ABB S-093H Phase Module for ACS6000 / PCS6000 Medium-Voltage Drive Systems
ABB S-093H Phase Module for ACS6000 / PCS6000 Medium-Voltage Drive Systems
0.0
Points
Brand:ABB PLC Item No.:ABB S-093H Product Origin:Sweden Product Dimensions:850 × 550 × 650 mm Product Weight:220 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB S-093H Phase Module is a high-power converter module used in medium-voltage industrial drive systems. Manufactured by ABB, the S-093H is a core component of the ACS6000 and PCS6000 high-voltage drive platforms, where it performs phase control and power conversion functions.
The module is designed to regulate and balance the three-phase voltage and current within high-power converter systems. It ensures stable and efficient operation of large industrial motors and power conversion equipment, especially in applications that require precise torque and speed control.
Built with modular architecture and advanced power electronics technology, the S-093H enables efficient energy conversion, supports high-power industrial loads, and integrates seamlessly with ABB automation platforms and drive control systems.
Technical Specifications
Parameter
Specification
Product Model
S-093H
Manufacturer
ABB
Product Type
Phase Module / Power Conversion Module
Compatible Systems
ABB ACS6000 / PCS6000 Medium-Voltage Drives
Technology
IGCT-based power electronics
Power Range
4 – 120 MVA system capacity
Voltage Level
Up to 3.3 kV systems
Input Voltage
85 – 264 V AC
Grid Frequency
50 / 60 Hz
Cooling Method
Air or water cooling (depending on configuration)
Protection Functions
Overvoltage, overcurrent, short circuit, overtemperature
Mounting Method
Rack-mounted power module
Operating Temperature
−25 °C to +60 °C
Dimensions (L × W × H)
850 × 550 × 650 mm
Weight
220 kg
Specifications may vary depending on hardware revision and configuration.
Recommended Related Models
Model
Description
S-053M
Phase module for medium-voltage converters
S-123H
High-power phase module
RUSB-02
USB/DDCS communication adapter
RMIO-01C
Drive control board
RDCU-12C
Drive control unit module
Popular ABB Models
Model
Module Type
PM783F
AC800M processor module
PM901F
Freelance PLC processor
CI840A
Communication interface module
AI830A
Analog input module
SB822
Power supply module
Applications
The ABB S-093H module is designed for high-power industrial drive and power conversion systems.
Typical applications include:
Medium-voltage motor drive systems
Wind power converter systems
Mining and metallurgy equipment
Cement and steel industry drives
Oil and gas processing plants
Large pumps, compressors, and conveyor drives
Grid stabilization and power conversion systems
In these systems, the module precisely controls phase synchronization, voltage regulation, and power conversion, ensuring reliable operation of high-power motors and converters.
Advantages
High-Power Conversion Capability
Supports power systems from several megawatts up to over 100 MVA, suitable for large industrial drives.
Advanced IGCT Technology
Utilizes integrated gate-commutated thyristor technology for efficient and reliable power switching.
Modular System Architecture
The modular design allows easy maintenance, system expansion, and hot-swap replacement.
High Efficiency and Energy Savings
Power conversion efficiency can exceed 98%, reducing energy losses in industrial drive systems.
Integrated Protection Functions
Includes protection against overcurrent, short circuit, overheating, and abnormal voltage conditions.
Industrial-Grade Reliability
Designed for harsh environments such as mining, steel plants, and heavy manufacturing facilities.
Technical FAQs
1. What is the ABB S-093H module used for?
It is a phase module used in medium-voltage drive systems to control power conversion and phase regulation.
2. Which ABB systems use the S-093H module?
It is commonly used in ACS6000 and PCS6000 medium-voltage converter systems.
3. What technology does the module use?
It uses IGCT power electronics technology for high-power switching and efficient conversion.
4. What industries use the S-093H module?
Mining, metallurgy, power generation, oil and gas, and large industrial manufacturing.
5. What is the operating temperature range?
Typically −25 °C to +60 °C depending on installation conditions.
6. What is the approximate size of the module?
About 850 × 550 × 650 mm.
7. What is the weight of the module?
Approximately 220 kg.
8. Does the module support modular expansion?
Yes, it supports modular system architecture for scalable power systems.
9. Can it be replaced without major system changes?
Yes, the modular design allows easier replacement and maintenance.
10. Why choose ABB S-093H?
Because it provides reliable high-power conversion, high efficiency, and stable operation in demanding industrial environments.
