 Enterprise 2016 LTSB	Comparison for higher installed memory and a preinstalled operating system
6AG4104-4DA12-3BX2	Core i7-6700, H110, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 7 Ultimate	Alternative processor configuration for more demanding workloads
6AG4104-4GA12-2DX1	Core i5-6500, C236, 8 GB DDR4, 1 TB HDD, dedicated dual-head graphics, Windows 10 Enterprise 2016 LTSB	Comparison for applications needing a dedicated graphics card
6AG4104-4GK13-1BX2	Core i5-6500, C236, 8 GB DDR4, front-access 480 GB SSD, redundant AC power supplies	Comparison for front-access storage and power redundancy

These models are not guaranteed drop-in replacements. Check the installed expansion cards, software dependencies, storage requirements, and power configuration before selecting an alternative.

7. Popular Related Models

These additional IPC547G variants offer different combinations of storage, chassis design, and power options for industrial maintenance and procurement comparisons.

Model	Configuration highlights	Key distinction
6AG4104-4CA04-0BX0	Core i5-6500, H110, 4 GB DDR4, 1 TB HDD, DVD±RW, redundant AC power supplies, Windows 7 Ultimate	Redundant power configuration
6AG4104-4EN16-3XX0	Pentium G4400, C236, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, COM2 and LPT, no operating system	Legacy interfaces and mirrored storage
6AG4104-4GN16-4BX0	Core i5-6500, C236, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, Windows 7 Ultimate	RAID 1 storage configuration
6AG4104-4CC20-0XX1	Core i5-6500, H110, 16 GB DDR4, 240 GB SSD, short enclosure, no operating system	Higher memory capacity and reduced enclosure depth
6AG4104-4CA00-0BX2	Core i5-6500, H110, 4 GB DDR4, 1 TB HDD, short enclosure, Windows 7 Ultimate	Short-depth rack installation

Applications

The IPC547G provides a flexible computing platform for industrial systems where expansion capability, wired networking, and rack installation are important.

Factory automation: Runs supervisory software, production monitoring tools, and machine-level applications.
SCADA and HMI systems: Supports visualization, operator interfaces, alarms, and process data management.
Industrial data acquisition: Processes information from measurement equipment, sensors, and connected controllers.
Machine vision and inspection: Supports compatible graphics hardware and specialized interface cards for inspection applications.
Automated testing: Provides computing resources for test benches, measurement stations, and engineering validation systems.
Industrial networking: Connects automation equipment and applications through its Ethernet interfaces.
Legacy equipment integration: Offers PCI and PCI Express expansion options for maintaining systems that rely on established industrial cards.

Advantages

Expansion Flexibility

With five PCI Express slots and two PCI slots in documented IPC547G configurations, the platform can accommodate a range of compatible industrial interface cards, communication adapters, and data-acquisition devices.

Industrial Connectivity

Two Gigabit Ethernet ports support wired network integration. Front USB ports, PS/2 connections, and rear audio interfaces provide additional connectivity for maintenance peripherals and compatible equipment.

Rack-Based Installation

The 19-inch, 4U chassis fits standard industrial equipment racks. Depending on the installation arrangement and accessories, the platform can also support alternative mounting configurations described in the product documentation.

Hardware Monitoring

Temperature and fan monitoring features help identify operating conditions that may affect system reliability. The integrated watchdog can support software-based system supervision when correctly configured.

Multiple Hardware Configurations

The IPC547G family was offered with different processors, memory capacities, storage devices, graphics options, and power-supply arrangements. This range allows engineers to select a configuration that suits the demands of an established application.

Suitable for Industrial Maintenance

For systems with validated software and specialized expansion cards, maintaining a compatible IPC547G can reduce the effort associated with migrating to a different computer platform. Compatibility should still be assessed before replacement.

Technical FAQs

Q1. What is the Siemens 6AG4104-4CA10-0XX1?
The supplied number could not be confirmed exactly in the available product records. The closely matching Siemens order number 6AG4104-4CA01-0XX1 identifies a SIMATIC IPC547G industrial rack PC.

Q2. What processor is installed in the closely matching 6AG4104-4CA01-0XX1 configuration?
The documented configuration uses an Intel Core i5-6500 processor with four cores and four threads, a 3.2 GHz base frequency, up to 3.6 GHz turbo frequency, and 6 MB cache.

Q3. How many expansion slots does the IPC547G provide?
The platform provides seven expansion slots in documented configurations: five PCI Express and two PCI. The supported card types and lane arrangements depend on the motherboard configuration.

Q4. How many Ethernet interfaces are available?
Documented IPC547G configurations include two Intel Gigabit Ethernet interfaces. Confirm the installed motherboard and interface condition when inspecting a used unit.

Q5. Which memory technology does the platform use?
Documented IPC547G configurations use DDR4 SDRAM. The closely matching 6AG4104-4CA01-0XX1 configuration has 4 GB installed as a single 4 GB module.

Q6. What storage device is included in the 6AG4104-4CA01-0XX1 configuration?
The documented configuration includes one internal 1 TB hard disk drive. Storage arrangements vary across the broader IPC547G family.

Q7. Which display connections are available?
The closely matching H110-based configuration includes one DVI-D port and one DisplayPort 1.2 connection, using the processor's integrated graphics. Other IPC547G configurations may include optional dedicated graphics cards.

Q8. What power input does the IPC547G support?
The documented platform supports 100–240 V AC input. Redundant power supplies were available in selected configurations, but they should not be assumed to be installed in every unit.

Q9. Does the IPC547G support both PCI and PCI Express cards?
Yes. The family includes both interface types. Before installing a card, check the motherboard's slot arrangement, card dimensions, power requirements, and software or driver compatibility.

Q10. What should be checked before purchasing a replacement unit?
Confirm the complete order number, processor, memory, storage configuration, operating system, graphics hardware, expansion cards, power-supply arrangement, and enclosure type. Because the requested number differs from the closely matching documented Siemens number, the equipment nameplate or original ordering documentation should be checked first.
