Siemens 6AG4104-4CA12-0BX3 SIMATIC IPC547G Industrial Rack PC

Where It Excels in Industrial Use

- Industrial automation and machine control: The SIMATIC IPC547G platform is designed for industrial control cabinets, production equipment, and applications requiring a rack-mounted computer.

- Production monitoring and data processing: Dual Gigabit Ethernet and multiple expansion slots support industrial communication, supervisory software, and compatible data-acquisition hardware.

- Legacy system integration: A combination of network, USB, PS/2, display, and expansion interfaces helps integrate existing industrial equipment and specialized peripherals.

- Centralized rack installations: The 19-inch, 4U design suits industrial racks and control-room cabinets where accessible connections and expansion flexibility are important.

- Industrial application support: Integrated temperature and fan monitoring, watchdog functionality, and expansion-card retention features support system supervision and hardware stability.

Key Strengths at a Glance

- 19-inch, 4U rack format: Designed for industrial rack and control-cabinet installations.

- Flexible expansion architecture: Five PCI Express slots and two PCI slots support a range of compatible industrial add-on cards.

- Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces provide network connectivity for automation and monitoring systems.

- Broad peripheral support: Two front USB 3.0 ports, rear USB connections, PS/2 interfaces, and rear audio are available across the product family.

- Configurable industrial platform: The IPC547G family supports different processor, memory, storage, graphics, and operating-system configurations, depending on the order number.

Technical FAQs

Q1: What is the Siemens 6AG4104-4CA12-0BX3?

It is an order number associated with the Siemens SIMATIC IPC547G industrial rack PC family, although the exact factory configuration for this suffix should be verified before purchase.

Q2: What is the form factor of the IPC547G?

The IPC547G uses a 19-inch, 4U rack format for industrial computing installations.

Q3: Which processor does this exact model contain?

The IPC547G family supports several Intel processor options, but the processor fitted to 6AG4104-4CA12-0BX3 requires confirmation from the original product documentation or rating plate.

Q4: How many expansion slots does the IPC547G provide?

The platform provides seven expansion slots: five PCI Express and two PCI.

Q5: Does the IPC547G include Gigabit Ethernet?

Yes. The product family provides two Intel Gigabit Ethernet interfaces.

Q6: Which display interfaces are supported?

H110-based configurations commonly provide DVI-D and DisplayPort 1.2. The installed motherboard and graphics configuration determine the available outputs.

Q7: What power input does the system support?

The IPC547G family supports 100–240 V AC input. Redundant AC power supplies are available on selected configurations.

Q8: Does this model include an optical drive?

Optical-drive availability depends on the exact factory configuration. The presence of a DVD±RW drive should be confirmed for this order number.

Q9: What are the standard dimensions and weight?

The standard enclosure measures 481.4 × 176.6 × 446.6 mm (W × H × D). Weight varies by configuration, with the family typically ranging from approximately 15 to 23 kg.

Q10: What should be checked before replacing the IPC547G?

Confirm the CPU, memory, storage, operating system, expansion cards, power supply, chassis dimensions, and interface requirements to maintain compatibility with the existing installation.
