The ABB DATX130 is an advanced industrial communication gateway designed to simplify data integration and facilitate seamless protocol conversion in industrial automation systems. By supporting a broad range of communication protocols, the DATX130 ensures that devices and systems operating on different networks can interact efficiently. Whether you're managing energy systems, automating processes, or monitoring industrial equipment, the DATX130 provides reliable and secure communication, helping organizations streamline their operations and improve system efficiency.

Technical Specifications

Model: DATX130
Type: Industrial Communication Gateway
Dimensions: 7.2 inches x 4.5 inches x 3.3 inches (183 mm x 115 mm x 84 mm)
Weight: 1.5 lbs (0.7 kg)
Power Supply: 24V DC
Power Consumption: 7 W
Communication Ports:
- 1x Ethernet Port (10/100/1000 Mbps)
- 2x Serial Ports (RS-232/RS-485)
- 1x CANopen Port
Supported Protocols: Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, BACnet, and more
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
Environmental Rating: IP20 (for indoor use)
Bus Current: 240 mA at 24V DC
Data Rate: 1000 Mbps (Gigabit Ethernet)

Recommended Related Models

ABB AC500 PLC: A flexible, modular PLC for integrating with the DATX130 in large-scale automation systems.
ABB COM600 Communication Module: A module designed to expand communication and integration capabilities in your ABB automation system.
ABB PM800 Power Meter: An energy monitoring solution that integrates seamlessly with the DATX130 for real-time energy data management.
ABB S800 I/O Modules: A series of I/O modules designed for high-performance automation systems, expanding the functionality of the DATX130.

Popular ABB Models

ABB AC500-eCo: A cost-effective PLC offering advanced control capabilities for smaller automation systems.
ABB CP600: A reliable communication processor for managing and controlling multiple industrial communication networks.
ABB S500 I/O System: A modular I/O system that complements the DATX130 for versatile control and monitoring of industrial systems.

Applications

The ABB DATX130 is engineered for a broad range of applications that demand high-performance communication and seamless data integration:

Protocol Conversion: The DATX130 supports multiple protocols such as Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, and BACnet, allowing devices and systems with different protocols to communicate effectively.
Data Logging and Analysis: Collect and store data from various industrial systems and sensors, enabling detailed analysis for optimization and system performance improvement.
Industrial Automation: Enhance communication and control across complex automation systems by integrating PLCs, I/O devices, sensors, and actuators.
Energy Management: Integrate the DATX130 with energy meters and monitoring systems for real-time energy consumption data, promoting energy efficiency in industrial processes.
Building Automation: Manage HVAC, lighting, and other systems within commercial or industrial buildings, ensuring centralized and efficient control of building operations.

Advantages

Multi-Protocol Support: The DATX130 supports a wide array of industrial communication protocols, such as Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, and BACnet, making it ideal for integrating disparate devices and systems.
High-Speed Communication: With Gigabit Ethernet (1000 Mbps), the DATX130 offers high-speed communication to handle large volumes of data across industrial networks.
Flexible Ports: The DATX130 features 1 Ethernet port, 2 serial ports (RS-232/RS-485), and 1 CANopen port, allowing for easy integration into a wide range of industrial environments.
Compact and Reliable Design: Despite its compact size, the DATX130 delivers reliable and high-performance data processing, making it a valuable addition to space-constrained applications.
Energy-Efficient: With a power consumption of only 7 W, the DATX130 delivers optimal performance while keeping energy usage to a minimum.

Technical FAQs

What communication protocols are supported by the DATX130?
The DATX130 supports a wide range of industrial protocols, including Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, and BACnet.
How many communication ports does the DATX130 have?
The DATX130 features 1 Ethernet port (10/100/1000 Mbps), 2 serial ports (RS-232/RS-485), and 1 CANopen port, providing a variety of options for device integration.
What is the power consumption of the DATX130?
The DATX130 consumes only 7 W, offering a highly efficient solution for data integration without excessive energy consumption.
What is the data rate of the Ethernet port on the DATX130?
The Ethernet port supports Gigabit Ethernet (1000 Mbps), providing fast and reliable communication for data-intensive applications.
Can the DATX130 be used for energy management?
Yes, the DATX130 can be integrated with ABB’s energy meters and monitoring devices to collect and analyze energy consumption data in real-time.
Is the DATX130 suitable for industrial environments?
Yes, the DATX130 is designed to operate in a variety of industrial settings, with an IP20 environmental rating for indoor use and an operating temperature range of -20°C to 60°C (-4°F to 140°F).
Can the DATX130 be used for protocol conversion between different network types?
Yes, the DATX130 excels in converting and integrating multiple protocols, making it an ideal solution for communication between diverse industrial networks.
What is the weight of the DATX130?
The DATX130 weighs approximately 1.5 lbs (0.7 kg), making it easy to integrate into your existing automation system.
How does the DATX130 enhance industrial automation systems?
The DATX130 simplifies communication between various industrial devices by supporting multiple protocols and offering high-speed data transfer, enabling efficient system control and monitoring.
Can the DATX130 be integrated with ABB PLC systems?
Yes, the DATX130 is fully compatible with ABB PLC systems, particularly the AC500 and AC500-eCo series, providing seamless integration and communication within the ABB ecosystem.
