Woodward 5462‑758B Discreet Output Module for Industrial Control & Automation Systems
Woodward 5462‑758B Discreet Output Module for Industrial Control & Automation Systems
0.0
Points
Brand:Woodward Item No.:Woodward 5462‑758B Product Origin:USA Product Dimensions:225 × 194 × 12.7 mm Product Weight:0.6 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Woodward 5462‑758B is a discrete output module engineered for heavy‑duty control and automation applications in industrial systems. Designed to provide reliable discrete signal outputs, this module is typically used within distributed control systems, turbine controls, and PLC/DCS environments where robust status indication and signal interfacing are needed. Built with a clear LED indicator system, the 5462‑758B offers visual feedback to simplify monitoring and diagnostics in complex installations.
Technical Specifications
Specification
Details
Model
5462‑758B
Module Type
Discrete Output Module
Manufacturer
Woodward (USA)
Function
Provides discrete digital output channels
LED Indication
29 LEDs (28 orange, 1 red) for status feedback
Input Pin Count
120‑pin interface for I/O connections
Operating Environment
Industrial automation & control systems
Mounting
Rack / control cabinet integration
Dimensions (L×W×H)
~ 225 × 194 × 12.7 mm (8 7/8″ × 7 5/8″ × 1/2″)
Weight
~ 0.6 kg (approx. less than 2 lbs before packaging)
Industrial Durability – Built to endure typical control room and plant conditions.
Broad Compatibility – Integrates with Woodward and third‑party control architectures.
Compact Form Factor – Efficient rack or panel mounting without occupying excessive space.
Technical FAQs
1. What is the main function of the 5462‑758B?
It serves as a discrete output interface that relays digital signals from a controller to field devices.
2. What kind of LED status system does it use?
It features 28 orange LEDs for normal channel activation and 1 red LED for fault or alarm indication.
3. How many pins are used for connection?
It uses a 120‑pin interface for output connections.
4. Is this module still manufactured?
This model is generally discontinued by Woodward but is available as new surplus.
5. What systems can it integrate with?
It integrates with Woodward MicroNet, NetCon, PLC and DCS systems.
6. What environments is it suited for?
Industrial automation and control cabinets where discrete outputs are required.
7. What is the approximate size of the module?
Roughly 225 × 194 × 12.7 mm (8 7/8″ × 7 5/8″ × 1/2″).
8. How much does it weigh?
About 0.6 kg (less than 2 lbs un‑packaged).
9. Why are discrete output modules important?
They provide reliable digital signal control to external devices like actuators, alarms, or indicators.
10. Where is this module typically installed?
Inside industrial control cabinets or racks alongside CPUs and power modules.
