The ABB NGDR-02C Digital Drive & Regulator Control Board Module is engineered to deliver dependable control logic and real-time processing within advanced industrial drive systems. Designed for integration with ABB drive platforms, this control board manages motor command coordination, speed regulation, and essential logic interfacing between field inputs, drive power stages, and supervisory controllers.
Built to withstand demanding industrial environments, the NGDR-02C combines rugged hardware with responsive processing capabilities. Its design supports stable, continuous operation in applications where speed control, torque management, and system protection functions must perform reliably under load.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | ABB |
| Model | NGDR-02C |
| Module Type | Digital Drive & Regulator Control Board Module |
| Application | Industrial motor drives and automation systems |
| Function | Drive logic, speed/torque regulation, signal computation |
| Mounting | Drive-integrated PCB |
| Power | Internal drive power supply |
| Communication Interface | Backplane / internal bus |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Tolerance | 5–95% non-condensing |
| Dimensions (L × W × H) | 260 × 175 × 38 mm |
| Weight | 0.78 kg |
| Signal Inputs | Digital inputs, encoder feedback |
| Protection Features | Integrated noise suppression & fault logic |
Recommended Related Models
To build a balanced drive control architecture, the NGDR-02C is frequently paired with:
-
ABB NAMC-11C – Main Drive Control Board
-
ABB NBIO-21CU – Universal I/O Interface Module
-
ABB NDCO-03C – Fieldbus Communication Interface
-
ABB NETA-21 – Ethernet Communication Adapter
-
ABB NAIO-01 – Analog I/O Expansion Module
Together, these boards expand drive control capabilities while enhancing connectivity and data handling.
Popular ABB Drive Control Modules
Across industrial automation systems, the following ABB modules are widely adopted:
-
ABB ACS800 / ACS880 Series Drive Control Boards
-
ABB PM583-ETH – PLC Processor with Ethernet
-
ABB CI840 – Fieldbus Communication Module
-
ABB S800 I/O Series Modules
-
ABB RUSB-02 – Backplane USB Communication Interface
These modules integrate seamlessly with the NGDR-02C to support flexible and scalable automation solutions.
