Introduction

The ABB DSQC 697 3HAC037084-001 DeviceNet board is a high-performance communication interface designed to connect ABB robotic systems with DeviceNet-based industrial networks. It plays a crucial role in enabling distributed automation by allowing controllers to communicate with multiple devices efficiently.

With its compact form factor and robust communication capabilities, this board enhances system flexibility and scalability, making it a reliable choice for modern industrial automation environments where stable and real-time communication is essential.

Technical Specifications

Parameter	Specification
Product Type	DeviceNet Communication Board
Manufacturer	ABB
Model	DSQC 697
Part Number	3HAC037084-001
Communication Protocol	DeviceNet (CAN-based)
Operating Mode	Master / Slave
Operating Voltage	24V DC
System Integration	ABB IRC5 Controllers
Mounting Type	Control Cabinet Installation
Dimensions (W × H × D)	140 mm × 10 mm × 130 mm
Weight	0.4 kg (0.88 lb)

Applications

The ABB DSQC 697 3HAC037084-001 DeviceNet board is engineered to enable seamless industrial communication between robotic controllers and distributed field devices. It is widely applied in:

ABB IRC5 robot controllers for DeviceNet network integration
Industrial automation systems requiring CAN-based communication
Robotic production lines with decentralized I/O architectures
Automotive and assembly systems with synchronized device control
Smart manufacturing environments with real-time data exchange

This module functions as a communication interface, allowing robots and control systems to interact efficiently with external devices across DeviceNet networks.

Advantages

Supports DeviceNet communication based on robust CAN technology
Enables both master and slave communication configurations
Compact PCB design ideal for dense control cabinet layouts
High noise immunity for stable industrial data transmission
Reliable operation in continuous-duty automation environments

Technical FAQs

What is the primary function of this board?
It enables DeviceNet communication between ABB controllers and field devices.
Which systems typically use this module?
It is mainly used in ABB IRC5 robot controller systems.
Does it support master and slave modes?
Yes, it can operate in both DeviceNet master and slave configurations.
What communication protocol does it use?
It uses DeviceNet, which is based on CAN bus technology.
What is the required system software?
It requires RobotWare 5.13 or higher for proper operation.
What type of signals can it handle?
It supports communication signals for distributed I/O and device control.
Is it suitable for real-time industrial communication?
Yes, it ensures deterministic and stable data exchange.
What voltage does it operate on?
It typically operates on 24V DC industrial power.
Can it be used in harsh environments?
Yes, it is designed for industrial conditions with wide temperature tolerance.
Is it replaceable without system impact?
Replacement requires system shutdown and proper configuration afterward.
