The GE IC200ALG630-BB Analog Input Module is engineered for high-density, reliable analog data acquisition in industrial control systems. Part of the VersaMax™ I/O system, this module integrates seamlessly with GE PACSystems™ and VersaMax PLCs to enable precise signal processing from a variety of analog sources. It supports 16 input channels, offering flexible configurations for voltage (0-10V, ±10V) and current (4-20mA) signals, making it suitable for a wide range of industrial sensors and measurement applications.
With 16-bit resolution and ±0.1% accuracy, the IC200ALG630-BB ensures high-quality analog-to-digital conversion for critical data collection and real-time monitoring. Its fast sample rate and high input density provide accurate readings and fast data acquisition, ensuring efficient system control. The module is designed to operate in harsh industrial environments, offering robust protection against electrical noise and extreme temperatures.
Ideal for applications such as manufacturing, chemical processing, oil & gas, and power generation, the GE IC200ALG630-BB delivers consistent performance and reliability. Its compact design and DIN rail mounting capability make installation quick and simple, while its comprehensive diagnostic features allow for easy troubleshooting and maintenance.
Technical Specifications
| Specification | Details |
|---|---|
| Model | GE IC200ALG630-BB |
| Module Type | Analog Input Module |
| Input Channels | 16 Single-Ended or 8 Differential Inputs |
| Input Signal Types | Voltage (0-10V, ±10V) or Current (4-20mA) |
| Accuracy | ±0.1% of Full Scale |
| Resolution | 16-bit |
| Sample Rate | 20ms per channel (for 8 differential channels) |
| Isolation | 1500V isolation between inputs and system |
| Dimensions (HxWxD) | 4.1" x 2.8" x 3.5" (104 mm x 71 mm x 89 mm) |
| Weight | 0.3 kg (0.66 lbs) |
| Power Supply | 5V DC (from system power supply) |
| Mounting | DIN Rail Mounted |
| Operating Temperature Range | -40°C to 70°C (-40°F to 158°F) |
| Environmental Protection | IP20 (protected from dust and water droplets) |
| Diagnostic Features | Built-in LEDs for status monitoring |
