The ABB DATX131 is a robust industrial communication gateway designed to enhance data integration and facilitate seamless protocol conversion in complex automation environments. This high-performance gateway supports a broad range of industrial communication protocols, enabling seamless connectivity between devices, systems, and networks that use different communication standards. Whether you’re managing process automation, energy systems, or building management systems, the DATX131 ensures efficient data exchange, enabling reliable operations and optimizing industrial processes.

Technical Specifications

Model: DATX131
Type: Industrial Communication Gateway
Dimensions: 7.4 inches x 4.7 inches x 3.5 inches (188 mm x 119 mm x 89 mm)
Weight: 1.6 lbs (0.73 kg)
Power Supply: 24V DC
Power Consumption: 8 W
Communication Ports:
- 1x Ethernet Port (10/100/1000 Mbps)
- 2x Serial Ports (RS-232/RS-485)
- 1x CANopen Port
Supported Protocols: Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, BACnet, LonWorks, and more
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
Environmental Rating: IP20 (for indoor use)
Bus Current: 250 mA at 24V DC
Data Rate: 1000 Mbps (Gigabit Ethernet)

Recommended Related Models

ABB AC500 PLC: A scalable and modular PLC solution ideal for complex automation systems that integrate with the DATX131.
ABB COM600 Communication Module: Expands communication options and enhances the functionality of your ABB automation system when combined with the DATX131.
ABB PM800 Power Meter: Integrate real-time energy monitoring and management with the DATX131 for improved energy efficiency in industrial operations.
ABB S800 I/O Modules: A flexible I/O system that can be used with the DATX131 to extend system functionality and provide more granular control.

Popular ABB Models

ABB AC500-eCo: A cost-effective PLC that delivers reliable automation for smaller to mid-sized applications, complementing the DATX131 for simple integration.
ABB CP600: A versatile communication processor that can handle a wide variety of communication tasks across industrial networks.
ABB S500 I/O System: A modular I/O solution offering flexibility and reliability when paired with the DATX131 for larger automation systems.

Applications

The ABB DATX131 is ideal for a variety of applications across different industrial sectors that require high-performance data integration and communication:

Protocol Conversion: The DATX131 supports numerous protocols such as Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, BACnet, and LonWorks, enabling devices with different communication standards to work together.
Data Logging and Monitoring: Collect and store operational data from industrial equipment, sensors, and meters, facilitating detailed performance analysis and system optimization.
Industrial Automation: The DATX131 integrates easily with PLCs, I/O devices, sensors, and actuators, providing seamless communication in large-scale automation systems.
Energy Management: Integrate the DATX131 with energy meters to gather real-time data for tracking and managing energy consumption, improving operational efficiency.
Building Automation: Use the DATX131 to connect and manage HVAC systems, lighting, and other building systems, allowing for centralized monitoring and control of facility operations.

Advantages

Multi-Protocol Support: The DATX131 supports a wide range of communication protocols, including Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, BACnet, and LonWorks, making it adaptable to various industrial systems.
High-Speed Data Transfer: Equipped with Gigabit Ethernet (1000 Mbps), the DATX131 ensures fast and reliable communication, ideal for systems that require high-speed data processing.
Multiple Communication Options: The DATX131 features 1 Ethernet port, 2 serial ports (RS-232/RS-485), and 1 CANopen port, allowing flexible integration with a variety of devices and control systems.
Compact and Efficient: Despite its powerful features, the DATX131 is compact, weighing only 1.6 lbs (0.73 kg), which allows for easy installation in space-constrained environments.
Energy-Efficient: The DATX131 consumes only 8 W, ensuring low operational costs and making it a cost-effective solution for continuous data transfer and integration.

Technical FAQs

What communication protocols does the DATX131 support?
The DATX131 supports a wide range of protocols, including Modbus TCP, EtherNet/IP, Profibus DP, OPC UA, CANopen, BACnet, and LonWorks, allowing seamless integration across various systems.
How many communication ports does the DATX131 have?
The DATX131 features 1 Ethernet port (10/100/1000 Mbps), 2 serial ports (RS-232/RS-485), and 1 CANopen port, providing flexibility for multiple types of connections.
What is the power consumption of the DATX131?
The DATX131 consumes 8 W of power, making it an energy-efficient choice for continuous operation and data transfer.
What is the data rate of the Ethernet port on the DATX131?
The Ethernet port on the DATX131 supports Gigabit Ethernet (1000 Mbps), enabling high-speed communication for large volumes of data.
Can the DATX131 be used in energy management applications?
Yes, the DATX131 can integrate with energy meters and monitoring devices, providing real-time data for energy consumption tracking and analysis.
Is the DATX131 suitable for industrial environments?
The DATX131 is designed for industrial use with an IP20 rating, suitable for indoor environments. It operates within a temperature range of -20°C to 60°C (-4°F to 140°F).
Can the DATX131 be used for protocol conversion in large-scale automation systems?
Yes, the DATX131 excels in protocol conversion and data integration, making it ideal for large-scale industrial automation systems requiring communication between devices with different protocols.
What is the weight of the DATX131?
The DATX131 weighs approximately 1.6 lbs (0.73 kg), providing a compact yet powerful solution for industrial communication.
How does the DATX131 improve building automation systems?
The DATX131 facilitates the integration of HVAC, lighting, and other building systems, allowing for centralized control and improved energy efficiency in commercial and industrial buildings.
Can the DATX131 be integrated with ABB PLCs?
Yes, the DATX131 is compatible with ABB PLCs, such as the AC500 series, allowing seamless communication and control across your automation systems.
