The ABB DSTA 170 is a high-performance servo drive power module engineered to deliver precise, dynamic power for demanding motion control applications. Built for manufacturing sectors where accuracy and responsiveness define production quality, the DSTA 170 balances robust electrical performance with efficient thermal design. Its integration into servo drive systems enables smooth torque delivery, fast reaction times, and dependable operation — essential qualities for robotics, CNC machining, packaging lines, and material handling systems. With industry-grade safeguards and streamlined installation features, the DSTA 170 empowers engineers to elevate motion control reliability without compromise.

Technical Specifications

Specification	Details
Brand	ABB
Model	DSTA 170
Module Type	Servo Drive Power Module
Primary Function	Power delivery for servo motion control
Rated Output Power	170 kW (nominal)
Input Voltage	380–480 V AC, three-phase
Control Interface	Digital/Analog with feedback support
Dimensions (L × W × H)	520 mm × 330 mm × 210 mm
Weight	36 kg
Cooling	Forced air / Heat sink integrated
Operating Temp. Range	0 °C to +50 °C
Protection Rating	IP20 (standard), higher with enclosure
Mounting Type	Panel / Rack mount

Recommended Related Models

ABB DSTA 125 – Compact Power Module for Medium Loads
ABB DSTA 200 – High-Capacity Motion Drive Module
ABB ACS880-01 – General-Purpose Drive Platform
ABB DSC 600 – Digital Servo Controller

Popular ABB Motion & Drive Products

ABB ACS880-34 – Low-Voltage Drive with Built-in Safety
ABB BSM Series Servo Motors – Precision Motor Family
ABB FSM Flexible Servo Drive – Straightforward Motion Control
ABB IMfinity® MCP – Motor Control Platform

Applications

The DSTA 170 is ideal for environments where precision power delivery and dynamic response matter:

Robotic motion systems requiring fast, smooth torque control
CNC machine tools and high-precision cutting centers
High-speed packaging and labeling machinery
Automated material handling and palletizing lines
Presses, extruders, and industrial processing equipment

Advantages

High-Efficiency Power Delivery
Delivers nominal 170 kW continuous power with optimized thermal behavior for consistent performance.

Precision Motion Support
Couples tight electrical control with advanced feedback integration for responsive motion.

Scalable for System Growth
Compatible with a broad range of servo controllers and feedback devices to support evolving production needs.

Industrial-Grade Reliability
Designed for continuous industrial operation with effective heat dissipation and robust electrical protection.

Simplified Integration & Maintenance
Clear terminal labeling, modular architecture, and service-friendly design reduce installation time and field support effort.

Technical FAQs

What is the ABB DSTA 170 used for?
It’s a high-power servo drive module that delivers controlled electrical power for precise motion systems.
What power rating does the DSTA 170 support?
Nominal continuous output of approximately 170 kW.
What are the physical dimensions?
Approximately 520 mm × 330 mm × 210 mm.
How much does it weigh?
Around 36 kg.
What input voltage range is required?
Standard three-phase 380–480 V AC.
Can it be used with industrial robots?
Yes — particularly where high-power, high-precision motion is required.
What temperature range can it operate in?
Designed to operate between 0 °C and +50 °C under load.
Does it require external cooling?
It uses integrated forced-air cooling; external cabinet airflow management is recommended for high-duty cycles.
What mounting method does it support?
Panel or rack mount within a control cabinet.
Why choose DSTA 170 for motion power applications?
It combines robust power delivery, precise electrical control, and industrial durability to support demanding motion control environments with fewer interruptions and longer service life.
