Siemens 6AG4104-4CA12-0FX3 SIMATIC IPC547G Industrial Rack PC

Where It Excels in Industrial Use

- Industrial automation and machine control: The SIMATIC IPC547G platform is designed for industrial computing tasks in factory automation, control cabinets, and machine-control systems.

- Production monitoring and data processing: Dual Gigabit Ethernet interfaces support communication with industrial networks, monitoring software, and compatible data-acquisition equipment.

- Legacy system integration: PCI, PCI Express, USB, PS/2, and display interfaces help accommodate established industrial peripherals and specialized expansion hardware.

- Centralized rack installations: The 19-inch, 4U chassis fits industrial equipment racks and control-room cabinets where expansion flexibility is important.

- Hardware supervision: Temperature and fan monitoring, watchdog functionality, and expansion-card retention features support monitoring and management of the industrial PC.

Key Strengths at a Glance

- Industrial rack format: A 19-inch, 4U platform intended for rack-mounted industrial computing.

- Seven expansion slots: Five PCI Express slots and two PCI slots support compatible communication, control, and data-acquisition cards.

- Dual Gigabit Ethernet: Two Intel Ethernet interfaces support industrial network connectivity.

- Flexible configuration options: The IPC547G family supports multiple processor, memory, storage, and graphics configurations.

- Industrial AC power: The family supports 100–240 V AC input, with redundant power supplies available on selected models.

Technical FAQs

Q1: What is the Siemens 6AG4104-4CA12-0FX3?

It is an order-number variant associated with the SIMATIC IPC547G family, but the exact factory configuration for this suffix could not be independently confirmed.

Q2: What form factor does the IPC547G use?

The IPC547G is a 19-inch, 4U industrial rack PC designed for installation in compatible equipment racks and industrial cabinets.

Q3: Which processor is installed in this model?

The IPC547G family supports several Intel processor options. The processor for this exact order number should be verified using the original product documentation or rating plate.

Q4: How many expansion slots are available?

The platform provides five PCI Express slots and two PCI slots for compatible expansion hardware.

Q5: Does the IPC547G support Gigabit Ethernet?

Yes. The family provides two Intel Gigabit Ethernet interfaces for industrial networking.

Q6: Which display interfaces are available?

Display connections depend on the motherboard and graphics configuration. H110-based variants commonly include DVI-D and DisplayPort 1.2.

Q7: What power supply does the IPC547G use?

The family supports 100–240 V AC input, with redundant AC power supplies available on selected configurations.

Q8: What storage options can be installed?

Depending on the configuration, the IPC547G family supports internal hard drives, solid-state drives, and selected removable-drive arrangements.

Q9: What are the chassis dimensions and weight?

The standard enclosure measures 481.4 × 176.6 × 446.6 mm (W × H × D). Weight varies by configuration, typically ranging from approximately 15 to 23 kg.

Q10: What should be checked before replacing this model?

Confirm the installed processor, memory, storage, operating system, expansion cards, power-supply arrangement, and chassis dimensions before choosing a replacement.
