Siemens 6AG4104-4CA12-0DX3 SIMATIC IPC547G Industrial Rack PC

Where It Excels in Industrial Use

- Industrial automation and machine control: The SIMATIC IPC547G platform is suited to factory automation, industrial control cabinets, and machine-control applications that require a rack-mounted computer.

- Production monitoring and data processing: Dual Intel Gigabit Ethernet interfaces support communication with industrial networks, supervisory systems, and compatible data-acquisition equipment.

- Legacy equipment integration: PCI, PCI Express, USB, PS/2, and display interfaces help accommodate established industrial peripherals and specialized expansion cards.

- Centralized rack installations: The 19-inch, 4U chassis fits industrial racks and control-room cabinets where expansion capacity and accessible connections are important.

- Industrial system supervision: Temperature and fan monitoring, watchdog functionality, and expansion-card retention features support hardware oversight in industrial installations.

Key Strengths at a Glance

- Rack-mounted design: A 19-inch, 4U platform for industrial computing and automation environments.

- Seven expansion slots: Five PCI Express slots and two PCI slots accommodate compatible industrial interface and data-acquisition cards.

- Dual Gigabit Ethernet: Two Intel Ethernet interfaces support industrial networking and communication with supervisory systems.

- Configurable hardware: The IPC547G family supports multiple processor, memory, storage, graphics, and operating-system configurations.

- Industrial power options: The family supports 100–240 V AC input, with redundant power supplies available on selected configurations.

Technical FAQs

Q1: What is the Siemens 6AG4104-4CA12-0DX3?

It appears to be an order-number variant associated with the SIMATIC IPC547G family, but its exact factory configuration could not be independently confirmed.

Q2: What form factor does the IPC547G use?

The IPC547G is a 19-inch, 4U industrial rack PC designed for suitable industrial cabinets and equipment racks.

Q3: Which processor is installed in this exact model?

The family supports several Intel processors, including Core i5 and Core i7 options. The processor for this specific suffix requires verification from the original ordering documentation or product label.

Q4: How many expansion slots are available?

The platform provides five PCI Express slots and two PCI slots.

Q5: Does the IPC547G support Gigabit Ethernet?

Yes. The family provides two Intel Gigabit Ethernet interfaces.

Q6: Which display connections are supported?

Display outputs depend on the installed motherboard and graphics configuration. H110-based variants commonly include DVI-D and DisplayPort 1.2.

Q7: What power input does the system support?

The family supports 100–240 V AC input, with redundant AC power supplies available on selected configurations.

Q8: What storage options are supported?

Depending on the factory configuration, IPC547G systems can use internal hard drives, solid-state drives, and selected removable-drive arrangements.

Q9: What are the dimensions and weight?

The standard enclosure measures 481.4 × 176.6 × 446.6 mm (W × H × D). The family weighs approximately 15–23 kg depending on the installed equipment.

Q10: What should be checked before replacing this model?

Confirm the processor, memory, storage, operating system, expansion cards, power-supply arrangement, and chassis dimensions to ensure compatibility with the existing installation.
