Name: Siemens 6AG4104-4CA11-0BX0 – SIMATIC IPC547G Industrial Rack PC
Brand: Siemens
SKU: 22898
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Siemens SIMATIC IPC547G is an industrial rack computer developed for applications that require conventional PC processing alongside industrial connectivity and hardware expansion. Its 19-inch, 4U form factor allows it to be integrated into equipment racks and control cabinets used in manufacturing, testing, and process-related environments.

A key characteristic of the platform is its support for both PCI Express and legacy PCI expansion cards. This is particularly valuable for installations that rely on specialized communication interfaces, data-acquisition devices, or established industrial software.

The IPC547G family includes configurations with different processors, memory capacities, storage devices, graphics options, and power supplies. Consequently, the family designation alone is not sufficient to determine the complete hardware specification of an individual unit.

For 6AG4104-4CA11-0BX0, confirm the full order number against the product nameplate or original ordering documentation before purchasing accessories, planning a replacement, or integrating the computer into an existing control system.

5. Technical Specifications

The table below summarizes the documented IPC547G family characteristics. Details that depend on the exact order number are marked as configuration-dependent or unverified.

Parameter	Specification
Manufacturer	Siemens
Product family	SIMATIC IPC547G
Order number	6AG4104-4CA11-0BX0
Exact configuration verification	Not independently confirmed
Product type	Industrial Rack PC
Rack format	19-inch, 4U
Processor	Configuration-dependent; exact model unverified
Family processor options	Intel Pentium G4400, Core i5-6500, Core i7-6700, Xeon E3-1275 v5
Motherboard chipset	Intel H110 or Intel C236, depending on configuration
Memory technology	DDR4 SDRAM
Installed memory	Configuration-dependent
Storage	HDD, SSD, or selected RAID configurations
Front USB	2 × USB 3.0 on documented configurations
Ethernet	2 × Intel Gigabit Ethernet
Rear USB	Configuration-dependent
Display interfaces	Configuration-dependent; documented options include DVI-D and DisplayPort
PS/2 interfaces	2 on documented configurations
Audio	Rear audio interfaces
Expansion slots	5 × PCI Express, 2 × PCI
Graphics	Integrated or optional dedicated graphics
System monitoring	Temperature and fan monitoring
Watchdog	Supported
Power input	100–240 V AC on documented configurations
Redundant power supply	Available on selected configurations
Standard enclosure dimensions (W × H × D)	481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)	481.4 × 176.6 × 356.6 mm
Family weight range	Approximately 15–23 kg, depending on equipment
Operating system	Configuration-dependent
Exact enclosure and weight for this model	Not independently verified

Installation note: The dimensions and weight are family-level figures. Confirm the actual enclosure variant and installed equipment before planning rack clearance, transport, or lifting arrangements.

6. Recommended Related Models

The following documented IPC547G variants provide useful comparison points when evaluating replacement hardware or planning maintenance.

Model	Configuration highlights	Recommended comparison
6AG4104-4CA01-0XX1	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, onboard graphics, no operating system	Basic IPC547G configuration
6AG4104-4CA12-1DX1	Core i5-6500, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 10 Enterprise 2016 LTSB	Comparison for memory and operating-system requirements
6AG4104-4DA12-3BX2	Core i7-6700, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 7 Ultimate	Alternative processor configuration
6AG4104-4GA12-2DX1	Core i5-6500, C236 chipset, 8 GB DDR4, 1 TB HDD, dedicated dual-head graphics, Windows 10 Enterprise 2016 LTSB	Comparison for dedicated graphics requirements
6AG4104-4GK13-1BX2	Core i5-6500, C236 chipset, 8 GB DDR4, front-access 480 GB SSD, redundant AC power supplies	Comparison for front-access storage and power redundancy

These are related configurations, not guaranteed drop-in replacements. Confirm interface requirements, software compatibility, and power arrangements before selecting an alternative.

7. Popular Related Models

The following additional IPC547G configurations offer reference points for different storage and power-supply arrangements.

Model	Configuration highlights	Main distinction
6AG4104-4CA04-0BX0	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, DVD±RW, redundant AC power supplies, Windows 7 Ultimate	Redundant power configuration
6AG4104-4EN16-3XX0	Pentium G4400, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, COM2 and LPT, no operating system	Legacy interfaces and mirrored storage
6AG4104-4GN16-4BX0	Core i5-6500, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, Windows 7 Ultimate	RAID 1 storage arrangement
6AG4104-4CC20-0XX1	Core i5-6500, H110 chipset, 16 GB DDR4, 240 GB SSD, short enclosure, no operating system	Higher memory capacity and reduced chassis depth
6AG4104-4CA00-0BX2	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, short enclosure, Windows 7 Ultimate	Short-depth rack installation

Applications

The IPC547G is suitable for a range of industrial computing tasks where connectivity, expansion capacity, and compatibility with established equipment are important.

Factory automation: Runs supervisory software, production monitoring applications, and machine-level programs.
SCADA and HMI systems: Supports process visualization, operator interfaces, alarms, and data logging.
Industrial data processing: Collects and processes information from sensors, controllers, and measurement devices.
Machine inspection: Supports compatible graphics and interface cards for vision and inspection systems.
Automated testing: Provides a rack-based computer for test benches, measurement stations, and engineering validation.
Industrial communication: Connects automation equipment through Gigabit Ethernet and compatible expansion cards.
Legacy system support: Helps maintain installations that depend on established PC software or PCI-based hardware.

Advantages

Expansion for Industrial Applications

The IPC547G family provides seven expansion slots in documented configurations: five PCI Express and two PCI. This supports compatible industrial communication cards, data-acquisition hardware, and specialized peripherals.

Integrated Network Connectivity

Two Intel Gigabit Ethernet interfaces provide wired network connectivity for communication between the computer, automation equipment, and supervisory systems.

Flexible Peripheral Support

Front USB 3.0 ports, PS/2 connections, and rear audio interfaces support a variety of compatible peripherals. Display and rear USB options depend on the installed motherboard.

Rack-Mount Construction

The 19-inch, 4U enclosure is designed for industrial racks and control cabinets. The family includes standard and short-depth enclosure variants, allowing engineers to consider available cabinet space when selecting a configuration.

System Monitoring

Temperature and fan monitoring help identify cooling-related issues. The watchdog function can support application-level supervision when configured with compatible software.

Adaptable Hardware Configurations

The IPC547G family was offered with different processors, memory capacities, storage arrangements, graphics options, and power-supply designs. This range helps support different industrial workloads, although the precise configuration must be verified for each order number.

Technical FAQs

Q1. What type of product is the Siemens 6AG4104-4CA11-0BX0?
The requested order number could not be independently confirmed against an exact configuration record. The related SIMATIC IPC547G family consists of industrial rack PCs designed for automation and industrial computing.

Q2. Which processor options are available in the IPC547G family?
Documented configurations include Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processors. The processor installed in this specific unit should be verified from its equipment label or original documentation.

Q3. How many expansion slots does the IPC547G support?
Documented family configurations provide five PCI Express slots and two PCI slots. Expansion-card compatibility depends on the motherboard, card dimensions, power requirements, and available interfaces.

Q4. Does the IPC547G include Gigabit Ethernet?
Yes. Documented configurations provide two Intel Gigabit Ethernet interfaces for wired network communication.

Q5. What memory technology does the IPC547G use?
The family uses DDR4 SDRAM. Installed capacity and memory-channel configuration vary by order number.

Q6. What storage options are available?
Depending on the configuration, the IPC547G family supports internal HDDs, SSDs, and selected RAID arrangements. The storage device and RAID configuration for 6AG4104-4CA11-0BX0 remain unverified.

Q7. Which display interfaces may be available?
Documented configurations include DVI-D and DisplayPort. Some variants also support optional dedicated graphics cards. The actual output arrangement depends on the motherboard and installed graphics hardware.

Q8. Does the IPC547G support redundant power supplies?
Redundant 100–240 V AC power supplies are available on selected family configurations. Their presence in the requested model has not been confirmed.

Q9. What monitoring functions are provided?
The IPC547G family includes temperature and fan monitoring, a watchdog function, and a card retainer. These features assist system supervision and hardware installation but do not replace application-level fault handling.

Q10. What should be checked before installing this PC in an existing automation system?
Confirm the complete order number, processor, memory, storage, operating system, expansion cards, display interfaces, network connections, and power-supply arrangement. Driver availability and software compatibility should also be assessed before commissioning.
