Woodward 5461‑290 High Voltage Power Supply & Control Module for Industrial and Turbomachinery Systems
Woodward 5461‑290 High Voltage Power Supply & Control Module for Industrial and Turbomachinery Systems
0.0
Points
Brand:Woodward Item No.:Woodward 5461‑290 Product Origin:USA Product Dimensions:102 × 127 × 224 mm Product Weight:1.5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Woodward 5461‑290 is a versatile industrial component primarily recognized as a high‑voltage power supply and modular controller for Woodward automation architectures. Designed for reliability in harsh environments, this unit plays a key role in distributed control systems such as Woodward MicroNet Plus and NetCon 5000, particularly in turbine and turbomachinery control networks. Its robust design ensures dependable performance in both legacy and modern industrial automation applications.
Technical Specifications
Specification
Details
Model
5461‑290
Module Type
High Voltage Power Supply / Control Module
Manufacturer
Woodward
Primary Function
Provides high‑voltage power support and integrates with control system I/O
System Compatibility
Woodward MicroNet Plus / NetCon 5000 control architectures
Operating Environment
Industrial control systems
Power Supply Role
High‑voltage power distribution support
Dimensions (L×W×H)
102 × 127 × 224 mm (approx.) (derived from 4.0 in × 5.0 in × 8.8 in)
Weight
1.5 kg (approx.)
Mounting
Rack / panel installation in control cabinets
Warranty
Varies by supplier (often 1–2 years)
Build
Industrial, rugged enclosure
Country of Manufacture
USA (typical for Woodward products)
