The GE IC697CHS783 is a high-flexibility VME integrator rack chassis designed for the GE Fanuc Series 90-70 PLC platform. It is engineered to support both GE IC697 modules and third-party VME boards, making it a powerful solution for hybrid automation systems, system expansion, and industrial retrofit projects.
Unlike standard PLC racks, this model is optimized for multi-vendor integration and configurable backplane architecture, allowing engineers to build complex control systems with maximum flexibility and long-term scalability.
Technical Specifications
The IC697CHS783 provides a versatile rack platform for mixed PLC and VME environments.
| Parameter | Specification |
|---|---|
| Model | IC697CHS783 |
| Product Type | VME Integrator PLC Rack |
| Series | GE Fanuc Series 90-70 |
| Slot Capacity | 17 slots (single-width) or mixed VME configuration |
| Module Compatibility | GE IC697 + 3rd-party VME modules |
| Backplane Standard | VME C.1 compatible |
| Power Supply | Plug-in AC/DC or external supply (adapter required) |
| Current Rating | 3.3 A @ 5 V DC (typical system load) |
| Expansion Support | Dual rack operation capability |
| Configuration | Jumper-configurable backplane slots |
| Cooling | Natural convection (optional fan kit) |
| Installation | Front or rear rack mount |
This rack is designed for engineering flexibility, supporting both standard PLC modules and external VME hardware integration.
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | ≈ 483 mm × 190 mm × 283 mm (19 × 7.5 × 11.15 in) |
| Weight | ≈ 4.5 kg – 5.8 kg (typical configuration) |
The rack is designed for standard 19-inch industrial cabinet mounting, with sufficient depth for rear wiring and airflow clearance.
Recommended Related Models
For a complete GE Series 90-70 system, IC697CHS783 is commonly paired with:
- GE IC697CPU772 Central Processing Unit
- GE IC697CGR935 Hot Standby CPU Module
- GE IC697PWR711 Power Supply Module
- GE IC697RCM711 Redundancy Communication Module
- GE IC697BEM713 Bus Transmitter Module
- GE IC697MDL Digital & Analog I/O Modules
These components enable scalable, hybrid, and high-reliability PLC architectures.
Popular GE Series 90-70 Modules
- IC697CPU780 – Standard PLC CPU
- IC697BEM731 – Genius Bus Controller
- IC697BEM733 – Remote I/O Scanner
- IC697ALG440 – Analog input module
- IC697CMM741 – Ethernet communication module
These modules are widely used in industrial automation, SCADA systems, and long-life legacy installations.
