Siemens 6AG4104-4CC10-1CX1 SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CC10-1CX1 SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4CC10-1CX1 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4104-4CC10-1CX1 is associated with the SIMATIC IPC547G family of industrial rack PCs. The platform is intended for industrial computing applications that require network connectivity, hardware expansion, and a rack-based installation format.
Its combination of Gigabit Ethernet interfaces and PCI Express and PCI expansion slots makes the family suitable for a variety of production monitoring, machine-control, and data-processing roles. Built-in temperature and fan monitoring, along with watchdog functionality, also provides useful support for system maintenance.
For industrial operators and system integrators, selecting the correct IPC547G configuration is important when maintaining equipment or planning a replacement. The exact processor, memory, storage, operating system, and enclosure options for 6AG4104-4CC10-1CX1 should be verified using the matching Siemens order documentation before purchase.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order number
6AG4104-4CC10-1CX1
Product family
SIMATIC IPC547G
Product type
Industrial rack PC
Rack format
19-inch, 4U
Processor
Exact configuration requires verification
Installed memory
Exact configuration requires verification
Storage
Exact configuration requires verification
Network interfaces
2 × Intel Gigabit Ethernet at platform level
Front USB interfaces
2 × USB 3.0 at platform level
Expansion slots
5 × PCI Express and 2 × PCI at platform level
Monitoring functions
Temperature monitoring, fan monitoring, watchdog
Power supply
100–240 V AC platform options; exact configuration requires verification
Standard enclosure dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)
481.4 × 176.6 × 356.6 mm
Weight
Approximately 15–23 kg across the family, depending on configuration
Dimensions, weight, and interface details reflect the IPC547G family. The exact enclosure and hardware configuration of order number 6AG4104-4CC10-1CX1 should be confirmed before installation.
- Production Line Control: Supports industrial applications that coordinate machine operations, monitor production status, and exchange data with automation equipment.
- Industrial Data Processing: Provides a platform for collecting production data, running monitoring applications, and connecting shop-floor systems with supervisory software.
- Machine Vision and Inspection Systems: With compatible expansion hardware, the IPC547G platform can support image-processing and inspection applications that require industrial PC integration.
- Control Cabinet Integration: Its 19-inch rack-mount format fits centralized equipment racks and industrial cabinets where organized installation and service access are important.
- Existing Automation Infrastructure: Conventional PCI and PCI Express expansion options help integrators retain compatible interface cards when maintaining established industrial systems.
Key Strengths at a Glance
- Industrial Rack-Mount Platform: The SIMATIC IPC547G family uses a 19-inch, 4U chassis designed for industrial computing installations.
- Flexible Expansion Architecture: Five PCI Express slots and two PCI slots at the platform level support a range of compatible industrial interface and communication cards.
- Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces support network connections to production equipment, engineering workstations, and supervisory systems.
- Built-In Hardware Monitoring: Temperature and fan monitoring, together with watchdog functionality, assists system diagnostics and maintenance.
- Service-Friendly Connectivity: Front USB 3.0 ports make it easier to connect service devices and transfer configuration files.
- Configuration-Based Deployment: The IPC547G family offers multiple processor, storage, and memory configurations, allowing system requirements to guide selection of the appropriate variant.
Technical FAQs
1. What is the Siemens 6AG4104-4CC10-1CX1?
It is an order number associated with the Siemens SIMATIC IPC547G industrial rack PC family. The precise hardware configuration should be confirmed against the matching product datasheet.
2. Which processor is installed in this model?
The exact processor for order number 6AG4104-4CC10-1CX1 has not been independently confirmed. The IPC547G family includes several Intel processor configurations, so the processor should be checked before deployment.
3. What memory capacity does it provide?
Installed RAM depends on the specific order configuration. Verify the original configuration or inspect the unit before planning memory expansion.
4. What storage devices are supported?
IPC547G variants were available with different internal storage options, including HDD and SSD configurations. Confirm the installed drive type and capacity for this specific model.
5. How many Ethernet interfaces are available?
The IPC547G platform provides two Intel Gigabit Ethernet interfaces, supporting connections to industrial networks and higher-level control systems.
6. Does the IPC547G support expansion cards?
Yes. The platform provides five PCI Express slots and two conventional PCI slots. Individual card compatibility depends on interface, dimensions, power requirements, and the installed configuration.
7. What monitoring functions does the system provide?
The IPC547G platform includes temperature and fan monitoring as well as watchdog functionality, supporting operational diagnostics and system supervision.
8. What operating system is compatible with this order number?
The operating system depends on the original product configuration. Check the product label, purchase documentation, or installed software image before performing an operating-system migration.
9. What power supply does the IPC547G use?
The platform supports 100–240 V AC power-supply options, with redundant power supplies available on selected configurations. The exact power-supply arrangement for this order number requires verification.
10. What should be checked before purchasing a replacement unit?
Confirm the full order number, processor, RAM, storage, operating system, expansion cards, enclosure depth, and power-supply arrangement. These checks help ensure compatibility with the existing automation system.
