The ABB DATX100 is a high-performance industrial communication gateway designed to facilitate seamless data integration and protocol conversion across diverse automation systems. With its advanced capabilities, the DATX100 enables different industrial devices, controllers, and networks to communicate efficiently, even when using different communication protocols. Ideal for complex industrial environments, the DATX100 ensures that your automation system operates smoothly, with reliable data exchange between components. Whether you are bridging multiple networks, performing data logging, or optimizing system performance, the DATX100 is a versatile and indispensable solution.

Technical Specifications

Model: DATX100
Type: Industrial Communication Gateway
Dimensions: 6.5 inches x 4.3 inches x 3.1 inches (165 mm x 110 mm x 78 mm)
Weight: 1.2 lbs (0.55 kg)
Power Supply: 24V DC
Power Consumption: 5 W
Communication Ports:
- 1x Ethernet Port (10/100 Mbps)
- 2x Serial Ports (RS-232/RS-485)
- 1x CANopen Port
Protocols Supported: Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, and more
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
Environmental Rating: IP20 (for indoor use)
Bus Current: 210 mA at 24V DC
Data Rate: 100 Mbps (Ethernet)

Recommended Related Models

ABB AC500 PLC: A modular PLC for advanced automation, compatible with the DATX100 for a seamless, integrated solution.
ABB COM600 Communication Module: An additional communication module for expanding the connectivity of your automation system.
ABB PM800 Power Meter: Monitors and optimizes energy consumption, complementing the DATX100’s role in system integration.
ABB S800 I/O Modules: Expand I/O capabilities for larger, more complex systems, ensuring the DATX100 can handle more I/O points when necessary.

Popular ABB Models

ABB AC500-eCo: A compact, entry-level PLC offering high functionality for small to mid-scale automation systems.
ABB CP600: A flexible communication processor designed to handle various industrial communication protocols.
ABB S500 I/O System: A modular I/O system to extend the functionality of your control and monitoring systems.

Applications

The ABB DATX100 is ideal for a wide range of industrial applications that require reliable communication and integration between systems:

Protocol Conversion: The DATX100 facilitates communication between different industrial networks, including Modbus TCP, EtherNet/IP, Profibus DP, and CANopen.
Data Logging: It allows data from various sensors and devices to be collected, logged, and analyzed, helping improve performance and system diagnostics.
Industrial Automation: Perfect for large-scale automation projects that require real-time communication between PLCs, sensors, actuators, and other devices.
Energy Management: Integrates with power monitoring devices and energy meters to optimize energy consumption and improve operational efficiency.
Building Automation: Integrates HVAC systems, lighting controls, and other building management systems, enabling centralized control and monitoring.

Advantages

Multi-Protocol Support: The DATX100 supports multiple communication protocols like Modbus TCP, EtherNet/IP, Profibus DP, CANopen, and OPC UA, ensuring compatibility with a wide variety of devices and networks.
Flexible Communication Ports: Equipped with 1 Ethernet port, 2 serial ports (RS-232/RS-485), and 1 CANopen port, the DATX100 offers a broad range of communication options.
Seamless Integration: The gateway’s ability to convert and integrate multiple protocols into a single communication standard streamlines network management and enhances system efficiency.
Compact Design: Despite its powerful capabilities, the DATX100 is compact and easy to integrate into existing control systems without requiring excessive space.
Energy-Efficient: With a power consumption of just 5 W, the DATX100 operates efficiently, making it an excellent choice for continuous industrial applications.

Technical FAQs

What communication protocols are supported by the DATX100?
The DATX100 supports a variety of protocols, including Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, and CANopen, making it versatile for different industrial environments.
How many communication ports does the DATX100 have?
The DATX100 comes with 1 Ethernet port (10/100 Mbps), 2 serial ports (RS-232/RS-485), and 1 CANopen port, offering flexible communication options.
What is the power consumption of the DATX100?
The DATX100 consumes 5 W of power, ensuring efficient operation while minimizing energy consumption.
Can the DATX100 be used for protocol conversion?
Yes, the DATX100 is designed specifically for protocol conversion, allowing seamless communication between different industrial networks.
What is the data rate of the DATX100’s Ethernet port?
The DATX100’s Ethernet port supports data rates of 100 Mbps, providing high-speed communication for connected devices.
Is the DATX100 suitable for use in harsh environments?
The DATX100 has an IP20 rating, meaning it is designed for indoor use. For installation in harsher environments, appropriate enclosures are recommended.
What is the operating temperature range of the DATX100?
The DATX100 can operate in environments with temperatures ranging from -20°C to 60°C (-4°F to 140°F).
Can the DATX100 integrate with ABB PLC systems?
Yes, the DATX100 is fully compatible with ABB PLC systems, especially the AC500 series, allowing seamless communication within ABB's automation ecosystem.
How is data logged with the DATX100?
The DATX100 can collect and store data from connected devices, enabling easy access and analysis for performance optimization and troubleshooting.
What is the weight of the DATX100?
The DATX100 weighs approximately 1.2 lbs (0.55 kg), making it compact and easy to install in industrial environments.
