Name: Siemens 6AG4104-4CA10-1XX3 – SIMATIC IPC547G Industrial Rack PC
Brand: Siemens
SKU: 22896
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Siemens SIMATIC IPC547G is an industrial rack computer designed to provide conventional PC computing capabilities in a format suited to industrial installations. Its expansion architecture and connectivity options make it useful for applications where standard computing resources must work alongside specialized automation hardware.

The platform supports a range of industrial workloads, from process visualization and data acquisition to testing and equipment supervision. The combination of PCI Express and PCI slots is particularly relevant when maintaining systems that use established interface cards or require hardware not readily accommodated by compact embedded computers.

Different IPC547G order numbers represent different combinations of processor, memory, storage, graphics, operating system, and power supply. These differences can affect both system performance and compatibility with an existing installation.

For 6AG4104-4CA10-1XX3, the exact configuration should be established from the product nameplate or original order documentation before purchasing replacement parts or planning a migration. Family-level specifications provide a useful starting point but should not be treated as confirmation of the individual unit's hardware.

5. Technical Specifications

The following specifications describe the documented IPC547G family. Configuration-dependent items are identified to avoid attributing unverified components to the requested order number.

Parameter	Specification
Manufacturer	Siemens
Product family	SIMATIC IPC547G
Order number	6AG4104-4CA10-1XX3
Exact configuration status	Not independently verified
Product type	Industrial Rack PC
Rack format	19-inch, 4U
Processor options across family	Pentium G4400, Core i5-6500, Core i7-6700, Xeon E3-1275 v5, depending on configuration
Motherboard chipset	Intel H110 or Intel C236, depending on configuration
Memory technology	DDR4 SDRAM
Installed memory	Model-dependent
Storage	HDD, SSD, or selected RAID arrangements
Front USB interfaces	2 × USB 3.0 on documented configurations
Ethernet interfaces	2 × Intel Gigabit Ethernet
Rear USB interfaces	Configuration-dependent
Display interfaces	Configuration-dependent; documented options include DVI-D and DisplayPort
PS/2 interfaces	2 on documented configurations
Audio interfaces	Rear audio connections
Expansion slots	5 × PCI Express, 2 × PCI
Graphics	Integrated or dedicated graphics, depending on configuration
System monitoring	Temperature and fan monitoring
Watchdog	Supported
Power input	100–240 V AC on documented configurations
Redundant power supply	Available on selected variants
Standard enclosure dimensions (W × H × D)	481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)	481.4 × 176.6 × 356.6 mm
Family weight range	Approximately 15–23 kg, depending on equipment
Operating system	Configuration-dependent
Exact enclosure and weight for this order number	Not independently verified

Technical note: The enclosure dimensions and weight are documented at the IPC547G family level. Confirm the actual chassis version and installed hardware before planning cabinet space, transport, or installation.

6. Recommended Related Models

The following documented IPC547G configurations offer useful comparison points for maintenance, replacement planning, and hardware evaluation.

Model	Configuration highlights	Recommended application
6AG4104-4CA01-0XX1	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, onboard graphics, no operating system	Basic IPC547G hardware reference
6AG4104-4CA12-1DX1	Core i5-6500, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 10 Enterprise 2016 LTSB	Comparison for increased memory and an installed operating system
6AG4104-4DA12-3BX2	Core i7-6700, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 7 Ultimate	Alternative for higher processor performance
6AG4104-4GA12-2DX1	Core i5-6500, C236 chipset, 8 GB DDR4, 1 TB HDD, dedicated dual-head graphics, Windows 10 Enterprise 2016 LTSB	Comparison for applications requiring dedicated graphics
6AG4104-4GK13-1BX2	Core i5-6500, C236 chipset, 8 GB DDR4, front-access 480 GB SSD, redundant AC power supplies	Alternative with front-access storage and power redundancy

These models are comparison candidates, not guaranteed direct replacements. Verify the target application's hardware, software, and interface requirements before choosing an alternative.

7. Popular Related Models

The following IPC547G variants provide additional reference points for storage design, power configuration, and chassis requirements.

Model	Configuration highlights	Main distinction
6AG4104-4CA04-0BX0	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, DVD±RW, redundant AC power supplies, Windows 7 Ultimate	Redundant power arrangement
6AG4104-4EN16-3XX0	Pentium G4400, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, COM2 and LPT, no operating system	Legacy interfaces and mirrored storage
6AG4104-4GN16-4BX0	Core i5-6500, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, Windows 7 Ultimate	Mirrored storage configuration
6AG4104-4CC20-0XX1	Core i5-6500, H110 chipset, 16 GB DDR4, 240 GB SSD, short enclosure, no operating system	Increased memory and shorter chassis
6AG4104-4CA00-0BX2	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, short enclosure, Windows 7 Ultimate	Short-depth rack installation

Applications

The IPC547G is suited to industrial environments where computing performance, expansion flexibility, and compatibility with existing equipment are important.

Factory automation: Runs production monitoring, supervisory applications, and machine-level software.
SCADA and HMI: Supports process visualization, operator interfaces, alarms, and operational data logging.
Industrial data acquisition: Processes information from sensors, measurement instruments, and connected controllers.
Machine vision and inspection: Can accommodate compatible graphics and interface cards for inspection and image-processing workloads.
Automated testing: Provides a rack-based platform for test benches, measurement systems, and engineering validation.
Industrial networking: Connects applications and automation equipment through Ethernet and compatible expansion interfaces.
Legacy system maintenance: Supports compatible PCI and PCI Express hardware used in established industrial installations.

Advantages

Flexible Expansion Architecture

The documented IPC547G platform provides seven expansion slots: five PCI Express and two PCI. This arrangement allows engineers to integrate compatible communication adapters, data-acquisition cards, and specialized industrial peripherals.

Reliable Wired Connectivity

Two Intel Gigabit Ethernet interfaces support network communication between the computer, automation equipment, and supervisory systems. Front USB 3.0 ports and additional peripheral connections simplify maintenance and equipment integration.

Industrial Rack Integration

The 19-inch, 4U chassis is designed for equipment racks and industrial control cabinets. Its standard enclosure provides space for expansion hardware while maintaining a conventional rack-mounted footprint.

Built-In Monitoring Functions

Temperature and fan monitoring help identify operating conditions that could affect system stability. The watchdog function can support application-level recovery strategies when configured with compatible software.

Configuration Versatility

The IPC547G family was offered with different processors, memory capacities, storage devices, graphics options, and power-supply arrangements. This makes it possible to match the computer to a range of industrial workloads, although the exact configuration must be checked for each order number.

Practical for Established Installations

Where validated software and specialized expansion cards are already in use, a compatible IPC547G can help preserve the existing system architecture and reduce the effort required for a complete platform migration.

Technical FAQs

Q1. What type of equipment is the Siemens 6AG4104-4CA10-1XX3?
The exact order number has not been verified. The related SIMATIC IPC547G product family consists of industrial rack PCs designed for automation, monitoring, and industrial computing applications.

Q2. Which processors are available in the IPC547G family?
Documented configurations include Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processors. The processor installed in the requested model remains unconfirmed.

Q3. How many expansion slots does the IPC547G support?
Documented family configurations provide five PCI Express slots and two PCI slots. Check the specific motherboard and slot arrangement before selecting expansion cards.

Q4. Does the IPC547G provide Gigabit Ethernet?
Yes. Documented configurations include two Intel Gigabit Ethernet interfaces for wired industrial networking.

Q5. Which memory technology does the system use?
The IPC547G family uses DDR4 SDRAM. Installed capacity and module arrangement vary according to the order number.

Q6. What storage configurations are supported?
Depending on the model, the family supports internal HDDs, SSDs, and selected RAID configurations. The storage hardware for 6AG4104-4CA10-1XX3 has not been confirmed.

Q7. Which display outputs may be available?
Documented configurations include DVI-D and DisplayPort. Selected variants also support dedicated graphics cards, depending on the motherboard and installed expansion hardware.

Q8. Does the IPC547G support redundant power?
Selected configurations use two redundant 100–240 V AC power supplies. This feature should be confirmed on the actual unit rather than assumed from the family designation.

Q9. What diagnostic functions are integrated into the platform?
The documented IPC547G family includes temperature and fan monitoring and a watchdog function. These features support hardware monitoring and system supervision when used with compatible software.

Q10. How can compatibility be assessed before replacing an existing IPC547G?
Compare the full order number, processor, memory, storage, operating system, expansion cards, network interfaces, display connections, and power-supply arrangement. Software and driver compatibility should also be checked before installation.
