Siemens 6AG4104-4CA12-0CX3 SIMATIC IPC547G Industrial Rack PC

Where It Excels in Industrial Use

- Industrial automation and control: The SIMATIC IPC547G platform is designed for rack-mounted computing in factory automation, machine control, and industrial monitoring environments.

- Production data processing: Dual Intel Gigabit Ethernet interfaces support communication with industrial networks, supervisory systems, and compatible data-acquisition equipment.

- Legacy equipment integration: PCI, PCI Express, USB, PS/2, and display connections help accommodate established industrial peripherals and specialized expansion cards.

- Centralized rack installations: The 19-inch, 4U chassis suits industrial cabinets and control-room racks where expansion capability and accessible connections are important.

- Operational monitoring: Integrated temperature and fan monitoring, watchdog functionality, and card-retention features support hardware supervision in industrial installations.

Key Strengths at a Glance

- Industrial rack architecture: A 19-inch, 4U platform designed for industrial computing and automation applications.

- Seven expansion slots: Five PCI Express slots and two PCI slots support compatible interface, communication, and data-acquisition cards.

- Dual Gigabit Ethernet: Two Intel Ethernet ports provide connectivity for industrial networks and supervisory systems.

- Flexible configuration options: The IPC547G family supports different processor, memory, storage, graphics, and operating-system configurations.

- Industrial power support: The platform supports 100–240 V AC input, with redundant power supplies available on selected configurations.

Technical FAQs

Q1: What is the Siemens 6AG4104-4CA12-0CX3?

It is an order number in the Siemens SIMATIC IPC547G industrial rack PC series, but the precise factory configuration for this suffix requires confirmation.

Q2: What type of installation does the IPC547G support?

The IPC547G is designed for 19-inch, 4U rack installation and can be integrated into suitable industrial cabinets and equipment racks.

Q3: Which processor is installed in this model?

The IPC547G family supports multiple Intel processor options. The processor for the exact 6AG4104-4CA12-0CX3 configuration should be verified from its product label or ordering documentation.

Q4: How many expansion slots does the system provide?

The platform provides five PCI Express slots and two PCI slots, allowing expansion with compatible industrial hardware.

Q5: Does the IPC547G support Gigabit Ethernet?

Yes. The family includes two Intel Gigabit Ethernet interfaces for industrial network communication.

Q6: Which display outputs are available?

Display outputs depend on the installed motherboard and graphics configuration. H110-based variants commonly provide DVI-D and DisplayPort 1.2.

Q7: What power supply is supported?

The IPC547G family supports 100–240 V AC input. Selected configurations offer redundant AC power supplies.

Q8: What storage options are available?

Depending on the factory configuration, the IPC547G family supports internal hard drives, solid-state drives, and selected removable storage arrangements.

Q9: What are the chassis dimensions and weight?

The standard enclosure measures 481.4 × 176.6 × 446.6 mm (W × H × D). Weight varies by configuration, typically ranging from approximately 15 to 23 kg.

Q10: What should be checked before replacing this model?

Verify the processor, installed memory, storage type, operating system, expansion cards, power-supply arrangement, and physical dimensions to ensure compatibility with the existing system.
