Name: Siemens 6AG4104-4CA11-1XX3 SIMATIC IPC547G Industrial Rack PC
Brand: Siemens
SKU: 22918
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Siemens SIMATIC IPC547G is an industrial rack computer developed for applications that require configurable computing performance, flexible expansion, and integration with established automation infrastructure. Its 19-inch, 4U format makes it suitable for control cabinets, industrial server racks, machine-control systems, and production monitoring stations.

The platform combines dual Gigabit Ethernet with a broad selection of expansion slots, allowing system integrators to adapt the computer to different communication, data acquisition, and control requirements. Industrial monitoring functions and support for selected redundant power configurations further suit the family to demanding operating environments.

For model number 6AG4104-4CA11-1XX3, confirm the exact factory configuration before ordering replacement parts or planning a system upgrade. CPU, memory, storage, operating system, and regional accessories can vary between IPC547G order numbers.

5. Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Product family	SIMATIC IPC547G
Model number	6AG4104-4CA11-1XX3
Product type	Industrial Rack PC
Rack format	19-inch, 4U
Processor	Exact configuration requires order-number verification
Chipset	IPC547G family uses Intel H110 or C236, depending on configuration
Memory	Configuration-dependent DDR4 SDRAM
Storage	Configuration-dependent HDD or SSD
Ethernet	2 × Intel Gigabit Ethernet
Front USB	2 × USB 3.0
Expansion slots	5 × PCI Express, 2 × PCI
Display interfaces	Configuration-dependent; H110 variants commonly provide DVI-D and DisplayPort 1.2
Monitoring	Temperature and fan monitoring, watchdog
Power input	100–240 V AC, depending on installed power supply
Standard enclosure dimensions	481.4 × 176.6 × 446.6 mm (W × H × D)
Short enclosure dimensions	481.4 × 176.6 × 356.6 mm (W × H × D), where applicable
Weight	Approximately 15–23 kg, depending on equipment
Installation	Rack installation; mounting arrangements depend on the setup

6. Recommended Companion Models

The following IPC547G configurations offer useful comparison points when evaluating compatible systems, upgrades, or alternative factory configurations.

Model number	Product name	Main configuration
6AG4104-4GK13-1BX2	Siemens SIMATIC IPC547G Industrial Rack PC	Core i5-6500, C236 chipset, 8 GB DDR4, 480 GB SSD in front-access removable insert, redundant AC power supplies, Windows 7 Ultimate
6AG4104-4CA06-0CX1	Siemens SIMATIC IPC547G Industrial Rack PC	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, DVD±RW, Windows 10 Enterprise LTSB 2015
6AG4104-4CA12-0XX1	Siemens SIMATIC IPC547G Industrial Rack PC	Core i5-6500, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, no operating system
6AG4104-4CA02-3XX0	Siemens SIMATIC IPC547G Industrial Rack PC	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, onboard graphics, 19-inch 4U format

7. Frequently Selected Alternatives

These additional configurations provide different memory, storage, processor, or chassis options within the IPC547G family. Confirm availability and compatibility before selecting a replacement.

Model number	Product name	Main configuration
6AG4104-4CA00-0BX2	Siemens SIMATIC IPC547G Industrial Rack PC	Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, short enclosure, Windows 7 Ultimate
6AG4104-4DA12-3BX2	Siemens SIMATIC IPC547G Industrial Rack PC	Core i7-6700, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, Windows 7 Ultimate
6AG4104-4EN16-3XX0	Siemens SIMATIC IPC547G Industrial Rack PC	Pentium G4400, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, DVD±RW, no operating system
6AG4104-4GN16-4BX0	Siemens SIMATIC IPC547G Industrial Rack PC	Core i5-6500, C236 chipset, 8 GB DDR4, RAID 1 with 2 × 1 TB HDD, Windows 7 Ultimate 64-bit

Where It Excels in Industrial Use

- Industrial automation and control: Designed for control cabinets and 19-inch rack installations, supporting industrial software, monitoring systems, and production-line applications.

- Machine vision and data acquisition: Seven expansion slots, including five PCI Express and two PCI slots, provide flexibility for compatible interface, acquisition, and specialized processing cards.

- Production monitoring: Dual Intel Gigabit Ethernet interfaces support communication with industrial networks, engineering workstations, and supervisory systems.

- Long-running industrial applications: Integrated temperature and fan monitoring, watchdog functionality, and a card retainer help support dependable operation in demanding environments.

- Legacy system integration: A combination of USB, Ethernet, PS/2, display, and expansion interfaces helps accommodate established industrial equipment and existing software infrastructure.

Key Strengths at a Glance

- 19-inch, 4U rack format: A rack-mountable design suited to industrial cabinets and centralized control installations.

- Intel Core processing platform: The IPC547G family supports several processor configurations. The exact CPU and installed memory should be confirmed for this order number.

- Flexible expansion: Five PCI Express slots and two conventional PCI slots accommodate a range of compatible industrial add-on cards.

- Industrial connectivity: Dual Gigabit Ethernet, front USB 3.0 ports, rear USB connectivity, PS/2, and audio interfaces support diverse peripherals and network connections.

- Industrial power input: The family supports 100–240 V AC input, with redundant power-supply options available on selected configurations.

Technical FAQs

Q1: What type of computer is the Siemens 6AG4104-4CA11-1XX3?

It belongs to the Siemens SIMATIC IPC547G family of industrial rack PCs designed for automation, control, and industrial computing applications.

Q2: What rack size does the IPC547G use?

The IPC547G is a 19-inch rack computer with a 4U chassis.

Q3: Which processor is installed in this exact model?

The IPC547G family includes several Intel processor options, but the processor configuration for the exact suffix 6AG4104-4CA11-1XX3 should be checked against its product label or ordering record.

Q4: How many expansion slots are available?

The platform provides seven expansion slots: five PCI Express and two PCI slots.

Q5: Does the IPC547G support Gigabit Ethernet?

Yes. The family provides two Intel Gigabit Ethernet interfaces for network communication.

Q6: What display interfaces are supported?

Display connectivity depends on the motherboard and configuration. H110-based variants commonly include DVI-D and DisplayPort 1.2.

Q7: What power supply does the IPC547G use?

The family supports 100–240 V AC industrial power input. Redundant power supplies are available on selected configurations.

Q8: Does the system include a DVD drive?

A slim DVD±R/RW drive is available on selected IPC547G configurations. Its inclusion in this specific model should be verified.

Q9: Can the IPC547G be used with legacy industrial equipment?

Yes. Its combination of PCI, PCI Express, Ethernet, USB, and PS/2 interfaces can support compatible legacy peripherals and industrial expansion hardware.

Q10: What should be checked before replacing this model?

Verify the installed CPU, memory, storage, operating system, expansion cards, power-supply arrangement, and chassis depth before selecting a replacement.
