ABB PFTL201CD Pressductor PillowBlock Load Cell for Precision Vertical Force & Strip Tension Measurement
ABB PFTL201CD Pressductor PillowBlock Load Cell for Precision Vertical Force & Strip Tension Measurement
0.0
Points
Brand:ABB PLC Item No.:ABB PFTL201CD Product Origin:Sweden Product Dimensions:150 mm × 100 mm × 60 mm Product Weight:1.04 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB PFTL201CD Pressductor PillowBlock Load Cell is a rugged and high-precision force measurement transducer engineered for industrial strip tension and vertical force applications. Manufactured as part of ABB’s proven Pressductor® sensor lineup, this load cell delivers exceptionally stable force signals and outstanding overload capacity, making it ideal for heavy-duty material processing lines where accurate tension measurement is critical to process quality and system reliability.
Constructed from a single block of high-strength stainless steel, the PFTL201CD provides excellent immunity to shock, impact, dust, and corrosion — characteristics essential for demanding manufacturing environments such as galvanizing lines, pickling processes, and continuous strip processing.
Technical Specifications
Parameter
Specification
Product Name
ABB PFTL201CD
Module Type
Pressductor PillowBlock Load Cell
Core Function
Vertical force and strip tension measurement
Measurement Technology
Magneto-elastic Pressductor® sensing
Output Type
Analog / digital force signal
Accuracy
High precision industrial grade
Mounting Method
PillowBlock mount under bearing
Construction Material
Stainless steel, fully encapsulated
Protection
Industrial sealed design
Operating Temperature
Typical industrial range
Dimensions (approx.)
~150 mm × 100 mm × 60 mm (estimated)
Weight
~1.04 kg (approx.)
Recommended Related Models
To build a complete, closed-loop tension control or force measurement system, the PFTL201CD is often paired with:
ABB PFEA112 Tension Electronics Unit – signal conditioning and interface
ABB PFEA113 Signal Amplifier Module – enhanced output and diagnostics
ABB AC500 PLC Controllers – logic and control integration
ABB PFCL201 Vertical Load Cells – for higher range vertical tension measurement
These combinations ensure precise measurement data, reliable control feedback, and expanded automation capability.
Popular ABB System Integration Platforms
The PFTL201CD seamlessly operates within a variety of ABB automation environments, including:
ABB Strip Tension and Web Control Solutions
ABB PLC-based Process Monitoring Systems
Automated Rolling, Galvanizing, and Pickling Lines
High-load Material Handling and Process Automation
Its compatibility with ABB measurement and analytics tools enables engineers to optimize production control and material quality.
Industrial Applications
The ABB PFTL201CD delivers consistent force measurement in demanding industrial contexts such as:
Steel and metal strip tension monitoring
Galvanizing and pickling line feedback systems
Continuous web handling and processing
Coil handling and rewinding tension control
Heavy-duty manufacturing and process lines
Integrated force control in automated machinery
By measuring vertical force precisely, the PFTL201CD helps maintain product quality and reduces material waste.
Key Advantages
Robust industrial construction: stainless steel housing for long-term durability.
High overload tolerance: designed to endure harsh processing loads.
Stable force output: exceptional measurement repeatability under dynamic conditions.
Sealed internal components: increased protection against contaminants.
Flexible connection variants: plug or cable seal options for diverse system needs.
Designed for heavy-duty environments: suitable for mill-proof applications.
Integrates with ABB force platforms: simplifies tension control system design.
These strengths make the PFTL201CD a dependable choice for modernization, preventive maintenance, and long-term process monitoring.
Technical FAQs
1. What type of force does the ABB PFTL201CD measure?
It measures vertical force output, commonly used in strip tension applications.
2. What sensing technology does it use?
Magneto-elastic Pressductor® technology for stable and interference-resistant signals.
3. Can this load cell handle industrial overloads?
Yes — its robust design offers high overload tolerance and shock resistance.
4. Is it suitable for harsh environments?
Yes — stainless steel construction and encapsulated components enhance durability.
5. How is the PFTL201CD mounted?
Standard PillowBlock mounting under bearing housings or support structures.
6. Does it provide real-time force data?
Yes — the transducer outputs force measurements that can be used in real-time control loops.
7. What industries use this load cell?
Steel processing, galvanizing, pickling, web handling, and automated manufacturing.
8. Is it compatible with ABB PLCs and controllers?
Yes — it integrates effectively with ABB automation systems and analytics tools.
9. Does this model come with different connector options?
Variants include plug-connect and cable seal versions to fit installation needs.
10. Is professional installation recommended?
Yes — proper alignment and integration ensure measurement accuracy and reliability.
