The ABB XV C768 AE105 (order code: 3BHB007211R0105) is a current measuring and scaling interface module used in ABB medium-voltage drive and industrial power conversion systems.
It is designed to perform precise current signal acquisition, scaling, and isolation, converting high-power circuit measurements into low-level feedback signals for control and protection systems. This ensures accurate monitoring of motor current, converter performance, and system protection logic.
The module is widely used in ABB ACS1000-type medium-voltage drive platforms, where stable current feedback is critical for safe operation and high-performance motor control.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | XV C768 AE105 |
| Order Code | 3BHB007211R0105 |
| Product Type | Current Measuring / Scaling Module |
| System Compatibility | ABB MV drive systems (e.g., ACS1000) |
| Function | Current measurement, scaling, signal conversion |
| Input Signal | High-current sensing circuit (CT-based) |
| Output Signal | Low-level analog feedback signal |
| Accuracy | High-precision industrial measurement grade |
| Isolation | Galvanic isolation (system dependent design) |
| Operating Temperature | -25°C to +70°C |
| Mounting Type | Plug-in PCB module (drive cabinet) |
Physical Characteristics
| Item | Specification |
|---|---|
| Dimensions (L × W × H) | 178 × 305 × 59 mm |
| Weight | Approx. 0.58 kg |
| Form Factor | Industrial PCB board |
| Installation | Rack-mounted / drive internal slot |
