Name: Siemens 6AG4104-4CA10-0XX3 – SIMATIC IPC547G Industrial Rack PC
Brand: Siemens
SKU: 22895
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Siemens SIMATIC IPC547G is a rack-mounted industrial computer intended for automation, data processing, and industrial control environments. It combines conventional PC computing capabilities with expansion options and connectivity suited to installations where specialized hardware must operate alongside industrial software.

Its principal strength is the ability to accommodate a variety of compatible expansion cards while retaining a familiar rack-based design. This makes the platform relevant to machine builders, system integrators, and maintenance teams responsible for established production systems.

Across the IPC547G family, Siemens offered different processor generations, memory capacities, storage configurations, graphics options, and power-supply arrangements. Consequently, the family name alone does not establish the complete specification of an individual unit.

For 6AG4104-4CA10-0XX3, the precise hardware configuration should be confirmed using the equipment nameplate or original Siemens ordering documentation before procurement, replacement, or system integration.

5. Technical Specifications

The following table summarizes documented IPC547G family characteristics. Values that depend on the individual order number are marked accordingly.

Parameter	Technical specification
Manufacturer	Siemens
Product family	SIMATIC IPC547G
Order number	6AG4104-4CA10-0XX3
Exact configuration verification	Not independently confirmed
Product type	Industrial Rack PC
Rack format	19-inch, 4U
Supported family processors	Intel Pentium G4400, Core i5-6500, Core i7-6700, Xeon E3-1275 v5, depending on configuration
Motherboard chipset	Intel H110 or Intel C236, depending on configuration
Memory technology	DDR4 SDRAM
Installed memory	Configuration-dependent
Storage	HDD, SSD, or selected RAID configurations, depending on model
Ethernet interfaces	2 × Intel Gigabit Ethernet on documented configurations
Front USB	2 × USB 3.0
Rear USB	Configuration-dependent; H110 and C236 variants differ
Display interfaces	Configuration-dependent; documented options include DVI-D and DisplayPort
PS/2 interfaces	2 on documented configurations
Audio	Rear audio interfaces
Expansion slots	5 × PCI Express, 2 × PCI
Graphics	Integrated graphics or optional dedicated graphics
System monitoring	Temperature and fan monitoring
Watchdog	Supported
Power input	100–240 V AC on documented configurations
Redundant power supply	Available on selected configurations
Standard enclosure dimensions (W × H × D)	481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)	481.4 × 176.6 × 356.6 mm
Family weight range	Approximately 15–23 kg, depending on equipment
Operating system	Configuration-dependent
Exact enclosure and weight for requested model	Not independently verified

Installation note: The dimensions and weight are family-level specifications. Confirm whether the actual unit uses the standard or short enclosure and check its installed equipment before planning rack clearance, lifting, or shipping.

6. Recommended Related Models

The following documented IPC547G configurations provide useful comparison points for replacement planning, performance evaluation, and industrial system maintenance.

Model	Configuration highlights	Recommended comparison
6AG4104-4CA01-0XX1	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, onboard graphics, no operating system	Basic IPC547G configuration for hardware comparison
6AG4104-4CA12-1DX1	Core i5-6500, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 10 Enterprise 2016 LTSB	Alternative with increased memory and a preinstalled operating system
6AG4104-4DA12-3BX2	Core i7-6700, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 7 Ultimate	Higher-performance processor option within the family
6AG4104-4GA12-2DX1	Core i5-6500, C236 chipset, 8 GB DDR4, 1 TB HDD, dedicated dual-head graphics, Windows 10 Enterprise 2016 LTSB	Comparison for applications requiring dedicated graphics
6AG4104-4GK13-1BX2	Core i5-6500, C236 chipset, 8 GB DDR4, front-access 480 GB SSD, redundant AC power supplies	Alternative with front-access storage and power redundancy

These models are not guaranteed direct replacements for 6AG4104-4CA10-0XX3. Compare the complete hardware configuration, installed software, expansion requirements, and power arrangement before selecting a substitute.

7. Popular Related Models

The additional variants below cover different industrial storage and power configurations within the IPC547G family.

Model	Configuration highlights	Distinguishing feature
6AG4104-4CA04-0BX0	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, DVD±RW, redundant AC power supplies, Windows 7 Ultimate	Redundant power-supply configuration
6AG4104-4EN16-3XX0	Pentium G4400, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, COM2 and LPT, no operating system	Legacy interfaces and mirrored storage
6AG4104-4GN16-4BX0	Core i5-6500, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, Windows 7 Ultimate	RAID 1 storage configuration
6AG4104-4CC20-0XX1	Core i5-6500, H110 chipset, 16 GB DDR4, 240 GB SSD, short enclosure, no operating system	Higher memory capacity and reduced enclosure depth
6AG4104-4CA00-0BX2	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, short enclosure, Windows 7 Ultimate	Short-depth rack configuration

Applications

The SIMATIC IPC547G provides a versatile computing foundation for industrial applications that require standard PC functionality and specialized hardware integration.

Factory automation: Runs production monitoring, supervisory applications, and machine-level software.
SCADA and HMI systems: Supports operator interfaces, process visualization, alarm handling, and data logging.
Industrial data acquisition: Processes information from sensors, measurement equipment, and connected controllers.
Machine vision: Accommodates compatible graphics and interface cards for inspection and image-processing applications.
Automated testing: Provides a rack-mounted platform for test benches, measurement systems, and engineering validation.
Industrial networking: Connects applications and equipment through Gigabit Ethernet and compatible expansion interfaces.
Legacy equipment integration: Supports systems that depend on compatible PCI or PCI Express cards and established software environments.

Advantages

Expansion for Specialized Hardware

The IPC547G family provides seven expansion slots in documented configurations: five PCI Express and two PCI. This arrangement supports the integration of compatible industrial communication cards, data-acquisition hardware, and other specialized peripherals.

Flexible Industrial Connectivity

Two Intel Gigabit Ethernet interfaces support wired network communication. Front USB 3.0 ports, PS/2 connections, and rear audio interfaces provide additional connectivity for maintenance equipment and compatible peripherals.

Rack-Mount Integration

The 19-inch, 4U chassis is designed for installation in industrial equipment racks. Depending on the installation arrangement and available accessories, the platform can also support other mounting configurations described in its technical documentation.

System Monitoring Functions

Temperature and fan monitoring help operators identify potential cooling issues. The integrated watchdog supports system-supervision strategies when appropriately configured in the operating system and application software.

Multiple Configuration Options

The IPC547G family was available with different processors, memory capacities, storage arrangements, graphics options, and power-supply designs. This flexibility allows the hardware to be selected for a range of industrial computing requirements.

Support for Established Industrial Systems

For installations that rely on validated software or specialized expansion cards, maintaining a compatible IPC547G configuration can simplify ongoing maintenance and reduce the disruption associated with replacing an entire computing platform.

Technical FAQs

Q1. What is the Siemens 6AG4104-4CA10-0XX3?
It is an order number that could not be independently verified against an exact configuration record. The IPC547G family is a Siemens industrial rack PC platform intended for automation and industrial computing applications.

Q2. Which processors are supported by the IPC547G family?
Documented configurations include Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processors. The installed processor for the requested order number must be confirmed separately.

Q3. How many expansion slots are available?
Documented IPC547G configurations provide five PCI Express slots and two PCI slots. Actual card compatibility depends on the motherboard, slot arrangement, card dimensions, and power requirements.

Q4. Does the IPC547G support industrial Ethernet communication?
Yes. Documented configurations include two Intel Gigabit Ethernet interfaces. Network settings, drivers, and application-level communication protocols depend on the installed operating system and software.

Q5. What memory technology does the IPC547G use?
The family uses DDR4 SDRAM. Installed memory capacity and module arrangement vary by configuration, so the actual hardware should be inspected before planning an upgrade.

Q6. What storage options are available?
The IPC547G family was offered with internal HDDs, SSD-based configurations, and selected RAID arrangements. The storage devices and controller configuration for 6AG4104-4CA10-0XX3 remain unverified.

Q7. Which display interfaces may be available?
Documented configurations include DVI-D and DisplayPort. Certain versions also support optional dedicated graphics hardware. The available ports depend on the motherboard and installed graphics configuration.

Q8. Does the IPC547G support redundant power supplies?
Redundant 100–240 V AC power supplies were available in selected configurations. Their presence in the requested unit cannot be established from the order number information available here.

Q9. What monitoring and protection features does the system provide?
The IPC547G family includes temperature and fan monitoring, a watchdog function, and a card retainer. These features assist system supervision and hardware installation, but they do not replace appropriate application-level fault handling.

Q10. What should be checked before integrating this computer into an existing control system?
Verify the complete order number, processor, memory, storage, operating system, expansion cards, display outputs, network interfaces, and power-supply arrangement. Also check software and driver compatibility before deploying the system.
